Philips GoGear SA2611 Manuale utente
Great user manuals database on UserManuals.info
1
EN
Contents
2 Is there a manual?
2 Register your product
2 Don’t forget about upgrades
3 What’s in the box
4 Overview of controls and connections
5 Install
5 Connect and charge
5 Insert the battery
5 Read the battery level indication of your player
6 Connect to PC
6 Transfer
6 Transfer music
7 Enjoy
7 Turn on and play
7 Main menu
7 Navigate the menu
8 Music mode
8 Radio*
8 Auto tune
8 Play a preset radio station
9 Recordings
9 Make recordings
9 Play back recordings
10 Troubleshooting
10 How do I reset my player?
10 Need help?
10 Disposal of your old product
* This feature is only available for some regional versions.
Great user manuals database on UserManuals.info
2
Is there a manual?
You have a detailed user manual and FAQ on the CD by-packed with your player. You can also
download the same file from this website: www.philips.com/support
Register your product
Since it is possible for you to upgrade your product, we recommend that you register your
product on www.philips.com/welcome so we can inform you as soon as new free upgrades
become available.
Don’t forget about upgrades
We know you will enjoy your product for a long time. For best performance, we recommend that
you regularly check in to www.philips.com/support for free updates of the latest software and
Firmware Manager for your product. These downloads will help you to optimize your product’s
performance and to take advantage of our future support of new audio formats.
Enjoy your new music experience.
Great user manuals database on UserManuals.info
3
EN
What’s in the box
A computer with:
Windows 2000, XP or Vista
Pentium III 800MHz processor or higher
CD-ROM drive
128 MB RAM
500MB Hard Disk space
USB Port
Internet connection (preferable)
Microsoft Internet Explorer 6.0 or later
What else you'll need.
USB cable
CD-ROM Quick start guide
Computer
Headphones
Philips GoGear audio player
Quick start guide
1
2
3
4
Install
Connect
Transfer
Enjoy
SA2610 SA2611 SA2615
SA2616 SA2620 SA2621
SA2625 SA2626 SA2627
SA2628 SA2629 SA2640
SA2641 SA2645 SA2646
SA2647
AAA battery
Great user manuals database on UserManuals.info
4
Overview of controls and connections
H
A
B
C
D
F
E
G
ApHeadphone jack
BMIC Microphone
C- VOLUME + Increases/decreases volume (hold to
increase/decrease fast)
Dy/ 2; On / Off
Play/Record / Pause
Confirm selection
EBack one level (hold to return to root menu)
FUSB connector
G3/4Scrolls up/down (hold to quick scroll)
Hslider Hold slider to lock/unlock all keys (except
-VOLUME+)
Great user manuals database on UserManuals.info
5
EN
Install
1
1Insert the CD supplied with your product into the CD ROM drive of your PC.
2Follow the on-screen instructions to complete the installation of Philips Device
Manager.
Connect
2
Insert the battery
A
B
1Remove the USB cap. 2Remove the battery door
by sliding it in the
direction of the arrow.
3Inser the supplied AAA
battery into the battery
compartment.
Read the battery level indication of your player
The approximate power levels of your battery are indicated as follows:
Full Two-thirds full Half full Low Empty
Note When the batteries are almost empty, the low battery screen blinks. The
player saves all settings and unfinished recordings and switches off in less than 60
seconds.
Great user manuals database on UserManuals.info
6
Transfer
3
The player appears as a USB mass storage device in Windows Explorer. You can organize
files, and transfer music to your player during USB connection.
Transfer music
1Click and highlight one or more songs to transfer between your player and your
computer.
2Use drag and drop actions to complete your transfer.
Tip To transfer music CDs to the player use software such as Musicmatch Jukebox or
Windows Media Player, rip (convert) the songs on your music CD into MP3/WMA
files. Copy the files into the digital audio player via Windows Explorer. Free versions of
these programs can be downloaded from the internet.
Connect to PC
Use the supplied USB cable to connect the player to the PC.
1Pull off the USB cap.
2Connect the supplied USB cable to the USB port at the bottom of the player, the
other end to your PC.
C
A
