Philips Lytespan 8202WH Manuale utente

631 Airport Road, Fall River, MA 02720 • (508) 679-8131 • Fax (508) 674-4710

We reserve the right to change details of design, materials and finish.

Job Information Type:

Job Name:

Cat. No.:

Lamp(s):

Notes:

Lytespan Track Lighting System 8202WH

Page 1 of 2 PAR-Tech Hinged

1 15/16"

6 3/16"

5 3/4"

Features

1. Lytespan Attachment Fitting: Molded polycarbonate. Integral color. Fitter

twists into track and locks on.

2. Movable Brass Contact: Extends for connection to 2nd circuit in Advent

Lytespan Track.

3. Embosed Keyway: For optional shade attachment.

4. Push Tab: Detaches unit.

5. Trunion Mounting: Tensioned with internal spring washer. 90° stop for

vertical adjustment (UL requirement).

6. Pivot Mounting: Permanently tensioned; 350° stop.

7. Textured Grip: Molded Valox®Integral color.

8. Fitting Housing: Die-cast aluminum.

Electrical

Porcelain socket, medium base, nickel plated screw shell. No. 18 braided SF-1

leads with silicone sleeving.

Finish

All painted finishes baked enamel.

Labels

UL; I.B.E.W.

Catalog No. Finishes Mounting Lamps Lamps

8202WH Matte White All Lytespan Track Systems R20 75W Max., R30 100W Max., Accepts PAR16, 20 or 30 shades.

8202BK Matte Black PAR16 75W Max. (T-H), PAR20 50W Max. (T-H), (See Lightolier Specication Sheets

PAR30 75W Max. (T-H), PAR38 150W Max. 8215, 8216, 8217, 8225, 8226,

8227, 8235, 8236 and 8237).

Ordering Information

8202WH

8202BK

Valox®is a trademark of General Electric.

Job Information Type:

631 Airport Road, Fall River, MA 02720 • (508) 679-8131 • Fax (508) 674-4710

We reserve the right to change details of design, materials and finish.

Lytespan Track Lighting System 8202WH

Page 2 of 2 PAR-Tech Hinged

Lighting Data

1,300 2,000

60W PAR16

NFL (Halogen) 30ϒ

3' 144 1.6' 1.6'

5' 52 2.7' 2.7'

7' 27 3.8' 3.8'

9' 16 4.8' 4.8'

3' 1.7' 94 2.2' 1.9'

5' 2.9' 34 3.7' 3.1'

7' 4.0' 17 5.1' 4.3'

9' 5.2' 10 6.6' 5.6'

2' 2.0' 115 2.3' 1.5'

3' 3.0' 51 3.5' 2.3'

4' 4.0' 29 4.6' 3.0'

5' 5.0' 18 5.8' 3.8'

1' 1.7' 163 2.7' 1.1'

2' 3.5' 41 5.5' 2.1'

3' 5.2' 18 8.2' 3.2'

4' 6.9' 10 10.9' 4.3'

6' 139 1.0' 1.0'

8' 78 1.4' 1.4'

10' 50 1.7' 1.7'

12' 35 2.1' 2.1'

5' 2.9' 130 1.2' 1.0'

7' 4.0' 66 1.6' 1.4'

9' 5.2' 40 2.1' 1.8'

11' 6.4' 27 2.6' 2.2'

3' 3.0' 196 1.1' 0.7'

5' 5.0' 71 1.8' 1.2'

7' 7.0' 36 2.5' 1.7'

9' 9.0' 22 3.2' 2.2'

2' 3.5' 156 1.4' 0.7'

3' 5.2' 69 2.1' 1.0'

4' 6.9' 39 2.9' 1.4'

5' 8.7' 25 3.6' 1.7'

5,000 2,000

60W PAR16

NSP (Halogen) 10ϒ

6' 167 0.8' 0.8'

8' 94 1.1' 1.1'

10' 60 1.4' 1.4'

12' 42 1.7' 1.7'

5' 2.9' 156 0.9' 0.8'

7' 4.0' 80 1.3' 1.1'

9' 5.2' 48 1.7' 1.5'

11' 6.4' 32 2.1' 1.8'

3' 3.0' 236 0.8' 0.6'

5' 5.0' 85 1.4' 1.0'

7' 7.0' 43 2.0' 1.4'

9' 9.0' 26 2.5' 1.8'

2' 3.5' 188 1.1' 0.6'

3' 5.2' 83 1.7' 0.8'

4' 6.9' 47 2.3' 1.1'

5' 8.7' 30 2.8' 1.4'

6,000 2,000

50W PAR20

NSP (Halogen) 8ϒ

DFCLWDC FC LW DC FC LW DC FC LW

Beam Spread Beam Center Rated

50% Max. CP C.P. Candelas Life-Hrs

1,850 2,000

50W PAR20

NFL (Halogen) 27ϒ

4' 116 1.9' 1.9'

6' 51 2.9' 2.9'

8' 29 3.8' 3.8'

10' 19 4.8' 4.8'

3' 1.7' 134 2.0' 1.7'

5' 2.9' 48 3.3' 2.8'

7' 4.0' 25 4.6' 3.9'

9' 5.2' 15 5.9' 5.0'

3' 3.0' 73 3.1' 2.0'

4' 4.0' 41 4.1' 2.7'

5' 5.0' 26 5.1' 3.4'

6' 6.0' 18 6.1' 4.1'

1' 1.7' 231 2.3' 1.0'

2' 3.5' 58 4.6' 1.9'

3' 5.2' 26 7.0' 2.9'

4' 6.9' 14 9.3' 3.8'

6' 89 1.6' 1.6'

8' 50 2.1' 2.1'

10' 32 2.6' 2.6'

12' 22 3.2' 3.2'

5' 2.9' 83 1.8' 1.5'

7' 4.0' 42 2.5' 2.1'

9' 5.2' 28 3.2' 2.7'

11' 6.4' 17 3.9' 3.3'

3' 3.0' 126 1.6' 1.1'

5' 5.0' 45 2.7' 1.9'

7' 7.0' 23 3.8' 2.6'

9' 9.0' 14 4.8' 3.4'

1' 3.5' 100 2.2' 1.1'

2' 5.2' 44 3.3' 1.6'

3' 6.9' 25 4.4' 2.1'

4' 8.7' 18 5.6' 2.6'

3,200 2,000

50W PAR20

SP (Halogen) 15ϒ

8' 266 1.1' 1.1'

12' 118 1.7' 1.7'

16' 66 2.2' 2.2'

20' 43 2.8' 2.8'

7' 4.0' 225 1.3' 1.1'

10' 5.8' 110 1.9' 1.6'

13' 7.5' 65 2.4' 2.1'

16' 9.2' 43 3.0' 2.6'

5' 5.0' 240 1.4' 1.0'

7' 7.0' 123 2.0' 1.4'

9' 9.0' 74 2.5' 1.8'

11' 11.0' 50 3.1' 2.2'

3' 5.2' 238 1.7' 0.8'

4' 6.9' 133 2.3' 1.1'

5' 8.7' 85 2.8' 1.4'

6' 10.4' 59 3.4' 1.7'

17,000 3,000

50W PAR30

NSP (HIR) 8ϒ

3,200 2,500

75W PAR30

NFL (Halogen) 30ϒ

6' 89 3.2' 3.2'

8' 50 4.3' 4.3'

10' 32 5.4' 5.4'

12' 22 6.4' 6.4'

5' 2.9' 83 3.7' 3.1'

7' 4.0' 42 5.1' 4.3'

9' 5.2' 26 6.8' 5.6'

11' 6.4' 17 8.1' 6.8'

3' 3.0' 126 3.5' 2.3'

5' 5.0' 45 5.8' 3.8'

7' 7.0' 23 8.1' 5.3'

9' 9.0' 14 10.4' 6.8'

2' 3.5' 100 5.5' 2.1'

3' 5.2' 44 8.2' 3.2'

4' 6.9' 25 10.9' 4.3'

5' 8.7' 16 13.7' 5.4'

8' 219 1.3' 1.3'

12' 97 1.9' 1.9'

16' 55 2.5' 2.5'

20' 35 3.1' 3.1'

7' 4.0' 186 1.5' 1.3'

10' 5.8' 91 2.1' 1.8'

13' 7.5' 54 2.7' 2.4'

16' 9.2' 36 3.4' 2.9'

5' 5.0' 198 1.6' 1.1'

7' 7.0' 101 2.2' 1.6'

9' 9.0' 61 2.9' 2.0'

11' 11.0' 41 3.5' 2.4'

3' 5.2' 194 1.9' 0.9'

4' 6.9' 109 2.6' 1.3'

5' 8.7' 70 3.2' 1.6'

6' 10.4' 49 3.8' 1.9'

14,000 2,500

75W PAR30

NSP (Halogen) 9ϒ

4' 125 2.9' 2.9'

6' 56 4.4' 4.4'

8' 31 5.8' 5.8'

10' 20 7.3' 7.3'

3' 1.7' 144 3.0' 2.5'

5' 2.9' 52 5.1' 4.2'

7' 4.0' 27 7.1' 5.9'

9' 5.2' 16 9.1' 7.6'

3' 3.0' 79 5.0' 3.1'

4' 4.0' 44 6.7' 4.1'

5' 5.0' 28 8.4' 5.1'

6' 6.0' 20 10.1' 8.2'

1' 1.7' 250 4.8' 1.5'

2' 3.5' 63 9.7' 2.9'

3' 5.2' 28 14.5' 4.4'

4' 6.9' 16 19.3' 5.8'

2,000 2,500

75W PAR30

FL (Halogen) 40ϒ

14,500 2,500

90W PAR38

SP (Halogen) 12ϒ

8' 227 1.7' 1.7'

12' 101 2.5' 2.5'

16' 57 3.4' 3.4'

20' 36 4.2' 4.2'

7' 4.0' 192 2.0' 1.7'

10' 5.8' 94 2.8' 2.4'

13' 7.5' 58 3.7' 3.2'

16' 9.2' 37 4.5' 3.9'

5' 5.0' 205 2.1' 1.5'

7' 7.0' 105 3.0' 2.1'

9' 9.0' 63 3.8' 2.7'

11' 11.0' 42 4.7' 3.3'

3' 5.2' 201 2.6' 1.3'

4' 6.9' 113 3.5' 1.7'

5' 8.7' 73 4.3' 2.1'

6' 10.4' 50 5.2' 2.5'

10' 195 1.6' 1.6'

15' 87 2.4' 2.4'

20' 49 3.1' 3.1'

25' 31 3.9' 3.9'

8' 4.6' 198 1.7' 1.5'

12' 6.9' 88 2.5' 2.2'

16' 9.2' 49 3.4' 2.9'

20' 11.5' 32 4.2' 3.6'

6' 6.0' 192 1.9' 1.3'

9' 9.0' 85 2.9' 2.0'

12' 12.0' 48 3.8' 2.7'

15' 15.0' 31 4.8' 3.3'

4' 6.9' 152 2.6' 1.3'

6' 10.4' 68 3.8' 1.9'

8' 13.9' 38 5.1' 2.5'

10' 17.3' 24 6.4' 3.1'

19,500 2,500

90W PAR38

NSP (Halogen) 9ϒ

6' 125 3.0' 3.0'

8' 70 4.0' 4.0'

10' 45 5.0' 5.0'

12' 31 6.0' 6.0'

5' 2.9' 117 3.4' 2.9'

7' 4.0' 60 4.8' 4.0'

9' 5.2' 36 6.1' 5.2'

11' 6.4' 24 7.5' 6.3'

3' 3.0' 177 3.2' 2.1'

5' 5.0' 64 5.3' 3.5'

7' 7.0' 32 7.4' 4.9'

9' 9.0' 20 9.6' 6.3'

2' 3.5' 141 4.9' 2.0'

3' 5.2' 63 7.4' 3.0'

4' 8.9' 35 9.8' 4.0'

5' 8.7' 23 12.3' 5.0'

4,500 2,500

90W PAR38

FL (Halogen) 28ϒ

DFC L

LAMP 0˚ AIMING ANGLE A=30˚ AIMING ANGLE A=45˚ AIMING ANGLE A=60˚ AIMING ANGLE

Aiming Angle 0˚ 30˚, 45˚ or 60˚ Horizontal 30˚, 45˚ or 60˚ Vertical

L Beam Length

W Beam Width

CDistance to center beam

D Distance

A Aiming Angle

FC Footcandles

Land Ware the outer points where the candle

power drops to 50% of the maximum. FC are the

initial footcandles at the center of the beam.
