Philips HX2225/02 Manuale utente
sensiflex
dental center HX2225
2
ENGLISH 4
BAHASA MELAYU 10
BAHASA INDONESIA 16
23
29
HX2225
3
Important
◗If the mains cord of this appliance is damaged,
it must always be replaced by Philips or a
service centre authorised by Philips,in order
to avoid hazardous situations.
◗The mains plug of the charging unit meets the
latest European standards.The plug is safe,
although the standard UK shaver socket holes
may be slightly too wide for the pins of the
plug.Make sure a proper connection is made.
◗When you use the Massage Jet for the first
time or when you have not been using it for a
long time,it is necessary to set the volume
control to its maximum setting to start the
water flowing to the jet tip.If the water
doesn't flow out after 10 seconds,put the jet
tip nozzle in your mouth and suck it shortly.
Taking optimal care of your teeth
Healthy teeth are to be treasured,which is logical,
for we want them to last a lifetime.Healthy gums
play an important role.By massaging with the
Massage Jet you keep your gums healthy.
Proper dental care is essential.By brushing only,
you may not remove all remaining food particles.
This may cause caries.By using the Massage Jet,
you are able to remove all remaining food
particles.Even hard to reach places,such as
between your teeth,can be cleaned.
ENGLISH4
Preparing the Massage Jet for use
Mounting the base unit to the wall
C1Mount the base unit to the wall,using 2
screws (3.5x30mm) and 2 wall plugs (S5)
(not included).
To drill the holes in the right places,you can use
the drilling stencil on the last page of these
directions for use.
Do not allow the base unit to come into contact
with water.
2Push excess mains cord into the storage
space in the back of the base unit.
Using the Massage Jet
When you use the Massage Jet for the first time
or when you have not been using it for a couple
of days:
C1Click the jet tip onto the appliance.
C2Remove the water reservoir from the base
unit.
ENGLISH 5
C3Fill the water reservoir with water.
4Put the water reservoir back onto the
base unit.Press it home properly.
C5Press the power button to switch the
Massage Jet on.
C6Push the slide on the handgrip upwards to
make the water start running.
When you use the Massage Jet for the first time,
let the appliance run until the water reservoir is
completely empty.Refill the water reservoir.
Tip:You may add mouthwash for extra freshness
to the water.After using mouthwash,fill the water
reservoir with clean,unmixed water and pump all
the water out of the appliance and into the
washbasin.
How to use the Massage Jet
C1Select position xfor cleaning.
ENGLISH6
C2Bend over the washbasin and hold the jet
tip close to your teeth.
C3Press the power button to switch the
Massage Jet on.
C4Push the switch slide upwards to start the
water running.
C5Guide the water jet along the front and
the back sides of the teeth and along the
gums,and direct it especially at the spaces
between the teeth to remove any
remaining food particles.
BMake sure the water jet is at straight angles to
the teeth.
BDo not direct the water jet at the gums in such
way that the jet penetrates beneath the gum line.
◗You can switch the water supply off with the
switch slide before changing the position of
the jet tip in your mouth.
C6Adjust the water volume by turning the
control ring.
ENGLISH 7
◗Tip:We advise you to use a low water volume
setting while you are getting accustomed to
the Massage Jet and when you are troubled by
gum inflammation.
7After cleaning,lower the water volume for
gum massage.
C8Guide the water over your teeth and
gums.
After using the Massage Jet
C1Remove the jet tip and put it in the
storage compartment.
C2Put the handgrip back into its holder.
Tip:You can obtain extra or replacement jet tips
at your nearest Philips Service Centre.
Cleaning the Massage Jet
1Remove the mains plug from the wall
socket.
2Clean the appliance with a damp cloth (if
necessary with some detergent).
ENGLISH8
Do not use abrasive or aggressive cleaners
scourers,alcohol,acetone,etc.
3Clean the storage compartment,the
handgrip holder,the insert container and
the water reservoir in hot soapy water.
4Rinse them under a running tap.
◗The storage compartment,the handgrip
holder and the water reservoir can also be
cleaned in a dishwasher.
Guarantee & service
If you need information or if you have a problem,
please visit the PhilipsWeb site at
www.philips.com or contact the Philips Customer
Care Centre in your country (you will find its
phone number in the worldwide guarantee
leaflet).If there is no Customer Care Centre in
your country,turn to your local Philips dealer or
contact the Service Department of Philips
Domestic Appliances and Personal Care BV.
Extra tips about the Massage Jet (for replacement
or extension) are available as an option at Philips
Service Centres.
ENGLISH 9
Penting
◗Jika kord utama peralatan ini rosak,ia mestilah
sentiasa digantikan oleh Philips atau pusat
perkhidmatan yang dibenarkan oleh Philips
untuk mengelakkan keadaan berbahaya.
◗Plag utama unit mengecas ini menepati piawai
Eropah mutakhir.Plag ini selamat,walaupun
soket pencukur UK adalah lebih sedikit lebar
untuk pin-pin plag ini.Pastikan sambungan
dibuat dengan sempurna.
◗Apabila anda menggunakan Jet Pengurut buat
pertama kali atau apabila anda tidak
menggunakannya setelah beberapa lama,
adalah perlu untuk tetapkan kawalan volume
kepada ketetapan maksimum untuk
memulakan air mengalir ke hujung jet.Jika air
tidak mengalir keluar selepas 10 saat,
masukkan hujung muncung jet ke dalam mulut
anda dan hisapnya sekejap.
Menjaga gigi anda secara optimal
Gigi yang sihat adalah sangat bernilai,ianya logik,
kerana kita mahu ianya kekal sepanjang hayat.Gusi
yang sihat memainkan peranan yang penting.
Dengan mengurut dengan Jet Pengurut,ia akan
menjaga gusi anda supaya sihat.
Penjagaan gigi yang sempurna adalah penting.
Hanya dengan memberus tidak akan
mengeluarkan semua partikel makanan.Ini akan
menyebabkan karies.Dengan menggunakan Jet
Pengurut,anda akan dapat menanggalkan kesemua
partikel makanan.Walaupun tempat-tempat yang
BAHASA MELAYU10
