Philips SONICARE elite e7000 Manuale utente

elite®

e7000

the sonic toothbrush

series

ENGLISH 4

FRANÇAIS 17

ESPAÑOL 31

SONICARE ELITE 7000

Table of contents

General description 4

Important safeguards 4

Dangers 4-5

Warnings 5

Medical warnings 5

Customer Service Information 6

Preparing for use 6

Charging your Sonicare 7

Using the appliance 7-8

Features 9-12

Cleaning 12-13

Storage 13

Replacement 13

Battery recycling 14-15

Guarantee & service 15-16

Troubleshooting 16

General description

ATravel cap

BBristles

CBrush head

DColor code ring

ERemovable nut

FHandle with soft grip

GPower on/off button

HDual Speed Control button

ILED charging lights

JCharger

IMPORTANT SAFEGUARDS

READ ALL INSTRUCTIONS BEFORE USE

Sonicare\has been carefully engineered for both effectiveness and

safety. However, basic safety precautions should always be followed

when using any electrical product, especially when children are present.

DANGERS

To reduce the risk of electrocution and fire:

1) DO NOT plug the charger into an incorrect voltage source outlet. It

has been designed for use with a specific electrical voltage. Refer to

the bottom (or back) of the charger for the correct voltage

specification.Voltage converters and plug adapters DO NOT

guarantee voltage compatibility. Never force the plug into an outlet.

2) DO NOT place or store the charger where it can fall or be pulled

into a tub, sink or toilet.

ENGLISH4

3) DO NOT place or drop the charger into water or other liquid.

4) DO NOT reach for a charger that has fallen into water. Unplug

immediately.

5) DO NOT use while taking a bath.

WARNINGS

To reduce the risk of burns, electrocution, fire or injury:

1) Close supervision is necessary when this product is used by or on

children or the disabled.

2) If you are unable to handle this product properly, discontinue use.

3) Use this product only for its intended use as described in this

booklet. Do not use attachments other than those recommended

by the manufacturer. See voltage information above.

4) Never operate the charger if it has a damaged cord or plug, if it has

been dropped or if the toothbrush handle has been damaged in any

way.This product contains no serviceable parts. If repair is needed

please refer to the Customer Service Information section of this

manual and contact one of our representatives.

5) Keep the cord away from heated surfaces.

6) If your favorite toothpaste includes peroxide, baking soda or other

bicarbonate (common in whitening toothpastes), it is important that

you thoroughly clean your brush head with soap and water after

each use.

7) Do not use charger base outdoors.

8) Unplug the charger base before cleaning and assure that it is dry

before plugging it into an electrical outlet.

9) Brush heads and charger base should never be placed in a

dishwasher for cleaning.

MEDICAL WARNINGS

1) Consult your dental professional before using this product if you

have had oral or gum surgery in the previous 2 months.

2) Contact your dental professional if excessive bleeding occurs after

using this product or bleeding continues to occur after 1 week of

use.

3) If you have any questions concerning usage with a pacemaker or

other implanted device, consult your physician or the implanted

device manufacturer prior to use. Sonicare has been tested and is

compliant with safety standards for electromagnetic devices.

4) Avoid using a brush head with crushed or bent bristles. Damaged

bristles may break off while brushing. In order to prevent this,

replace the brush head with a new one every 6 months or sooner if

signs of wear appear.

5)The Sonicare toothbrush is a personal care device and is not

intended for use on multiple patients in a dental office or institution.

6)This product is designed for cleaning teeth, gums and tongue only.

Do not use for any other purpose.

ENGLISH 5

Customer Service Information

If you have any questions after reading this manual, feel free to contact

our Customer Service Center or visit our website.

◗Customer Service Center

1-800-682-7664 (North America), outside North America contact

your local Philips Customer Care Center.

◗Internet Information

www.sonicare.com (North America) www.philips.com (outside North

America)

SAVE THESE INSTRUCTIONS

Preparing for use

To attach the Sonicare brush head:

C1Align the front of the brush head with the front of the

toothbrush handle. Match the bars on the brush head with the

notches inside the top of the handle and slide the brush head

onto the handle.

C2Screw the brush head nut clockwise until it is firmly tightened.

If the brush head rattles during use, tighten the nut further.

3Remove the travel cap from your brush head when you are

ready to brush.

C4Use the cord wrap in the bottom of the charger to store

excess cord.

ENGLISH6

Charging your Sonicare\

Sonicare comes with the batteries completely discharged and should

be charged for at least 24 hours during the first few days of use.

◗It is recommended that you keep your Sonicare in the charger

when not in use to maintain a full battery charge. It takes at least

24 hours to fully charge Sonicare's battery.

C1Be sure the bottom of the handle sits back securely in the

charger, making complete contact.

◗Handles of other Sonicare models do not fit in this charger and

will therefore not charge effectively. Do not attempt to force a

handle into this charger as this will cause damage.

Using the appliance

Useful tips

◗The brush head comes with a convenient travel cap. Remove the

travel cap from the brush head before turning on your Sonicare.

◗Place the brush head in your mouth before turning on your

Sonicare, and be sure it is turned off before removing it from your

mouth, otherwise toothpaste may splatter.

◗Rinse the brush head and bristles after each use.

◗Clean the brush head weekly, including under the nut.

◗A fully charged Sonicare will provide approximately 2 weeks of

typical use (2 minutes of brushing twice a day), making it easy to

travel without the charger.

Remember: voltage converters and plug adapters DO NOT guarantee

voltage compatibility. Always check for voltage compatibility.

Brushing technique

Follow these simple steps to maximize your brushing experience:

C1Before turning the Sonicare on, place the bristles of the brush

head on your gumline at a 45-degree angle.

2Hold the handle with a light grip, turn the Sonicare on, and

gently move the bristles in a small circular motion so the

longer bristles reach between your teeth.After a few seconds

glide the bristles to the next secion. Continue this routine

throughout your 2-minute brushing cycle.

3To maximize Sonicare's effectiveness apply only light pressure

and let the Sonicare toothbrush do the brushing for you.

Do not scrub.

ENGLISH 7

C4To make sure you brush evenly throughout the mouth, divide

your mouth into 4 sections: outside top, inside top, outside

bottom and inside bottom teeth. Begin brushing in section 1

(outside top teeth) and brush for 30 seconds before moving to

section 2 (inside top teeth). Continue brushing for 30 seconds

in each section progressing through all 4 sections until you've

brushed for 2 minutes.

5After having completed the 2-minute brushing cycle, additional

time should be spent brushing the chewing surfaces of your

teeth.

6Press the power button to turn the brush on and off as

needed.

◗You may also brush your tongue, with the toothbrush turned on

or off, as you prefer.

Tips for specific oral care needs

◗Stain removal

In areas where staining occurs, spend extra brushing time to assist with

stain removal.

C◗Braces

The brush should be placed at a 45-degree angle between your

brackets and gumline. Using light pressure, gently move the bristles in a

small circular motion so that the long bristles reach between your

teeth for 2 seconds.Then gently turn (roll) the brush handle so the

bristles clean the bracket and the rest of the tooth before you move

the bristles to the next tooth. Continue this until you have brushed all

of your teeth. Please note that brush heads will wear out sooner when

used on braces.

◗Dental restorations (dental work)

Use Sonicare on dental restorations (such as implants, caps, crowns,

bridges and fillings) as you would on your normal tooth surfaces to

reduce plaque build-up and improve gum health.Work the bristles

around all areas of the restoration for thorough cleaning.

◗Periodontal pockets

Your dental professional may have indicated that you have periodontal

pockets, deep pockets where plaque bacteria collect. If this is the case,

after brushing for a full 2 minutes, spend extra time gently brushing

these areas to improve your gum health.

ENGLISH8

Features

Easy-start\brushing power ramp-up

◗All Sonicare models come with the Easy-start feature activated,

which helps you get used to brushing with Sonicare.

◗Brushing power will gently increase to full power over the first

14 brushings.

◗The Easy-start feature is active if you hear 2 beeps immediately

after turning on your Sonicare. Once the appliance has reached

optimal brushing power (after the 14th brushing), you will no

longer hear the double beep at the beginning of your brushing

routine.

BNote: Each of the first 14 brushings must be at least 1 minute in length

to properly advance through the Easy-start ramp-up cycle.

To deactivate or activate the Easy-start feature:

1Attach your brush head to the handle.

2Place the handle in the plugged-in charger.

3To deactivate Easy-start feature: while handle is still in the

charger, press and hold the power button for 5 seconds.You

will hear 1 beep to indicate that the Easy-start feature has

been deactivated.

4To reactivate Easy-start: while handle is still in the charger,

press and hold the power button for 5 seconds.You will hear 2

beeps to indicate that the Easy-start feature has been activated.

Using the Easy-start feature beyond the initial ramp-up period is not

recommended and reduces Sonicare's effectiveness in removing

plaque.

The Easy-start feature should be deactivated when Sonicare is used in

clinical trials.

Smartimer\2-minute timer

◗All Sonicare models come with the Smartimer feature, which

automatically sets the brushing time to the 2 minutes

recommended by dental professionals.

◗After 2 minutes, your Sonicare will automatically turn off the

toothbrush.

◗If you wish to pause or stop brushing during your 2-minute cycle,

press the power button. Press the power button again and the

Smartimer will pick up where you left off.

ENGLISH 9

BThe Smartimer will automatically reset to the beginning of a 2-minute

cycle if:

- brushing is paused for 30 seconds or longer;

- the handle is returned to the charger.

Quadpacer\30-second interval timer

C◗Quadpacer makes sure that you brush all sections of your mouth

evenly and thoroughly.When using a two-minute brushing cycle,

you will hear a short beep and a pause in brushing action at 30, 60

and 90 second intervals.

Programmable Quadpacer timer (select models only)

The Programmable Quadpacer timer offers you the option of

customizing the Quadpacer performance in 1 of 3 ways:

◗You may opt to keep the factory default setting of a 2-minute

brushing time with Quadpacer feature activated.

◗You may choose to extend your brushing time to 2 1/2 minutes

by adding an additional timing interval of 30 seconds with

Quadpacer feature active.

◗You may choose a 2-minute brushing time, but with the

Quadpacer feature turned off.

To change the Quadpacer settings:

1Place the handle in the charger that is plugged into a live

electrical outlet.

C2Press the Dual Speed Control button briefly and note which

LED lights up.

3Press and hold the Dual Speed Control button. Continue to

hold the button while the LEDs slowly cycle through the timing

interval setting options:

C◗Green LED in position 4: Quadpacer active (factory default

setting).

ENGLISH10

Altri manuali per SONICARE elite e7000

Questo manuale è adatto per i seguenti modelli

Indice

Lingue:

Altri manuali Philips Spazzolino elettrico

Philips

Philips Sonicar AirFloss Ultra HX8331/11 Manuale utente

Philips

Philips Sonicare 2 Series Manuale utente

Philips

Philips Elite+ sonicare HX3285/06 Manuale utente

Philips

Philips HX6581 Manuale utente

Philips

Philips HX6582/51 Manuale utente

Philips

Philips Sonicare Airfloss HX8181 Manuale utente

Philips

Philips Sonicare DiamondClean 300 SERIES Manuale utente

Philips

Philips sonicare 9900 Prestige Manuale utente

Philips

Philips Sonicare ProtectiveClean HX6803 Manuale utente

Philips

Philips sonicare ProtectClean HX6839/66 Manuale utente

Philips

Philips Sonicare DiamondClean Manuale di istruzioni

Philips

Philips Sonicare DiamondClean HX9337 Manuale utente

Philips

Philips Sonicare DailyClean 3100 Guida all'installazione

Philips

Philips Sonicare FlexCare+ HX6972/10 Manuale utente

Philips

Philips Sonicare HX6218/10 Manuale utente

Philips

Philips HX6733/90 Manuale utente

Philips

Philips Sonicare FlexCare HX6971/59 Manuale utente

Philips

Philips Sonicare DiamondClean 300 SERIES Manuale utente

Philips

Philips Sonicare DiamondClean 9000 Manuale utente

Philips

Philips HP555/12 Manuale utente

Philips

Philips AirFloss HX8254 Manuale utente

Philips

Philips DiamondClean 300 series Manuale utente

Philips

Philips Sonicare FlexCare Platinum Manuale utente

Philips

Philips Sonicare CleanCare+ HX3214/02 Manuale utente

Manuali Spazzolino elettrico popolari di altre marche

Omron

Omron Colgate ProClinical C600 Manuale utente

Dentle

Dentle One Plus Manuale utente

SPORT ELEC

SPORT ELEC Smilyss HC5305C Manuale utente

Kompernass

Kompernass dentalux DAZ 2.4 A1 Manuale utente

ONE

ONE PERSONAL OSEB001-W Manuale utente

Panasonic

Panasonic EW118WC Operating Manuale utente

Jula

Jula 804-193 Manuale utente

Panasonic

Panasonic EW-PDA52 Manuale utente

Braun

Braun OC17525 Manuale utente

Panasonic

Panasonic ER-CBL1 Manuale utente

Waterpik

Waterpik Sensonic Professional Plus SR-3000 Manuale utente

TrueLife

TrueLife SonicBrush T100 Manuale utente

Braun

Braun Oral-B 450 Manuale utente

Braun

Braun Oral-B Professional Care 7000 Manuale utente

Panasonic

Panasonic EW1012 Manuale utente

Waterpik Technologies

Waterpik Technologies WP-900 Manuale utente

Waterpik

Waterpik ST-01 Manuale utente

Kooper

Kooper Sonic Pulse 2192267 Manuale utente
