Philips HQT562/00 Manuale utente

ENGLISH 4

DEUTSCH 10

NORSK 17

SVENSKA 23

SUOMI 29

DANSK 35

HQT562

Important

◗Check if the voltage indicated on the mains

plug corresponds to the mains voltage in your

home before you connect the appliance.

◗Make sure that the appliance does not get

wet.

◗This appliance is only designed for trimming

the human beard.

◗Keep the appliance out of the reach of

children.

Charging

Charge the appliance fully before you start using

it for the first time.

1Make sure the appliance is switched off.

C2Insert the appliance plug into the

appliance.

3Put the mains plug in the wall socket.

C◗The green pilot light on the adapter will go on

to indicate that the appliance is charging.

It will take approx.14 hours to fully charge the

battery.

To optimize the lifetime of the appliance,do not

charge it for more than 24 hours.

A fully charged appliance has a trimming time of

up to 50 minutes.

ENGLISH4

CHARGE

Trimming

Always comb the beard and/or moustache with a

fine comb before you start trimming.

Do not move the trimmer too fast.Make smooth

and gentle movements.

Trimming with comb attachment

C1Slide the adjustment comb to the desired

trimming length setting (see table).

The setting will appear in the window in the

middle of the attachment comb.

BIf you are trimming for the first time,start by using

the maximum trimming length setting:setting 4.

2Switch the appliance on.

C3To trim in the most effective way,move

the trimmer against the direction of hair

growth.Make sure the flat surface of the

comb always stays in contact with the skin.

C4If a lot of hair has accumulated in the

comb,remove the comb attachment by

adjusting it to setting 4 and then pulling it

off the appliance.

C5Blow and/or shake the hair out of the

comb.Readjust the comb to the chosen

setting.

ENGLISH 5

Trimming length settings table

◗Using setting 1 will result in an unique 'stubble

look'.

Trimming without comb attachment

Full beards and single hairs

C1Remove the comb attachment by adjusting

it to setting 4 and then pulling it off the

appliance.

Never pull at the flexible top of the comb

attachment.Always pull at the bottom part.

2Switch the appliance on.

C3Make well-controlled movements.Touch

the hair lightly with the trimmer.

Cleaning

Do not use abrasives,scourers or liquids such as

alcohol,petrol or acetone to clean the appliance.

ENGLISH6

resulting beard length

1.5 mm

3.0 mm

5.0 mm

7.0 mm

setting

1Make sure the appliance is switched off

and disconnected from the mains.

2Remove the comb attachment.

C3Open the cutting unit by pushing it

backwards (1).

4Clean the cutting unit and the inside of the

appliance with the brush supplied (2).

C5Close the cutting unit by pushing it back

onto the appliance until you hear a click.

Replacing the cutting unit

A worn or damaged cutting unit should only be

replaced with an original Philishave cutting unit,

available from authorised Philips service centres.

C1Open the cutting unit.

2Remove the old cutting unit by pulling it

upwards.

C3Place the two lugs of the new cutting unit

into the guiding slots.

4Push the cutting unit back onto the

appliance until you hear a click.

ENGLISH 7

CLICK

Environment

To protect the environment,this appliance has

been equipped with a nickel-metal-hydride

battery which contains less than 0.01% cadmium.

Remove the rechargeable battery when you

discard the appliance.

Do not throw the battery away with the normal

household waste but hand it in at an official

collection point.

You can also take the appliance to a Philips

service centre,where the staff will be happy to

help you remove the battery and dispose of it in

an environmentally safe way.

1Disconnect the appliance from the mains

and let the appliance run until the motor

stops.

C2Undo the screw of the base plate on the

rear side of the appliance.

3Pull the battery holder approximately

4 cm.out of the appliance.

C4Insert the screwdriver into the small slot

in the printed circuit board marked with

an arrow.Push the screwdriver down until

parts of the printed circuit board break

off.

ENGLISH8

C5Grasp the blue wire and pull the battery

out of the appliance.

Do not connect the appliance to the mains again

after it has been opened!

Guarantee & service

If you need information or if you have a problem,

please visit the PhilipsWeb site at

www.philips.com or contact the Philips Customer

Care Centre in your country (you will find its

phone number in the worldwide guarantee

leaflet).If there is no Customer Care Centre in

your country,turn to your local Philips dealer or

contact the Service Department of Philips

Domestic Appliances and Personal Care BV.

ENGLISH 9

Wichtig

◗Prüfen Sie,bevor Sie das Gerät in Betrieb

nehmen,ob die Spannungsangabe auf dem

Steckernetzgerät mit der örtlichen

Netzspannung übereinstimmt.

◗Achten Sie darauf,dass das Gerät nicht nass

wird.

◗Dieses Gerät ist nur zum Schneiden von

menschlichen Bärten bestimmt.

◗Halten Sie das Gerät außer der Reichweite

von Kindern auf.

Akku aufladen

Laden Sie den Akku voll auf,bevor Sie das Gerät

zum ersten Mal benutzen.

1Achten Sie darauf,dass das Gerät

ausgeschaltet ist.

C2Stecken Sie den Gerätestecker in das

Gerät.

3Stecken Sie den Netzstecker in die

Steckdose.

C◗Die grüne Kontroll-Lampe auf demAdapter

leuchtet auf und zeigt an,dass derAkku

geladen wird.

Der Akku ist nach ca.14 Stunden voll aufgeladen.

Halten Sie das Gerät nicht länger als 24 Stunden

am Netz;um eine optimale Lebensdauer des

Akkus zu gewährleisten.

DEUTSCH10

CHARGE

Mit voll aufgeladenem Akku können Sie das Gerät

ca.50 Minuten.

Bart schneiden

Kämmen Sie den Bart/den Schnurrbart vor dem

Gebrauch des Geräts mit einem feinen Kamm

aus.

Führen Sie das Gerät nicht zu schnell durch den

Bart.Gehen Sie langsam,mit ruhigen und

kontrollierten Bewegungen vor.

Bartschneiden mit dem Scherkamm-

Aufsatz

C1Schieben Sie den Scherkamm-Aufsatz auf

die Einstellung hoch,die der gewünschten

Bartlänge entspricht.-Vgl.dieTabelle.

Die Einstellung wird in dem Fenster im

Scherkamm-Aufsatz sichtbar.

BWenn Sie das Gerät zum ersten Mal verwenden,

dann beginnen Sie mit der höchsten Einstellung:

Position 4.

2Schalten Sie das Gerät ein.

C3Das beste Resultat erhalten Sie,wenn Sie

das Gerät gegen die Bartwuchsrichtung

führen.Achten Sie darauf,dass die flache

Seite des Scherkamm-Aufsatzes stets in

gutem Kontakt mit der Haut bleibt.

DEUTSCH 11

C4Sollten sich im Scherkamm-Aufsatz viele

Haare ansammeln entfernen Sie den

Aufsatz indem sie ihn auf Position 4 stellen

und dann vom Gerät abziehen.

C5Blasen und/oder schütteln Sie das

angesammelte Haar heraus.Setzen Sie den

Scherkamm-Aufsatz wieder auf,und stellen

Sie die gewünschte Position wieder ein.

Tabelle der Barthaarlängen

◗MitVerwendung der Position 1 schneiden Sie

einen 3-Tage-Bart.

Verwendung ohne den Scherkamm-

Aufsatz

Vollbart konturieren und einzelne Haare

zurückschneiden

DEUTSCH12

Resultierende Barthaarlänge

1,5 mm

3,0 mm

5,0 mm

7,0 mm

Position
