Philips SJA9190/17 Manuale utente
1
SJA9190/17
EN User manual 2
SP Manual de utilizador 16
3 Safety Instructions
6 Introduction
7 Installation
8 Operation
10 Troubleshooting and FAQs
11 FCC Information
14 Warranty
15 Technical Support
2
EN Contents
Safety Instructions
When using your telephone equipment, basic
safety precautions should always be followed to
reduce the risk of fire, electric shock and injury
to persons, including the following:
1. Read and understand all instructions.
2. Follow all warnings and instructions marked
on the product.
3. Unplug this product from the wall outlet
before cleaning. Do not use liquid cleaners
or aerosol cleaners; use a damp cloth for
cleaning.
4. Do not use this product near water for
example, near a bath tub, wash bowl,
kitchen sink, or swimming pool, or in a wet
basement.
5. Do not place this product on an unstable
cart, stand or table, as the product may fall,
causing serious damage to the product.
6. Slots and openings in the cabinet and the
back or bottom of this product are provid-
ed for ventilation (to protect it from over-
heating) and should not be blocked or cov-
ered. The openings should never be
blocked by placing this product on a bed,
sofa, rug or other similar surface. This
product should never be placed near or
over a radiator or heat register. This prod-
3
EN
Safety Instructions
uct should never be placed in a built-in
installation unless proper ventilation is pro-
vided.
7. This product should be operated only from
the type of power source indicated on the
marking label. If you are not sure of the
type of power supply to your home, consult
your dealer or local power company.
8. Do not allow anything to rest on the power
cord. Do not place this product where the
cord will be abused by people walking on it.
9. Do not overload wall outlets and extension
cords, as this can result in the risk of fire or
electric shock.
10.Never push objects of any kind into this
product through cabinet slots, as they may
touch dangerous voltage points or short out
parts, resulting in the risk of fire or electric
shock. Never spill liquid of any kind on the
product.
11.To reduce the risk of electric shock, do not
disassemble this product, but take it to a
qualified serviceman, when service or repair
work is required. Opening or removing
covers may expose you to dangerous volt-
age or other risks. Incorrect reassembly
can cause electric shock when this product
is subsequently used.
4
EN Safety Instructions
12.Unplug this product from the wall outlet
and refer servicing to a qualified service per-
sonnel under the following conditions: a)
when the power supply cord or plug is dam-
aged or frayed; b) if liquid has spilled into the
product; c) if the product has been exposed
to rain or water; d) if the product does not
operate normally when you follow the
operating instructions (adjust only those
controls that are discussed in the operating
instructions, as improper adjustment of
other controls may result in damage, often
requiring extensive work by a qualified tech-
nician to restore the product to normal per-
formance); e) if the product has been
dropped or the cabinet has been damaged;
f) if the product exhibits a distinct change in
performance.
13.Avoid using a telephone (other than a cord-
less type) during an electrical storm. There
may be a remote risk of electric shock from
lightning.
14.Do not use the telephone to report a gas
leak in the vicinity of the leak.
Save these instructions.
5
EN
Safety Instructions
Introduction
The SJA9190 lets you know who’s calling by
announcing the Caller’s telephone number
when the phone rings, without interrupting
what you’re doing. If the Caller’s telephone
number is not available, the unit will announce
“Number Unknown.” If the Caller has blocked
their telephone number, the unit will announce
“Number Blocked.”
Check the Package Contents
Check the package contents to make sure you
have the following items: talking Caller ID unit
and telephone line cord.
Care and handling of your batteries
Please read these instructions before installing
batteries.
Make sure to insert the batteries properly, fol-
lowing the symbols showing you the correct
way to position the positive (+) and negative (-)
ends of the batteries.
Replace batteries with the size and type speci-
fied by the device’s manufacturer. Remove all
used batteries from the device at the same
time, then replace them with new batteries of
6
EN Introduction
the same size and type.
Don’t dispose of batteries in a fire—they may
rupture or leak.
Don’t mix old and new batteries, or mix differ-
ent types or makes of batteries. This can cause
rupture or leakage, resulting in personal injury
or property damage.
Don’t give batteries to young children.
Installation
Set up the product by installing three (3)
“AAA” batteries inside the battery compart-
ment on the underside of the unit. The unit will
also work with a compatible AC Adapter
(7.5VDC output with negative pin polarity.)
Plug one end of the telephone cord into the
telephone jack on the wall, and the other end
into either of the telephone jacks on the back
of the unit.
An extra telephone jack is provided on the
back of the unit for connecting a telephone or
7
EN
Introduction
Installation
other device at your option.
Screening telephone calls while you’re
at home
The talking Caller ID works with standard
(number-only) and deluxe (name and number)
Caller ID service available from your local tele-
phone company.
The unit identifies calls by announcing the
Caller’s ten-digit telephone number between
the first and second ring. If the call is coming
from a number that has been blocked, it will
announce “Number Blocked.” If the telephone
number is unidentified, the unit will announce
“Number Unknown.”
If the phone is still ringing, and you didn’t hear
the number being announced, just press the big
key and it will repeat the number.
Audibly Reviewing Calls
The unit stores the last ten calls in memory for
audible review. This is convenient for finding
out who called while you were out. There are
two ways to perform audible call review:
1. Press the big key to hear the date, time, and
telephone number of the most recent call in
the log. Subsequent pressing and releasing
this key will go further back into the call log
and announce information about earlier
8
EN Operation
calls. Pressing the big key while an
announcement is in process pre-empts the
current announcement and goes to the next
call. After the final call is announced, the
unit beeps. Continued pressing will start
back at the top of the log again.
2. Hold down the big key for 2-seconds, and it
will announce the number of new calls fol-
lowed by the date, time, and telephone
number of every new call in the log. After
the final call is announced, the unit beeps.
Language Selection
The unit speaks in English and Spanish. To
change the selected language, hold down the
small key and momentarily press and release
the big key. The unit announces “January” in
the selected language.
Erasing Calls
To erase the calls in the audible call log, hold
down the big key for 4-seconds. The unit
beeps confirming the calls have been erased.
Volume Control
There are four volume settings - low, medium,
high, and off. To change the volume, press and
release the small key very quickly. You may
find it helpful to press the key using the eraser-
9
EN
Operation
end of a pencil. The key is designed so that it
is difficult to change the setting by accident. The
unit beeps reflecting the new volume setting. It
beeps twice to indicate the volume is turned
OFF.
If the volume is set to OFF, incoming calls will
not be announced. Calls reviewed while the
volume is OFF will be announced at medium
volume level.
Troubleshooting & FAQs
Having problems? Before contacting PHILIPS
or your dealer, check the following list of sug-
gestions. You might be able to solve the prob-
lem yourself.
Question:
My unit does not announce anything when the
phone rings.
Answers:
Make sure the volume is turned up. To turn up
the volume, press the volume control button
(small button) with your finger or a pencil eras-
er until you hear the unit “beep” at the desired
volume level. If you hear the unit beep twice,
then the volume is off.
10
EN Operation
Troubleshooting & FAQ
