Philips MCB395 Manuale utente

MCB395

Quick Start Guide

What’s in the Box?

You should find these items upon opening the box.

Quick Start Guide

User Manual

Quick start guide User manual Remote control with

1 x CR2025 battery

Pull out the plastic

protective sheet

before use.

MCB395 QSG_05-Eng 2008.4.25, 10:031

Connect the speaker cables.

Connect the power plug to AC power socket.

Tip

See the User Manual for how to connect other equipment

to this system.

AC power cord

Speaker

(left)

Speaker

(right)

DAB/FM T-type antenna

MCB395 QSG_05-Eng 2008.4.25, 10:032

Setting the clock

In the standby mode, press and hold CLOCK on the remote control.

➜The clock digits for the hours continue to flash.

Adjust VOLUME -/+ (or press VOL +/- on the remote control) to set the hours.

Press CLOCK to confirm.

➜The minute digits start flashing.

Adjust VOLUME -/+ (or press VOL +/- on the remote control) to set the minutes.

Press CLOCK to confirm the time.

Playing a USB mass storage device

With the Hi-Fi system, you can use USB flash memory (USB 2.0 or USB1.1),

USB flash players (USB 2.0 or USB1.1), memory cards (requires an additional card reader to

work with this Hi-Fi system).

Insert the USB device’s USB plug into the socket on the set.

Press SOURCE once or more (or USB on the remote control) to select USB.

Play the USB’s audio files as you do with the albums/tracks on a CD.

Enjoy

Playing a disc

Press OPEN/CLOSEçto open the disc tray and load in a disc, then press the same

button again to close the disc tray.

➜Make sure the label side of the disc is facing up.

Press ÉÅ to start playback.

To stop playback, press 9.

Notes for remote control:

– First select the source you wish to control by pressing one of the source select

keys on the remote control (for example FM, DISC).

–Then select the desired function (for example

,S ,

T).

IMPORTANT!

– To set clock in the Eco Power mode, press and hold ECO POWER/STANDBY-ON

on the set for 3

seconds or more to switch to normal standby mode first before proceeding with the procedures below.

iPod playback via the USB

port cannot be guaranteed.

MCB395 QSG_05-Eng 2008.5.23, 13:353

PDCC-JS_JW-0716

Enjoy

Printed in China

Programming and tuning to FM radio

stations

Press SOURCE repeatedly (or FM on the remote control) to select the

tuner source.

Press PROG on the remote control) for more than two seconds to

program all available stations in order of waveband.

Press ALBUM/PRESET 4or 3(or ¡ / ™on the remote control) until

the desired preset station is displayed.

Tuning to DAB stations

Press SOURCE on the system to select DAB (or press DAB on the remote control) to start

automatic search for available DAB stations.

Press SCAN to search for all band III frequencies.

At the completion of full scan, press ALBUM/PRESET 4or 3 (or ¡ / ™ on the remote

control) to select your desired DAB channels backward/forward.

Press ENTER/ÉÅ to confirm and tune to your selected channel.

Tip

–See the User Manuals for detailed instructions on DAB

operations.

MCB395 QSG_05-Eng 2008.4.25, 10:034
