Philips MCM207/12 Manuale utente

MCM207

What’s in the Box?

You should nd these items upon opening the box.

Quick Start Guide

Remote Control

Quick Start Guide User Manual

Power adapter

MCM207_12_QSG_Eng.indd 1 2009-9-24 16:24:45

1

2

Connect the speaker cables. Tip

See the User Manual for how to

connect other equipment to this

system.

Connect the AC power adapter to the

wall socket.

Set clock

Important!

– If in Eco Power Standby mode, press CLOCK to show clock rst, then press and

hold CLOCK to proceed clock setting as described in step 2 and afterwards.

1

2

3

4

5

6

In standby mode, press and hold CLOCK on the main unit.

Press 9 on the main unit to select 12 hour or 24 hour format.

Turn VOLUME +/- to set the hour.

Press CLOCK to conrm.

The minute digits are displayed and begin to blink.

»

Turn VOLUME +/- to set the minute.

Press CLOCK to conrm.

MCM207_12_QSG_Eng.indd 2 2009-9-24 16:24:46

Play disc

Press CD to select the disc source.

Press ç to open the disc tray.

Insert a disc with the printed side facing up, then close the disc tray.

To pause/resume play, press ÉÅ.

To stop play, press 9 .

4

3

2

1

5

1

2

3

Insert the USB device’s USB plug into the socket on the main unit.

Press USB/MP3 LINK repeatedly to select the USB device source.

Play the USB’s audio les as you do with the albums/tracks on a CD.

Play form USB

With the micro system, you can use USB ash memory (USB 2.0 or USB1.1),

USB ash players (USB 2.0 or USB1.1), memory cards (requires an additional card reader to

work with this micro system).

MCM207_12_QSG_Eng.indd 3 2009-9-24 16:24:47

C Royal Philips Electronics N.V. 2009

All rights reserved.

http://www.philips.com

Tip

Detailed playback features and additional functions

are described in the accompany owner's manual.

1

2

3

Press TUNER repeatedly to select FM or MW.

Press PROG for more than two seconds to program all available stations in order of wave-

band.

Press 34 to select a preset number.

Program and tune to radio stations

MCM207_12_QSG_V3.0

MCM207_12_QSG_Eng.indd 4 2009-9-24 16:24:47
