Philips BVP500 Guida utente

443000016379_B

09/2015

Data subject to change

Printed in Spain

www.philips.com/lighting

Optivision LED Floodlight BVP500

Mounting instruction

Instructions de montage

Instrucciones de montaje

Kokoonpano- ja kiinnitysohjeet

Szerelési utasítások

Montageanleitung

Instrucões de montagem

Montaj yönergesi

Návod k montáži

Montage instruktie

Monteringsinstruktioner

Oδηγίες συναρμολόγησης

Монтажная инструкция

Istruzioni di montaggio

Monteringsvejledning

Instrukcja montazu

LUMEN

BVP500

40000h

93K/757

93000

1012

4,4(*)

15ºC

-30ºC

●

BVP500

40000h

90K/757

90000

954

4,2(*)

25ºC

BVP500

40000h

82K/757

82000

841

3,7(*)

35ºC

BVP500

40000h

67K/757

67000

607

2,7(*)

BVP500

40000h

72K/757

72000

688

3,0(*)

45ºC

BVP500

40000h

47K/757

47000

374

1,7(*)

35ºC

BVP500

40000h

81K/740

81000

1014

4,5(*)

15ºC

BVP500

40000h

79K/740

79000

954

4,2(*)

25ºC

BVP500

40000h

71K/740

71000

836

3,7(*)

35ºC

BVP500

40000h

58K/740

58000

607

2,7(*)

BVP500

40000h

62K/740

62000

683

3,0(*)

45ºC

BVP500

40000h

41K/740

41000

374

1,7(*)

35ºC

BVP500

20000h

93K/757

93000

1012

4,4(*)

25ºC

BVP500

20000h

90K/757

90000

954

4,2(*)

35ºC

BVP500

20000h

80K/757

80000

803

3,5(*)

45ºC

BVP500

20000h

65K/757

65000

601

2,7(*)

35ºC

BVP500

20000h

59K/757

59000

529

2,3(*)

45ºC

BVP500

20000h

81K/740

81000

1014

4,5(*)

25ºC

BVP500

20000h

79K/740

79000

954

4,2(*)

35ºC

BVP500

20000h

69K/740

69000

798

3,5(*)

45ºC

BVP500

20000h

57K/740

57000

601

2,7(*)

35ºC

BVP500

20000h

52K/740

52000

529

2,3(*)

45ºC

BVP500

10000h

75K/757

75000

726

3,2(*)

35ºC

BVP500

10000h

72K/757

72000

681

3,0(*)

45ºC

BVP500

10000h

65K/740

65000

721

3,2(*)

35ºC

BVP500

10000h

63K/740

63000

676

3,0(*)

45ºC

347-480V

50-60hZ

110-277V

50-60hZ

INRUSH CURRENT

30 A/Kw at 200µs

(*)

.- Measured current for 230V mains.

Max. 34 Kg 1,25 m RG2 0,19/15º 0,30/40º 0,32/65º

Risk Group 2: - CAUTION Retinal Blue Light: Do not look into operating lamp, may be harmful to the eyes

LIFE

L80B10

443000016379_B

09/2015

Data subject to change

Printed in Spain

www.philips.com/lighting

DIMENSION: 707x615x446 mm

WEIGHT : 34 Kg

707

TOP

BOTTOM

TOP

BOTTOM

443000016379_B

09/2015

Data subject to change

Printed in Spain

www.philips.com/lighting

- M16 with extra large washer (not provided)

- M12 with extra large washer (not provided)

±40 mm

(x2)

50 Nm

17 Nm

(x1)

50 Nm

Higher >3m

Use 2nd fixing security

(x2)

50 Nm

443000016379_B

09/2015

Data subject to change

Printed in Spain

www.philips.com/lighting

MAINTENANCE

x2 17 Nm

LIGHT-MODULE LABEL

Mark the

position

before

untightening

Rotate back to

the marked

position before

tightening

12 NC: 91XXXXXXXXXX

I: 0,8-2,0 A

Tc: 90ºC

OPTIC TYPE

S2 TO S8

OPTIC TYPE

NB/MB/WB/VWB

Connect the

cable module to

connection box

Disconnect

from connection

box

2,5 Nm

443000016379_B

09/2015

Data subject to change

Printed in Spain

www.philips.com/lighting

ACCESSORIES

External spill-light control louvre ZVP500 L or zero candela louvre ZVP500 L-A90

Precision aiming device ZVP520 PAD A30 or ZVP420 PAD A0

50 Nm

x8 screws: 4x10 mm

2,5 Nm

ZVP420 PAD A0

12NC: 912300022989 (ZVP500 L)

ZVP520 PAD A30

12NC: 912300022990 (ZVP500 L-A90)

443000016379_B

09/2015

Data subject to change

Printed in Spain

www.philips.com/lighting

POWER LINE

Ø13-18 mm

4 mm2 max.

347-480

VAC

x6 screws: 4x16 mm

110-277

VAC

Screw retainer

x6 screws

The screws have to be remove

sequentially to avoid losing them

443000016379_B

09/2015

Data subject to change

Printed in Spain

www.philips.com/lighting

DALI

CONTROL LINE

Ø4-9 mm

2-4 mm2

443000016379_B

09/2015

Data subject to change

Printed in Spain

www.philips.com/lighting

D min (mm)

D max (mm)

TORQUE Nm

M12 3 6,5 1,6

M25 13 18 5

M12

M25

x6 screws: 4x16 mm

2,5 Nm

M121,6 Nm

M255,0 Nm

Ensure the tightening of the

cableglands for protection against

ingress of dust and moisture (IP66)

443000016379_B

09/2015

Data subject to change

Printed in Spain

www.philips.com/lighting

BASIC VERSION Controls disabled

FUSE REPLACEMENT

WARRANTY VOID IF REMOVED

The system can be made upgradable by

the qualified and authorized Philips

technical only!

10X38

10 A

500V gG

In=120KA

443000016379_B

09/2015

Data subject to change

Printed in Spain

www.philips.com/lighting
