Philips MCM 760 Manuale utente

MCM 760

Quick Start Guide

What’s in the Box?

You should find these items upon opening the box.

Quick Start Guide

User Manual

Quick start guide User manual

Prepare

Install

Enjoy

Step A

Step

FM wire antenna AM antenna

PRO

CD TUNER

REPEATPROGRAM

TAPEA/BDISPLAY/CLOCK

SHUFFLE

TAPEAUX

STANDBY

TAPEREC

INC.SURR

BASSTREBLE

DIM

SLEEP/TIMERTIMERON/OFF

USBRECUSBDELSNOOZE

MUTE

USB

PRESET

ALBUM

VOL

Remote control and

2 x AAbattery

AC power cord

MCM760 QSG_-37-Eng 2/16/2006, 19:071

Install

Rear connections

Connect the cable of the left speaker to L +/- (red and black) and the cable

of the right speaker to R +/- (red and black)

Extend the wire antenna and fit it to FM ANTENNA

a. Assemble the loop antenna

b. Fit the plug of the loop antenna to AM ANTENNA

Connect the AC power cord to the wall socket

To deactivate the *Demonstration Mode

Press and hold Çon the set until DEMO OFF appears

STANDBY-ON

ECO POWER

TAPERECORDUSB RECORD OPEN/CLOSEPROGRAM

OPEN CLOSE

WMA-MP3-CD/CD-R/CD-RW COM PATIBLE

ALBUM STOP/DEMO

VOLUME

BASS

TREBLE

PLAY/PAUSEPRESET

USB DIRECT

*The Demonstration Mode displays various features of MCM760.

MCM760 QSG_-37-Eng 2/16/2006, 19:082

Tuner: Plug & Play

Notes for remote control:

– First, select the source you wish to

control by pressing one of the source

select keys on the remote control (DISC

orTUNER, for example).

–Then select the desired function

(2;,

for example).

Connect the set to the power supply

➜ AUTO INSTALL – PRESS PLAY appears

Install

Plug & Play allows you to store all available radio stations automatically (up to 40 stations).

STANDBY-ON

ECO POWER

TAPE RECORDUSB RECORD OPEN/CLOSEPROGRAM

OPEN CLOSE

WMA-MP3-CD/CD-R/CD-RW COMPATIBLE

ALBUM STOP/DEMO

VOLUME

BASS

TREBLE

PLAY/PAUSEPRESET

USB DIRECT

Prepare

Press ÉÅ on the set to start installation

➜INSTALL TUNER AUTO appears

➜ After all stations are stored, the last preset station will then be played

Press the íor ëbuttons once or more until the desired preset station is displayed

Setting the clock

Press PROGRAM repeatedly to change between 12-hour and 24-hour clock mode

Press ÉÅ to change to minutes setting, then press àor árepeatedly to set the minutes

Press DISPLAY/CLOCK again to store the setting

On the remote control, press and hold DISPLAY/CLOCK until the clock time starts

flashing

Press àor árepeatedly to set the hour

CD TUNER

REPEAT PROGRAM

TAPE A /B DISPLAY/CLOCK

SHUFFLE

TAPE AUX

STANDBY

TAPE REC USB REC USB DEL SNOOZE

PRESET

ALBUM

VOL

To view the clock time,

a. During playback, press DISPLAY/CLOCK on the remote control

b. In ECO POWER mode (power-saving mode), press and hold STANDBY-ON/ ECO

POWER y to switch the set to standby mode

Helpful hints:

- To learn how to set the timer, see the chapter Timer in the User Manual.

- In standby mode, pressing DISPLAY/CLOCK button will switch the system to ECO POWER mode.

MCM760 QSG_-37-Eng 2/16/2006, 19:083

Enjoy

Playing discs

With this system, you can play all pre-recorded audio CDs (CDDA), all finalized audio CD-Rs

and CD-RWs, MP3/WMA-CDs (CD-Rs/CD-RWs with MP3/WMA files)

Press OPEN/CLOSEçto open the CD compartment

Press ÉÅ to start playback

To stop playback, press STOPÇ

Press CD to select CD source

Insert a disc with the printed side facing up. Press OPEN/CLOSEçagain to close the

compartment

STANDBY-ON

ECOPOWER

TAPERECORDUSBRECORD OPEN/CLOSEPROGRAM

MCM760 MICRO SYSTEM

CD TUNER USB

TAPE /AUX

MP3-CD/ CD-R/CD

-RW COMPATIBLE

MICRO SYSTEM

WMA-MP3-CD/CD-R/CD-RW COMPATIBLE

OPEN/

CD TUNER

REPEAT PROGRAM

TAPE A /B DISPLAY/CLOCK

SHUFFLE

TAPE AUX

STANDBY

PRESET

VOL

Playing a USB mass storage device

With the Hi-Fi system, you can use USB flash memory (USB 2.0 or USB1.1),

USB flash players (USB 2.0 or USB1.1), memory cards (requires an additional card reader to

work with this Hi-Fi system).

Insert the USB device’s USB plug into the socket on MCM760

STANDBY-ON

ECO POWER

TAPE RECORDUSB RECORD OPEN/ CLOSEPROGRAM

WMA-MP3-CD/CD-R/CD-RW COMPATIBLE

CD TUNER USB

VOLUME

BASS

TREBLE

PLAY/PAUSE

TAP E /AUX

PRESET

Press USB to select USB source

Play the USB’s audio files as you do with the albums/tracks on a CD

BASS TREBLE

MUTEUSB

MCM760 QSG_-37-Eng 2/16/2006, 19:084

Enjoy

STANDBY-ON

ECO POWER

TAPE RECORDUSB RECORD OPEN/ CLOSEPROGRAM

WMA-MP3-CD/CD-R/CD-RW COMPATIBLE

CD TUNER USB

VOLUME

BASS

TREBLE

PLAY/PAUSE

TAP E /AUX

PRESET

STANDBY-ON

ECOPOWER

TAPE RECORDUSB RECORD OPEN/CLOSEPROGRAM

MCM760 MICRO SYSTEM

CD TUNER USB

TAPE / A U X

MP3-CD/ CD-R/CD

-RW COMPATIBLE

M ICRO SYSTEM

WMA-MP3-CD/CD-R/CD-RW COMPATIBLE

OPEN/

CD TUNER

REPEAT PROGRAM

TAPE A /B DISPLAY/CLOCK

SHUFFLE

TAPE AUX

STANDBY

TAPE REC

INC. SURR DIM

SLEEP/TIMER TIMER ON/OFF

USB REC USB DEL SNOOZE

PRESET

ALBUM

VOL

Recording to a USB mass storage device

With MCM760, you can record your favorite CD music to a USB mass storage device.

Carry your favorite songs wherever you go.

Insert the USB device’s USB plug into the socket on MCM760

Press CD to select CD source

Press íor ëonce or repeatedly until the desired track number appears in the display

Program your desired tracks (see User Manual, CD: Programming tracks)

- Make sure you press Çafter finishing programming

Press USB RECORD once or more to select your recording options:

RECORD TRACK–record the selected track to the USB mass storage device

RECORD ALL–record the whole disc/program to the USB mass storage device

Press Çto stop recording

Insert a disc with the printed side facing up. Press OPEN/CLOSEçagain to close the

compartment

To find your recorded tracks

You can find and playback the ripped tracks in the album _PHILIPS

Press USB to select USB source

➜The audio CD files have been converted to MP3 format and named as

TRXXXXXX.MP3

➜ For MP3/WMA files, the track information are retained

Helpful hints:

- MCM760 only supports the filenames in English.

- Only the completely ripped MP3/WMA file can be found and played by MCM760.

Press à/áand í/ëto select the desired album _PHILIPS and tracks

MCM760 QSG_-37-Eng 2/16/2006, 19:085

Enjoy

Recording to a tape

Press TAPE/AUX once or more to select TAPE (or TAPE on the remote control)

Load a recordable tape into the tape deck.

Press TAPE A/B on the remote control repeatedly to select a recording mode:

➜åfor recording on one side only

➜ ∂∂

∂∂

∂for recording on both sides

OPEN CLOSE

ALBUM STOP/DEMO

Select the recording source: CD, TUNER, USB or AUX

Start playback of the selected source

6 Press TAPE RECORD

➜REC starts flashing

To stop recording, pressÇon the set

STANDBY-ON

ECO POWER

TAPE RECORDUSBRECORD OPEN/ CLOSEPROGRAM

OPEN CLOSE

WMA-MP3-CD/CD-R/CD-RW COMPATIBLE

ALBUM STOP/DEMO

VOLUME

BASS

TREBLE

PLAY/PAUSEPRESET

USB DIRECT

PHILIPS CONSUMER ELECTRONICS NORTH AMERICA

P.O. Box 671539, Marietta, GA. 30006-0026

http://www.philips.com PDCC-AL-0607

Playing a tape

Press TAPE/AUX once or more to select TAPE (or TAPE on the remote control)

Press OPEN / CLOSE 0to open the tape deck door

Insert a recorded tape and close the tape deck door

➜Load the tape with the open side downward and full spool to the left

PressÉÅ to start playback

Press TAPE A/B on the remote control repeatedly to select the different playback modes

å: plays one side of the tape

∂ : plays both sides once

∫: plays both sides repeatedly (up to 10 times)

OPEN CLOSE

ALBUM STOP/DEMO

CD TUNER

REPEAT PROGRAM

TAPE A /B DISPLAY/CLOCK

SHUFFLE

TAPE AUX

STANDBY

PRESET

VOL

MCM760 QSG_-37-Eng 2/16/2006, 19:086
