Philips RQ1052 Manuale utente

RQ1090, RQ1062, RQ1060, RQ1052, RQ1050 with charger

ENGLISH 6

FRANÇAIS 23

Introduction

Thank you for buying this Philips shaver. Please read

this user manual, as it contains information about the

wonderful features of this shaver as well as some tips

to make shaving easier and more enjoyable.

Important

Read this user manual carefully before you use the

shaver, the Power Pod and the charger. Save the user

manual for future reference.

Danger

- Make sure the adapter does not get wet.

Warning

- Be careful with hot water. Always check if the

water is not too hot, to prevent your hands from

getting burnt.

- The adapter contains a transformer. Do not cut

off the adapter to replace it with another plug, as

this causes a hazardous situation.

- The shaver, the Power Pod and the charger

are not intended for use by persons (including

children) with reduced physical, sensory or mental

capabilities, or lack of experience and knowledge,

unless they have been given supervision or

instruction concerning use of the appliances by a

person responsible for their safety.

- Children should be supervised to ensure that they

do not play with the shaver, the Power Pod and

the charger.

Caution

- Do not use the shaver, the Power Pod, the

charger or the adapter if it is damaged.

- Charge and store the shaver at a temperature

between 5°C and 35°C.

ENGLISH

- Always put the protection cap on the shaver

to protect the shaving heads when you are

travelling.

- Never use scouring pads, abrasive cleaning agents

or aggressive liquids such as petrol or acetone to

clean the appliance.

- Only use the adapter supplied.

- If the adapter is damaged, always have it replaced

with one of the original type in order to avoid a

hazard.

- Never immerse the Power Pod in water, nor rinse

it under the tap.

- Never immerse the charger in water, nor rinse it

under the tap.

Compliance with standards

- The shaver complies with the internationally

approved IEC safety regulations and can be safely

cleaned under the tap.

- These Philips appliances comply with all standards

regarding electromagnetic elds (EMF). If handled

properly and according to the instructions in this

user manual, the appliances are safe to use based

on scientic evidence available today.

General

- The adapter transforms 100-240 volts to a safe

low voltage of less than 24 volts.

Overview (Fig. 5)

AProtection cap

BShaving unit

CTrimmer

DTrimmer on/off slide

ENGLISH 7

EShaver (RQ1090/RQ1062/RQ1060/RQ1052/

RQ1050)

FShaver on/off button

GDisplay

HPower Pod

ICleaning brush

JAdapter

KSmall plug

LCharger

The display

Before you use the shaver for the rst time, remove

the protective foil from the display.

The ve shaver types (RQ1090, RQ1062, RQ1060,

RQ1052 and RQ1050) have different displays, which

are shown in the gures below.

- RQ1090

- RQ1062/RQ1060

- RQ1052/RQ1050

Charging

- Charging takes approx. 1 hour.

ENGLISH8

- When you place the shaver in the Power Pod

or in the charger, the display automatically

switches off after approx. 5 hours.

RQ1090

- When the shaver is charging, the minutes

indication and the plug symbol ash.

- The shaving minutes increase until the shaver is

fully charged.

RQ1062/RQ1060

- When the shaver is charging, the plug

symbol ashes.

- First the arrowheads of the bottom charge level

ash, then the arrowheads of the second level

ash, and so on until the shaver is fully charged.

RQ1052/RQ1050

- When the shaver is charging, the battery symbol

ashes blue.

Battery fully charged

RQ1090

- When the battery is fully charged, the minutes

indication is visible on the display and the plug

symbol disappears from the display.

RQ1062/RQ1060

- When the battery is fully charged, all arrowheads

and all charge level lights light up blue continuously

and the plug symbol disappears from the display.

ENGLISH 9

- When you remove the shaver from the Power

Pod or the charger, the arrowheads of the top

charge level light up blue to indicate that the

battery is full.

RQ1052/RQ1050

- When the battery is fully charged, the battery

symbol lights up blue continuously.

Battery low

RQ1090

- When the battery is almost empty (when there

are only 5 or fewer shaving minutes left), the

minutes indication and the plug symbol start to

ash.

- When you switch off the shaver, the shaving

minutes and the plug symbol continue to ash for

a few more seconds.You hear a beep when there

are no minutes left.

RQ1062/RQ1060

- When the battery is almost empty (when there

are only 5 or fewer shaving minutes left), the

battery symbol ashes red and the arrowheads of

the bottom charge level ash blue.

- When you switch off the shaver, the battery

symbol and the arrowheads of the bottom charge

level continue to ash for a few seconds.

ENGLISH10

RQ1052/RQ1050

- When the battery is almost empty (when there

are only 5 or fewer shaving minutes left), the

battery symbol lights up red.

- When you switch off the shaver, the battery

symbol starts to ash for a few seconds.

Remaining battery capacity

RQ1090

- The remaining battery capacity is indicated by the

number of shaving minutes shown on the display.

RQ1062/RQ1060

- The remaining battery capacity is indicated by the

ashing arrowheads of a particular charge level

Clean shaver

For optimal shaving performance, we advise you to

clean the shaver after every use.

- The tap symbol ashes to remind you to clean the

shaver.

Note:The displays of types RQ1062, RQ1060, RQ1052

and RQ1050 look different but show the same

indication.

Replace shaving unit

For maximum shaving performance, we advise you

to replace the shaving unit every two years.

ENGLISH 11

- To remind you to replace the shaving unit, the

shaving unit symbol ashes (all types) and you

hear a beep when you switch off the shaver

(RQ1090 only).This happens at the end of 7

successive shaves to remind you to replace the

shaving unit.

Note:The displays of types RQ1062, RQ1060, RQ1052

and RQ1050 look different but show the same

indication.

Travel lock

You can lock the shaver when you are going to

travel.The travel lock prevents the shaver from being

switched on by accident.

Activating the travel lock

1 Press the on/off button for 3 seconds to enter

the travel lock mode.

,The lock symbol appears on the display (all

types) and you hear a beep (RQ1090 only) to

indicate that the travel lock has been activated.

Note:The displays of types RQ1062, RQ1060, RQ1052

and RQ1050 look different but show the same

indication.

Deactivating the travel lock

1 Press the on/off button for 3 seconds.

,The motor starts running to indicate that the

travel lock has been deactivated.

The shaver is now ready for use again.

Note:When you place the shaver in the plugged-in

Power Pod or charger, the travel lock is automatically

deactivated.

ENGLISH12
