Philips Philishave 655 Manuale utente

655

RECHARGEABLE

English Page 4

• Keep pages 3, 40, 41, and 42 open when reading

these operating instructions.

Français Page 9

• Pour le mode d'emploi: dépliez la page 3 et les pages 40,

41 et 42.

Deutsch Seite 14

• Schlagen Sie beim Lesen der Gebrauchsanweisung Seite

3 und Seiten 40, 41 und 42 auf.

Nederlands Pagina 19

• Sla bij het lezen van de gebruiksaanwijzing pagina 3 en de

pagina's 40, 41 en 42 op.

Italiano Pagina 24

• Prima di usare l'apparecchio, aprite la pagina 3 e le pagine

40, 41 e 42 e leggete attentamente le istruzioni per l'uso.

Español Página 29

• Desplegar la página 3 y las páginas 40, 41 y 42 al leer las

instrucciones de manejo.

Português Página 34

• Durante a leitura do modo de emprêgo, desdobre e

verifique a pág. 3 e as pág. 40, 41 e 42.

Important

•Please read these instructions carefully in

conjunction with the illustrations (pages 3, 40, 41

and 42) before using the appliance.

•If using the Philishave system for the first time,

please bear in mind that your skin may need about

two weeks to become fully accustomed to the new

shaving method.

•Regular cleaning and maintenance ensures

optimal performance and prolongs the shaver's

working life.

•Before using the shaver for the first time and also

if the shaver has not been used for a month or

more, charge it for at least 24 hours.

•Do not allow the shaver to come into contact with

water.

•Do not leave the appliance in a very warm place or

in direct sunlight.

The built-in rechargeable nickel-cadmium batteries

contain substances which may pollute the

environment.

When discarding your appliance in due course, please

ensure that the batteries are separated from the normal

household refuse and that they are disposed of at an

officially assigned place. (Please refer to section "How to

remove the built-in rechargeable batteries".)

This product is manufactured to comply with the radio

interference requirements of the council directive

87/308/EEC.

English

You now own an excellent Philishave®shaver featuring the

unique Philishave Rotary Action shaving system.

General description (fig. 1, page 3)

AShaving unit with three shaving heads. Each shaving

head consists of a guard and a cutter.

BGreen pilot light. Illuminates whilst the shaver is

connected to the mains supply (for charging or shaving

directly from the mains).

COn/Off switch. The shaver is prevented from being

switched on accidentally by the locking device

incorporated in the switch.

- On: keep the locking knob on the switch pressed-in

and slide the switch upwards.

- Off: slide the switch downwards.

DMains cord. Using the mains cord you can connect the

shaver to any mains voltage between 100 and 240 Volts

AC (for charging and shaving).

EConnector. When using the mains cord insert the small

plug firmly into the connector up to the indication mark.

FTrimmer. The trimmer can be switched on whilst the

motor is running.

- Switch on by moving the slide (f) upwards.

- Switch off by moving the slide downwards.

- Brush the trimmer clean after use.

GBrush. Refer to section "Maintenance and cleaning" for

correct usage.

HProtective cap. Keep the protective cap on the shaver

when not in use.

Shaving tips for a close, quick and comfortable shave

•The best results are obtained if the skin is dry. So

preferably shave before washing or some time afterwards.

•If required, apply a preshave lotion. This can be

particularly helpful if the climate is warm and humid.

•The Philishave system gives you a quick, close and

comfortable shave. Just move the shaving unit quickly

over the skin.

•For the best results stretch the skin to bring the hairs into

an upright position.

Then move the shaving unit against the direction of the

growth of the hairs. 5

•The trimmer has been especially designed for grooming

sideburns, moustache and beard.

The trimmer is not required for long hairs in the neck area;

these hairs can easily be shaved off with the shaving unit.

Charging

•We advise you to charge the batteries at temperatures

between 5°C and 35°C (40°F and 95°F respectively).

Charging at temperatures outside this range will reduce

the lifetime of the rechargeable batteries.

•Keep the cassette open if you charge the appliance in it.

- Slide the on/off switch (C) downwards.

- Insert the small plug firmly into the connector (E) up to the

indication mark.

- Then connect to the wall socket.

The green pilot light (B) will come on.

After 8 hours the shaver will be fully charged. This allows

cordless shaving for a period of about 2 weeks. The number

of shaves per charge is dependent upon your beard type

and shaving time. Regular cleaning has a beneficial effect

on this. (See section "Maintenance and cleaning".)

It will not harm the appliance if it remains connected to the

mains supply (max. 4 weeks).

Shaving directly from the mains

- Slide the on/off switch (C) downwards.

- Connect the appliance to a wall socket.

- Then switch the appliance on.

Maintenance and cleaning (fig. 2-17 on pages 40 and 41)

•Always switch the shaver off before carrying out

maintenance or cleaning.

•The rotating cutter blades of the Philishave system keep

the shaved stubble neatly inside the shaving unit. In

general, the shaving unit needs cleaning only once a

week.

Every week

Fig. 2. Clean the guard slots using the short bristled end of

the brush.

Fig. 3. Pull the shaving unit from the shaver.

Fig. 4 and 5. Clean the inside using the long bristled end of

the brush.

Every three months

If your skin is of an oily type or if you have been using a pre-

shave lotion, this procedure should be carried out once a

month.

Fig. 6. Pull the shaving unit from the shaver.

Fig. 7. Press the wheel downward and turn it anti-clockwise

(see the arrow). Then lift the cluster frame holding

the shaving heads from the shaving unit.

Fig. 8. Slide one shaving head (guard and cutter) out of the

frame. Keep your finger under the shaving head to

prevent the cutter from falling out of the guard.

Fig. 9. Keep the guard and cutter together because

each pair has been especially ground to match

each other. If the guards and cutters are mixed, it

may take a couple of weeks before optimal shaving

performance is restored.

Fig. 10. Hold the cutter as shown...

Fig. 11 ....and brush it carefully clean as illustrated.

Use only the short bristled end of the brush.

Fig. 12. Clean the inside of the guard, using the long bristled

end of the brush.

Fig. 13. Slide the shaving head back into place. Then clean

the other two shaving heads one by one in the

same way.

Fig. 14. Replace the cluster frame with the shaving heads.

Do not forget to secure the cluster frame by pressing

the wheel downward and turning it clockwise.

Fig. 15. Do not apply any pressure to the guards when

replacing the shaving unit on to the shaver.

Fig. 16. If you have used a degreasing liquid (e.g. alcohol) to

clean the shaving heads, or if your skin is very dry,

lubricate the guards with one drop of light machine

oil.

Every six months

Fig. 17. Put two drops of light machine oil on the teeth of the

trimmer.

Replacement shaving heads

Worn or damaged shaving heads must be replaced only with

the original Philips replacement heads type HP 1917.

How to remove the built-in rechargeable batteries

(when discarding the appliance) (fig. 18-21, page 42)

- Remove the plug from the wall socket.

- Push the trimmer slide (f) upwards (fig. 18).

- Unscrew the two countersunk screws at the back side of

the shaver. For this purpose you can use a small

screwdriver (width approx. 2 mm) or a Torx T-8 type

screwdriver (fig. 19).

- Remove the back plate of the appliance (fig. 20).

- Remove the two rechargeable batteries (fig. 21). You will

recognise the batteries by the three arrows symbol.

Do not connect the appliance to the mains power after

the batteries have been removed.

Important

•Lisez attentivement ce mode d'emploi et regardez

tous les dessins des pages 3, 40, 41 et 42 avant

d'utiliser l'appareil.

•Lorsque vous utilisez le système "Philishave"

pour la première fois, il est important de savoir

qu'une période d'adaptation de la barbe d'environ

2 semaines est nécessaire pour obtenir l'efficacité

optimale du rasage.

•Un nettoyage et un entretien réguliers vous

garantissent de bonnes performances et une

longue durée de vie de l'appareil.

•Avant la première utilisation du rasoir, ou après

une période de non utilisation prolongée

(supérieure àun mois), il est recommandéde

mettre l'appareil en charge pendant au moins

24 heures consécutives pour obtenir les meilleurs

résultats des accumulateurs.

•Evitez tout contact de l'appareil avec l'eau.

•Ne laissez pas l'appareil exposéàde fortes

chaleurs ou aux rayons directs du soleil.Vous êtes

maintenant propriétaire d'un rasoir Philishave de

hautes performances, utilisant un principe de

rasage unique avec têtes rotatives.

Les accumulateurs rechargeables au nickelcadmium

contiennent des substances qui peuvent polluer

l'environnement.

Le jour oùvotre appareil arrivera en fin d'utilisation, assurez-

vous au préalable que les accumulateurs soient retirés de

leur emplacement normal et qu'ils soient déposés dans un

endroit assignéàcet effet. (Voir chapitre "Comment retirer

les accumulateurs rechargeables".)

Français

Vous êtes maintenant propriétaire d'un rasoir Philishave®de

hautes performances, utilisant un principe de rasage unique

avec têtes rotatives.

Description générale (fig. 1, page 3)

AUnitéde rasage avec 3 têtes de rasage (grilles et

couteaux).

BTémoin lumineux vert. S'allume lorsque le rasoir est

sous tension (pour recharge ou utilisation directe sur

secteur).

CInterrupteur marche/arrêt, avec sécuritécontre la mise

en marche involontaire.

Mise en marche: appuyez sur la sécuritéet faites

glisser l'interrupteur vers le haut.

Arrêt: faites glisser l'interrupteur vers le bas.

DCordon d'alimentation. Le cordon d'alimentation

permet d'utiliser l'appareil sur des tensions secteur de

100 à240 Volts AC.

EConnecteur. Enfoncez bien la fiche dans le connecteur

jusqu'au repère.

FTondeuse. La tondeuse peut être mise en service

pendant que le moteur fonctionne.

- Pour cela, faites glisser le curseur (f) vers le haut.

- Pour l'arrêter, ramenez le curseur vers le bas.

- Nettoyez la tondeuse avec la brosse après chaque

utilisation.

GBrosse. Lisez le chapitre "Entretien et nettoyage" pour

utiliser correctement la brosse.

HCapot de protection. Remettez le capot sur l'unitéde

rasage après chaque utilisation.

Conseils de rasage

pour un rasage rapide, agréable et de très près.

•On obtient les meilleurs résultats quand la peau est bien

sèche. Il est donc préférable de se raser avant de se laver

ou quelque temps après.

•Utilisez éventuellement une lotion de pré-rasage, ce qui

assure un rasage plus agréable, particulièrement en climat

chaud et humide.

•Le système Philishave vous assure un rasage rapide,

agréable et de très près. Déplacez rapidement la tête de

rasage sur la peau.

Questo manuale è adatto per i seguenti modelli

Indice

Lingue:

Altri manuali Philips Rasoio elettrico

Philips

Philips HQ6900 series User m Manuale operativo

Philips

Philips PT920CC Manuale utente

Philips

Philips SH70/70 Manuale utente

Philips

Philips Norelco Beardtrimmer 3000 Manuale di istruzioni

Philips

Philips Norelco NT9145 Manuale utente

Philips

Philips RQ1100 Series Manuale utente

Philips

Philips HQT162/60 Manuale utente

Philips

Philips Essence 5000 Series Manuale utente

Philips

Philips HP6383 Manuale utente

Philips

Philips RQ1275CC Manuale utente

Philips

Philips HC5100 Manuale utente

Philips

Philips HQ4441, HQ4421, HQ4411, HQ4407, HQ4406,... Manuale utente

Philips

Philips HQ5812 Manuale utente

Philips

Philips Norelco SmartTouch-XL 9195XL Manuale utente

Philips

Philips HQ5811/16 Manuale utente

Philips

Philips HQ4830/16 Manuale utente

Philips

Philips BT3237 Manuale utente

Philips

Philips AT9 SERIES Manuale utente

Philips

Philips OneBlade QP2530 Manuale utente

Philips

Philips TW-RQ1050 Manuale utente

Philips

Philips S5060/05 Manuale utente

Philips

Philips HQ6466/01 Manuale utente

Philips

Philips TT2021/32 Manuale utente

Philips

Philips HQ8251 Manuale utente

Manuali Rasoio elettrico popolari di altre marche

Norelco

Norelco Quadra 7610X Manuale utente

Braun

Braun WaterFlex WF2s Manuale utente

Daga

Daga MT-400 Manuale

Remington

Remington BHT100 Manuale utente

Kompernass

Kompernass KH 5537 Manuale utente

Remington

Remington BHT6100 Manuale utente

MIA

MIA Aqua Body Manuale utente

Matheo

Matheo MLR 15 Manuale utente

CTC Union

CTC Union Clatronic HSM 3441 NE Manuale utente

Remington

Remington XR7000 Manuale utente

Eldom

Eldom G47 Manuale utente

Braun

Braun silk-epil 5 Manuale utente

SEVERIN

SEVERIN SÉRIE E700 0533 Guida utente

Remington

Remington PR1355 Manuale utente

Aurora

Aurora AU 3543 Manuale utente

Braun

Braun InterFace 3614 Manuale utente

Wahl

Wahl 8061 5-STAR Manuale utente

Norelco

Norelco 4404LC Manuale utente
