MCD759D

Quick Start Guide

What’s in the Box?

You should find these items upon opening the box.

1X Docking cradle

8 X iPod dock adaptors

Composite video and audio

cables

(yellow, white, red)

Remote control with two

AAA batteries

Control Cable

FM and AM antennas

DIN Cable

User Manual

Quick Start Guide

Quick start guide

User manual

MCD759D QSG_37-Eng 2007.6.22, 9:251

Tips

–See the User Manual for other TV

connection options.

– See the related part in the User

Manual if you want to mount the

speakers on the wall.

–For connecting to a Progressive Scan

TV, refer to the user manual for proper

connections and detailed setup.

Connect the speaker cables.

Connect the AM and FM antennas.

Connect the control cable.

Connect the composite video and audio cables to a TV.

Connect the iPod dock.

Connect the power cords of the system andTV.

Front Speaker

(Left)

Center

Speaker

Rear Speaker

(Right)

Rear Speaker

(Left)

Front Speaker

(Right)

Subwoofer

AC power

AM antenna

FM antenna 2

iPod dock

Setting up the TV

Press SOURCE (DISC on the remote) to select disc source.

Turn on the TV and set it to the correctVideo In channel.

MCD759D QSG_37-Eng 2007.6.22, 9:252

Setting the clock

In standby mode, press and hold CLOCK/RDS on the remote.

When the hour digits flash, turn VOLUME-/+ on the system or press VOL +/- on the

remote to set the hours.

Press CLOCK/RDS again and the minute digits flash.Then turn VOLUME-/+ on the

system or press VOL +/- on the remote to set the minutes.

Press CLOCK/RDS again to confirm the time setting.

Setting DVD menu options

IMPORTANT!

If the progressive scan feature is activated but the connected TV does not support progressive

signals or the cables are not connected accordingly, see the user manual for proper progressive

scan setup or deactivate the progressive scan feature as below:

1) Turn off your TV progressive scan mode or turn on to interlaced mode.

2) Press SYSTEM MENU on the remote to exit the system menu and then DISC and “1” to exit

progressive scan.

Tip

See chapters "Preparations" and "DVD Menu Options" in the User Manual for detailed descriptions.

CLOSED CAPTIONS

Press OPEN •CLOSEç(çon the remote) to open the disc tray and load in a disc,

then press the same button again to close the disc tray.

➜Make sure the label side of the disc is facing up.

Playback will start automatically. If not pressÉÅ.

To stop playback, press PRESET-/9(9on the remote).

Playing a disc

OPEN•CLOSE

MCD759D QSG_37-Eng 2007.6.22, 9:253

Programming and tuning to radio stations

Press SOURCE (TUNER on the remote) to select tuner source.

Press PROGRAM on the remote control for more than two seconds to program all

available stations in order of waveband.

Press PRESET+/- (¡/ ™on the remote control) until the desired preset station is

displayed.

PDCC-JS/JW-0727

Playing Apple iPod using MCD759D

Select the correct dock adaptor, as indicated on each adaptor, then fit it in

the dock.

Correctly place the compatible iPod player into the dock.

Before selecting the iPod source, switch on your iPod player and set:

1) "TV Out" to "On";

2) "TV Signal" to "NTSC";

3) "Widescreen" to "Off". (See your iPod user’s manual for details.)

Press SOURCE on the system repeatedly or iPod on the remote control

to select the iPod source.

Select and play your favourite audio or video files stored in the iPod player.

Tip

Detailed playback features and

additional functions are described

in the accompany owner's

manual.

Notes for remote control:

–First, select the source you wish to

control by pressing one of the source

select keys on the remote control (DISC or

TUNER, for example).

–Then select the desired function (

for example).

iPod

Music

Photos

Videos

Extras

Settings

Shuffle Songs

Videos

Video Playlists

Movies

Music Videos

Video Podcasts

Video Settings

Settings

TV Out On

TV Signal NTSC

Widescreen Off

Notes:

– HDMI sound/picture output will

be unavailable for the docked iPod

portable player.

– The supported iPod video output

formats are as follows:

(1) H.264 video, 640 by 480

pixels, 30 frames per second;

(2) H.264 video, 320 by 240

pixels, 30 frames per second;

(3) MPEG-4 video, 640 by 480

pixels, 30 frames per second.

– The output picture on the TV

screen may be blurry if the format

of video files in the docked iPod

portable player is 320 by 240

pixels.

MCD759D QSG_37-Eng 2007.6.22, 9:254
