Philips MCD190/55 Manuale utente

MCD 190

Quick Start Guide

What’s in the Box?

You should find these items upon opening the box.

User Manual

Quick Start Guide

CompositeVideo Cable MW antenna Remote Control

Quick Start Guide

User Manual

MCD190 QUG_Eng-21 2005.7.27, 10:481

speaker

(right)

speaker

(left)

AC power cord

FM wire

antenna MW loop

antenna

Connect the speaker wires to the SPEAKERS terminals, right speaker to "RIGHT" and left speaker to

"LEFT", coloured (marked) wire to "+" and black (unmarked) wire to "–".

For radio reception, connect the supplied MW antenna to the "MW AERIAL" terminal.

Use the composite video cable (yellow) to connect the system's VIDEO jack to the video input jack (or labeled

as A/V In,Video In, Composite or Baseband) on the TV set.

Connect the power cord of the DVD system to the AC power outlet.

Tip

See the User Manual for otherTV connection options.

Tip

It is unnecessary to connect the FM pigtail antenna since it

is fixed to the main unit.

MCD190 QUG_Eng-21 2005.7.27, 10:482

Setting up the TV

Press STANDBY ONBon the front panel of the DVD player or B on the remote to switch the DVD system

on and then select the disc source.

Switch on the TV set and set to the correct video-in channel until the blue Philips DVD background screen

appears on the TV.

Tip

See your TV manual for more details.

Setting up the TV Type and Language Preferences

In the stop mode or during playback, press SYSTEM MENU on the remote to

enter the system menu.

Press 22/33 on the remote to enter 'SYSTEM SETUP'.Then, select the color

system matching your TV and the TV type using 22/33/3/4on the remote.

Press 22/33 on the remote to enter 'LANGUAGE SETUP' and select the

preferred OSD language, audio language, subtitle language and menu language using

22/33/3/4 on the remote.

MCD190 QUG_Eng-21 2005.7.27, 10:483

Loading a disc

Select the disc source, then press OPEN•CLOSE3at the top of the DVD player.

Load in a DVD disc with the label side facing up.

A disc menu pops up.

Playback

Use 22/33/3/4and OK or Numeric Keypad (0-9) on the remote to select a playback feature or item.

➜Playback will start automatically.

Press STOP9to stop playback.

Types of Discs used on this DVD System

Tip

Refer to the user manual for playback of other types of discs.

Type

DVD VIDEO

AUDIO CD

VIDEO CD

MP3-CD

Record Playback Edit

DVD+RW

Super VCD

VIDEO CD

2005 © Koninklijie Philips Electronics N.V.

www.philips.com

MCD190 QUG_Eng-21 2005.7.27, 10:484
