Designed for the VL1000™ ERS

7002Y

Maximum ﬂexibility in theaters

Provides all the light that’s needed – wherever and whenever.

Specially suited to moving head systems

that allow maximum freedom of light delivery.

Tested and approved by Vari*Lite

114243_LL_7002Y.qxd 07-06-2005 10:17 AM Page 1

12NC 3222 635 48561 P - 5643a Printed in the Netherlands 07/04. Data subject to change.

APPLICATION: THEATER LIGHTING • TV / STUDIO LIGHTING • EVENT LIGHTING

Features Beneﬁts

Type A w x h

max.

7002Y 100 V 22.0 11.5 x 11.5

7002Y 115 V 22.0 11.5 x 10.5

7002Y 230 V 22.0 10.5 x 14.0

7002Y 240 V 22.0 11.5 x 13.5

Type Lamp Lamp Cap/ Finish Filament Lumen Burning Average Maximum permissible Color Ordering

voltage wattage base shape output position lamp life 50% pinch temp. temperature number

VW lm h °C K

7002Y 100 1000 G22 CLEAR Biplane 29000 UNIV. 250 500 3200 9245 536 30900

7002Y 115 1000 G22 CLEAR Biplane 29000 UNIV. 250 500 3200 9245 536 34400

7002Y 230 1000 G22 CLEAR Biplane 29000 UNIV. 250 500 3200 9245 536 44200

7002Y 240 1000 G22 CLEAR Biplane 29000 UNIV. 250 500 3200 9245 536 45500

7002Y

P3 technology ensures outstanding performance in extreme heat conditions Longer lifetime, fewer early failures

Shock resistant design Ideal for moving head systems

Ultimate performance when used with Vari*Lite VL1000™ ERS High quality bright light

7002Y 7002Y

140 max.

72.5

∅A

w x h

VL1000™ ERS

Dimensions in mm

PHILIPS PINCH PROTECTION TECHNOLOGY

•Reliability, through longer lifetime and fewer

early failures.

•Quality, through excellent storage characteristics

and consistent performance over time.

•Compactness, allowing more compact design of

ﬁxtures and burning positions.

★Philips P3 technology ★

Max 500º C pinch temperature

•Competitive technology

Max 450º C pinch temperature

•No pinch protection

Max 350º C pinch temperature

114243_LL_7002Y.qxd 07-06-2005 10:17 AM Page 2

Philips Lighting Company

200 Franklin Square Drive

P.O. Box 6800

Somerset, NJ 08875-6800

1-800-555-0050

A Division of Philips Electronics

North America Corporation

Philips Lighting

281 Hilmount Road

Markham, Ontario

Canada, L6C 2S3

1-800-555-0050

A Division of Philips Electronics Ltd.

P-5643-A

You can ﬁnd more info at our website

www.broadway.philips.com
