Philips RQ1075 Manuale utente
3
H
I
J
K
L
MN
B
A
E
CD
F
G
R
Q
P
O
1
4
RQ1095, RQ1085, RQ1075
ENGLISH 6
FRANÇAIS 28
INDONESIA 52
한국어 76
BAHASA MELAYU 98
ภาษาไทย 124
142
繁體中文 165
简体中文 185
6
Introduction
Thank you for buying this Philips shaver. Please read
this user manual, as it contains information about the
wonderful features of this shaver as well as some tips
to make shaving easier and more enjoyable.
Important
Read this user manual carefully before you use the
shaver, the Jet Clean System and the Power Pod.
Save the user manual for future reference.
Danger
Make sure the adapter does not get wet.
Warning
Be careful with hot water. Always check if the
water is not too hot, to prevent your hands from
getting burnt.
The adapter contains a transformer. Do not cut
off the adapter to replace it with another plug, as
this causes a hazardous situation.
These appliances are not intended for use
by persons (including children) with reduced
physical, sensory or mental capabilities, or lack of
experience and knowledge, unless they have been
given supervision or instruction concerning use of
the appliances by a person responsible for their
safety.
Children should be supervised to ensure that they
do not play with the appliances.
Caution
Do not use the shaver, the Jet Clean System, the
Power Pod or the adapter if it is damaged.
Charge and store the shaver at a temperature
between 5°C and 35°C.
-
-
-
-
-
-
-
ENGLISH
Always put the protection cap on the shaver
to protect the shaving heads when you are
travelling.
Never use scouring pads, abrasive cleaning agents
or aggressive liquids such as petrol or acetone to
clean the appliance.
Only use the adapter supplied.
If the adapter is damaged, always have it replaced
with one of the original type in order to avoid a
hazard.
Only use the Jet Clean System with the original
HQ200 cleaning uid.
Never immerse the Jet Clean System in water nor
rinse it under the tap.
Use and store the Jet Clean System at a
temperature between 5°C and 35°C.
Always place the Jet Clean System on a stable,
level and horizontal surface to prevent leakage.
Empty the cleaning chamber and clean it
thoroughly by rinsing it with hot tap water every
15 days.
Always place the Jet Clean System on a uid-
resistant surface.
The Jet Clean System thoroughly cleans but does
not disinfect your shaver, therefore do not share
the shaver with others.
The cleaning chamber of the Jet Clean System is
not dishwasher-proof.
When the Jet Clean System is ready for use, do
not move it to prevent leakage of cleaning uid.
Never immerse the Power Pod in water, nor rinse
it under the tap.
-
-
-
-
-
-
-
-
-
-
-
-
-
-
ENGLISH 7
Compliance with standards
The shaver complies with the internationally
approved IEC safety regulations and can be safely
cleaned under the tap.
These Philips appliances comply with all standards
regarding electromagnetic elds (EMF). If handled
properly and according to the instructions in this
user manual, the appliances are safe to use based
on scientic evidence available today.
General
The adapter transforms 100-240 volts to a safe
low voltage of less than 24 volts.
Overview (Fig. 1)
AProtection cap
BShaving unit
CTrimmer
DTrimmer on/off slide
EShaver (RQ1090/RQ1060/RQ1050)
FShaver on/off button
GDisplay
HShaver holder
IJet Clean System (RQ1005/RQ1000)
JJet Clean System on/off button
KCleaning symbol
LDrying symbol
M’Cleaning chamber empty’ symbol
NCleaning chamber
OPower Pod
PCleaning brush
QAdapter
RSmall plug
-
-
-
ENGLISH8
The display
Before you use the shaver for the rst time, remove
the protective foil from the display.
The three shaver types (RQ1090, RQ1060 and
RQ1050) have different displays, which are shown in
the gures below.
RQ1090
RQ1060
RQ1050
Charging
Charging takes approx. 1 hour.
When you place the shaver in the Jet
Clean System or in the Power Pod, the
display automatically switches off after approx. 5
hours.
RQ1090
When the shaver is charging, the minutes
indication and the plug symbol ash.
The shaving minutes increase until the shaver is
fully charged.
-
-
-
-
-
-
-
ENGLISH 9
RQ1060
When the shaver is charging, the plug
symbol ashes.
First the arrowheads of the bottom charge level
ash, then the arrowheads of the second level
ash, and so on until the shaver is fully charged.
RQ1050
When the shaver is charging, the battery symbol
ashes blue.
Battery fully charged
RQ1090
When the battery is fully charged, the minutes
indication is visible on the display and the plug
symbol disappears from the display.
RQ1060
When the battery is fully charged, all arrowheads
and all charge level lights light up blue continuously
and the plug symbol disappears from the display.
When you remove the shaver from the Jet Clean
System or the Power Pod, the arrowheads of the
top charge level light up blue to indicate that the
battery is full.
-
-
-
-
-
-
ENGLISH10
RQ1050
When the battery is fully charged, the battery
symbol lights up blue continuously.
Battery low
RQ1090
When the battery is almost empty (when there
are only 5 or fewer shaving minutes left), the
minutes indication and the plug symbol start to
ash.
When you switch off the shaver, the shaving
minutes and the plug symbol continue to ash for
a few more seconds.You hear a beep when there
are no minutes left.
RQ1060
When the battery is almost empty (when there
are only 5 or fewer shaving minutes left), the
battery symbol ashes red and the arrowheads of
the bottom charge level ash blue.
When you switch off the shaver, the battery
symbol and the arrowheads of the bottom charge
level continue to ash for a few seconds.
RQ1050
When the battery is almost empty (when there
are only 5 or fewer shaving minutes left), the
battery symbol lights up red.
When you switch off the shaver, the battery
symbol starts to ash for a few seconds.
-
-
-
-
-
-
-
ENGLISH 11
Remaining battery capacity
RQ1090
The remaining battery capacity is indicated by the
number of shaving minutes shown on the display.
RQ1060
The remaining battery capacity is indicated by the
ashing arrowheads of a particular charge level
Clean shaver
For optimal shaving performance, we advise you to
clean the shaver after every use.
The tap symbol ashes to remind you to clean the
shaver.
Note:The displays of types RQ1060 and RQ1050 look
different but show the same indication.
Replace shaving unit
For maximum shaving performance, we advise you
to replace the shaving unit every two years.
To remind you to replace the shaving unit, the
shaving unit symbol ashes (all types) and you
hear a beep when you switch off the shaver
(RQ1090 only).This happens at the end of 7
successive shaves to remind you to replace the
shaving unit.
Note:The displays of types RQ1060 and RQ1050 look
different but show the same indication.
-
-
-
-
ENGLISH12
