Philips 105S61 Manuale utente

Safetyand Troubleshooting Information

SafetyPrecautionsand Maintenance Troubleshooting RegulatoryInformation

Safetyprecautionsandmaintenance

Read and followtheseinstructionswhenconnectingandusing yourcomputermonitor:

lDisconnectthe monitorfromthe powersupplyifthe monitorisnot tobe used foran

extended period oftime.

lDonotattempttoremovethe back cover,asyou willbeexposedtoashockhazard.The

back covershouldonlybe removed byqualifiedservicepersonnel.

lDonotplaceobjectson topofthe monitorcabinet, objectscouldfall intoventsorcover

themand preventpropercoolingofthe monitor'selectronicdevices.

lToavoidtheriskofshock orpermanentdamagetotheset,do notexposethe monitorto

rainorexcessivemoisture.

lDonotusealcoholorammonia-based liquidtocleanthe monitor.Ifnecessary, clean with

aslightlydampcloth.Disconnectthe monitorfromthe powersupplybeforecleaning.

lWhen positioning themonitor,makesurethepowerplug and outletareeasilyaccessible.

Consult aservicetechnicianif the monitordoesnot operatenormallywhen operating instructions

ofthismanualarefollowed.

RETURN TOTOPOFTHE PAGE

WARNING:Useofcontrols, adjustments, orprocedures other

thanthosespecifiedinthisdocumentationmayresultin

exposuretoshock, electrical hazards, and/ormechanical

hazards.

AboutThisElectronicUser'sManual

About ThisGuide OtherDocumentsYouMayNeed NotationalDescriptions

AboutThisGuide

Thiselectronicuser'sguide isintended foranyone who usesthe PhilipsColorMonitor.It

describesthe monitor'sfeatures,setup,operation and all otherinformation,whichisthesame

exactinformationdescribed inourprinted version.

The sectionsareasfollows:

lSafetyandTroubleshooting Information providestipsand solutionsforcommonproblems,

and otherrelatedinformation you mayneed.

lAboutThisElectronicUser'sManualgivesoverviewofwhatinformationareincluded as

well asnotationicondescriptionsand otherdocumentation you can referto.

lProductInformation givesan overviewofthe monitor'sfeaturesandaswellasthe

technicalspecificationsforthismonitor.

lInstalling YourMonitor describesthe initialsetup process andgivesan overviewofhowto

usethe monitor.

lOnScreenDisplay providesinformation on adjustingthe settingson yourmonitor.

lCustomerCareand Warranty isalistofworldwidePhilipsconsumerinformation centers

along withthehelpdesk phone numbersand informationonthe applicablewarrantyof

yourproduct..

lGlossary providesmoreinformation fortechnicalterms.

lDownload allowsuserstoinstallthe entiremanualon theirharddrive.

lFrequentlyAskedQuestions providesanswerstocommonlyasked questions.

RETURN TOTOPOFTHE PAGE

OtherDocumentsYouMay Need

Inadditiontothis ElectronicUser'sGuide,youmayneed torefertothe followingdocumentation:

lPhilipsColorMonitorQuick StartGuide whichsummarizesthe stepsforsetting up the

monitor. Thisisincluded withthisproduct.

RETURN TOTOPOFTHE PAGE

Notational Descriptions

The following subsectionsdescribe notationalconventionsused inthisdocument.

Notes,Cautions,andWarnings

Throughoutthisguide,blocks oftext maybe accompaniedbyan icon and printed inboldtype or

initalictype.Theseblocks arenotes,cautions,and warnings,and theyareusedasfollows:

Somewarningsmayappearinalternateformatsandmaybe unaccompanied byan icon. Insuch

cases, the specificpresentation ofthewarning ismandated byregulatoryauthority.

RETURN TOTOPOFTHE PAGE

All rightsreserved. Reproduction,copying,usage,modifying,hiring, renting,publicperformance,transmissionand/or

broadcastinginwholeorinpartisprohibitedwithout writtenconsentofPhilipsElectronicsN.V.

NOTE:Thisiconindicatesimportantinformationandtipsthathelpyou make

betteruseofyour computersystem.

CAUTION: Thisiconindicatesinformationthattellsyouhowtoavoideither

potentialdamagetohardwareor loss ofdata.

WARNING:Thisiconindicatesthepotentialforbodilyharmand tellsyou

howtoavoidtheproblem.

SMARTHELP:Thisiconindicates helpfulinformationwhenadjustingtheOn

ScreenDisplay ofyourmonitor.

Product Information

Product Features • Technical Specifications • Automatic Power Saving •

Physical Specification • Pin Assignment • Product Views

Product Features

Model Regulation Color

105S61 MPRII Grey

105S68 TUV-Bauart Grey

105S69 TUV-Bauart Grey

105S6

z15" -inch (14.0" VIS) color monitor with excellent front of screen performance

zAutoscan covers horizontal frequencies up to 54kHz offering a maximum resolution of

1024 x 768

zFlat square high contrast CRT with high-resolution 0.28 mm dot pitch

zFCC, CE (in selected countries only) and ISO9241, ISO14001 certified

RETURN TO TOP OF THE PAGE

Technical Specifications*

CRT

• Size and deflection 15 inch / 38 cm ; 90° deflection angle

• Dot pitch 0.28 mm

• Tube type 29mm neck. non-glare screen

• Phosphor P22

SCANNING

• Horizontal scanning 30 - 54KHz

• Vertical scanning 50 - 120 Hz

VIDEO

• Video dot rate 72 MHz

• Input impedance

- Video 75 ohm

- Sync 4.7 kOhm

• Input signal levels 0.7 Vpp

Automatic Power Saving

If you have VESA's DPMS compliance display card or software installed in your PC, the monitor

can automatically reduce its power consumption when not in use. And if an input from a

keyboard, mouse or other input device is detected, the monitor will automatically "wake up". The

following table shows the power consumption and signaling of this automatic power saving

features:

RETURN TO TOP OF THE PAGE

Physical Specifications

• Sync input signal Separate sync

• Sync polarities Positive and negative

WHITE COLOR TEMPERATURE

Chromaticity CIE coordinates:

• at 9300 degrees K x = 0.283 / y = 0.297

• at 6500 degrees K x = 0.313 / y = 0.329

Power Management Definition

VESA's

Mode Video H-sync V-sync Power

Used

LED

color

ON Active Yes Yes Typical

≤62WGreen

OFF Blanked No No ≤5W orange

This monitor is ENERGY STAR®compliant. As an ENERGY STAR®Partner, PHILIPS

has determined that this product meets the ENERGY STAR®guidelines for energy

efficiency.

• Dimensions

14.2" x 14.3" x 15.3" / 360 x 362 x 387 mm (including base)

14.2" x 12.7" x 15.3" / 360 x 321 x 387 mm (excluding

base)

• Weight 11.5 kg

• Power supply 90 - 264 VAC, 50/60Hz

* These information are subject to change without notice.

RETURN TO TOP OF THE PAGE

Pin Assignment

The 15-pin D-sub connector (male) of the signal cable (IBM systems):

RETURN TO TOP OF THE PAGE

Views

Follow the links to see various views of the monitor and its components.

Front View

Rear View

• Temperature (operating) 0° to 40°C / 32° to 104°F

• Temperature (storage) -25° to +65°C / -13° to +149°F

• Relative humidity (storage) 5% to 95%

No. Assignment

1Red 9 NC

2 Green 10 Ground

3 Blue 11 Monitor Ground

4 Ground 12 DDC-Serial Data

5 Ground 13 H. Sync

6 R-Ground 14 V- Sync / * VCLK

7 G-Ground 15 DDC-Serial clock

8 B-Ground * For DDC

RETURN TO TOP OF THE PAGE

Installing your Monitor

Front View • Rear View

Front View

RETURN TO TOP OF THE PAGE

Rear View

1. Power Switch

2. Power Indicator

3. Menu

4. Contrast

5. Brightness

6. Exit

1. Power in - attach power cable here.

2. Video In - this is a cable which is already attached to your monitor. Connect

the other end of the cable to your PC.

RETURN TO TOP OF THE PAGE

On-Screen Display

Description of the On-Screen Display • The OSD Tree • The OSD Controls

Description of the On Screen Display

What is the On-Screen Display?

This is a feature in all Philips monitors which allows an end-user to adjust screen performance of

monitors directly through an on-screen instruction window. The user interface provides user-

friendliness and ease-of-use when operating the monitor.

Basic and simple instruction on the control keys.

On the front controls of your monitor, once you press the MENU button, the On Screen Display

(OSD) Main Controls window will pop up and you can now start making adjustments to your

monitor's various features. Use the Left or Right to make your adjustments within.

RETURN TO TOP OF THE PAGE

The OSD Tree

Below is an overall view of the structure of the On-Screen Display. You can use this as reference

when you want to later on work your way around the different adjustments.

RETURN TO TOP OF THE PAGE
