Philips 107B Manuale utente

electronic user's manual

file:///D|/EDFU/crt_17_6/edoc/english/107B/manual.html2005-05-19 ¤W¤È 10:16:07

Safety & Troubleshooting

Safety and Troubleshooting Information

Safety Precautions and Maintenance • Troubleshooting • Regulatory Information • Other

Related Information

Safety precautions and maintenance

●

RETURN TO TOP OF THE PAGE

file:///D|/EDFU/crt_17_6/edoc/english/107B/SAFETY/SAFETY.HTM2005-05-19 ¤W¤È 10:16:20

When using the monitor,please make sure to install the swivel base for safety concern.

WARNING: Use of controls, adjustments, or procedures other than those

specified in this documentation may result in exposure to shock, electrical

hazards, and/or mechanical hazards.

Read and follow these instructions when connecting and using your computer monitor:

●Disconnect the monitor from the power supply if the monitor is not to be used for an

extended period of time.

●Do not attempt to remove the back cover, as you will be exposed to a shock hazard. The

back cover should only be removed by qualified service personnel.

●Do not place objects on top of the monitor cabinet, objects could fall into vents or cover them

and prevent proper cooling of the monitor's electronic devices.

●To avoid the risk of shock or permanent damage to the set, do not expose the monitor to rain

or excessive moisture.

●Do not use alcohol or ammonia-based liquid to clean the monitor. If necessary, clean with a

slightly damp cloth. Disconnect the monitor from the power supply before cleaning.

●When positioning the monitor, make sure the power plug and outlet are easily accessible.

Consult a service technician if the monitor does not operate normally when operating instructions of

this manual are followed.

About This Electronic User's Manual

About This Guide • Other Documents You May Need • Notational Descriptions

About This Guide

This electronic user's guide is intended for anyone who uses the Philips Color Monitor. It describes

the monitor's features, setup, operation and all other information, which is the same exact

information described in our printed version.

The sections are as follows:

●Safety and Troubleshooting Information provides tips and solutions for common problems,

and other related information you may need.

●About This Electronic User's Manual gives overview of what information are included as well

as notation icon descriptions and other documentation you can refer to.

●Product Information gives an overview of the monitor's features and as well as the technical

specifications for this monitor.

●Installing Your Monitor describes the initial setup process and gives an overview of how to

use the monitor.

●On Screen Display provides information on adjusting the settings on your monitor.

●Customer Care and Warranty is a list of worldwide Philips consumer information centers

along with the help desk phone numbers and information on the applicable warranty of your

product..

●Glossary provides more information for technical terms.

●Download allows users to install the entire manual on their hard drive.

●Frequently Asked Questions provides answers to commonly asked questions.

RETURN TO TOP OF THE PAGE

Other Documents You May Need

In addition to this Electronic User's Guide, you may need to refer to the following documentation:

file:///D|/EDFU/crt_17_6/edoc/english/107B/ABOUT/ABOUT.HTM (1 of 3)2005-05-19 ¤W¤È 10:16:21

About This Electronic User's Manual

●Philips Color Monitor Quick Start Guide which summarizes the steps for setting up the

monitor. This is included with this product.

RETURN TO TOP OF THE PAGE

Notational Descriptions

The following subsections describe notational conventions used in this document.

Notes, Cautions, and Warnings

Throughout this guide, blocks of text may be accompanied by an icon and printed in bold type or in

italic type. These blocks are notes, cautions, and warnings, and they are used as follows:

NOTE: This icon indicates important information and tips that help you make

better use of your computer system.

CAUTION: This icon indicates information that tells you how to avoid either

potential damage to hardware or loss of data.

WARNING: This icon indicates the potential for bodily harm and tells you how

to avoid the problem.

SMART HELP: This icon indicates helpful information when adjusting the On

Screen Display of your monitor.

Some warnings may appear in alternate formats and may be unaccompanied by an icon. In such

cases, the specific presentation of the warning is mandated by regulatory authority.

RETURN TO TOP OF THE PAGE

file:///D|/EDFU/crt_17_6/edoc/english/107B/ABOUT/ABOUT.HTM (2 of 3)2005-05-19 ¤W¤È 10:16:21

About This Electronic User's Manual

broadcasting in whole or in part is prohibited without written consent of Philips Electronics N.V.

file:///D|/EDFU/crt_17_6/edoc/english/107B/ABOUT/ABOUT.HTM (3 of 3)2005-05-19 ¤W¤È 10:16:21

Product Information

Product Features • Lead-free product •Technical Specifications • Automatic Power Saving •

Specification • Pin Assignment • Product Views

Product Features

107B7

z17" -inch (16.0" VIS) color monitor with excellent front of screen performance for use with MACs and P

zAutoscan covers horizontal frequencies up to 86kHz offering a maximum resolution of 1600 x 1200

zReal Flat High Contrast CRT with high-resolution 0.25 mm dot pitch (0.21 hdp)

zLarge screen display in a small footprint: 17-inch conventional monitor with maximum depth of only 42

zsRGB for true on screen color representation.

zFCC, CE (in selected countries only) and ISO9241, ISO14001 certified

zHigh Bright hot key delivers 4 suitable brightness instantly for text, internet, game and multimedia.

RETURN TO TOP OF THE PAGE

Lead-free product

Philips eliminated toxic substances like lead from its displays. Lead-free display helps protect your health and

environmentally sound recovery and disposal of waste from electrical and electronic equipment. Philips compl

Community stringent RoHS Directive mandating restrictions on

hazardous substances in electrical and electronic equipment. With Philips, you can be confident that your dis

harm the environment.

Technical Specifications*

Model Regulation Color

107B70 TCO'03Grey

107B75 TCO'03 Black

CRT

• Size and deflection 17 inch / 41 cm ; 90° deflection angle

• Dot pitch 0.25 mm

• Horizontal dot pitch 0.21 mm

• Tube type Shadow mask, Real Flat, high contrast, anti-glare,

anti-static, anti reflection

• Phosphor P22

• Recommended display area 12.0" x 9.0" / 306 x 230 mm

• Maximum display area 12.8" x 9.6" / 325 x 244 mm

* These information are subject to change without notice.

RETURN TO TOP OF THE PAGE

Automatic Power Saving

SCANNING

• Horizontal scanning 30 - 86KHz

• Vertical scanning 50 - 160 Hz

VIDEO

• Video dot rate 180 MHz

• Input impedance

- Video 75 Ohm

- Sync 1.8 kOhm

• Input signal levels 0.7 Vpp

• Sync input signal Separate sync

• Sync polarities Positive and negative

WHITE COLOR TEMPERATURE

Chromaticity CIE coordinates:

• at 9300 degrees K x = 0.283 / y = 0.297

• at 6500 degrees K x = 0.313 / y = 0.329

• at 5500 degrees K x = 0.332 / y = 0.347

sRGB x = 0.313 / y = 0.329

sRGB

sRGB is a standard for ensuring correct exchange of colors between different devices (e.g.

digital cameras, monitors, printers, scanners, etc.)

Using a standard unified color space, sRGB will help represent pictures taken by an sRGB

compatible device correctly on your sRGB enabled Philips monitors. In that way, the colors

are calibrated and you can rely on the correctness of the colors shown on your screen.

Important with the use of sRGB is that the brightness and contrast of your monitor is fixed to

a predefined setting as well as the color gamut. Therefore it is important to select the sRGB

setting in the monitor's OSD.

To do so, open the OSD by pressing the MENU button on the front of your monitor. Use the

down button to go to Color temperature and press MENU again. Then move the down button

to go to sRGB and press MENU again.

Exit this OSD.

After this, please don't change the brightness or contrast setting of your monitor. If you

change either of these, the monitor will exit the sRGB mode and go to a color temperature

setting of 6500K.

If you have VESA's DPMS compliance display card or software installed in your PC, the monitor can automati

reduce its power consumption when not in use. And if an input from a keyboard, mouse or other input device i

the monitor will automatically "wake up". The following table shows the power consumption and signaling of t

saving features:

RETURN TO TOP OF THE PAGE

Physical Specifications

* These information are subject to change without notice.

RETURN TO TOP OF THE PAGE

Pin Assignment

Power Management Definition

VESA's Mode Video H-sync V-sync Power Used Power

Saving (%) LED color

Active ON Yes Yes < 75W 0 % Green

Sleep OFF No No < 2W 99% Flashing

Green

Switch Off OFF -- -- < 2W 99% Off

• Dimensions 15.6" x 15.0" x 16.7" / 397 x 382 x 423.5 mm (including base)

15.6" x 13.1" x 16.7" / 397 x 333.5 x 423.5 mm (excluding base)

• Weight 13.5 kg

• Power supply 100-240 VAC, 60-50Hz

• Temperature (operating) 0° to 40°C / 32° to 104°F

• Temperature (storage) -25° to +65°C / -13° to +149°F

• Relative humidity (storage) 5% to 95%

* Resolution 1280 x 1024, standard size, contrast max., brightness 50%, 9300°, full white pattern.

The 15-pin D-sub connector (male) of the signal cable (IBM systems):

RETURN TO TOP OF THE PAGE

Views

Follow the links to see various views of the monitor and its components.

Front View

Rear View

RETURN TO TOP OF THE PAGE

No. Assignment

1Red video input 9+5V DDC supply

2Green video input 10 Logic ground

3Blue video input 11 Identical output -

connected to pin 10

4Identical output -

connected to pin 10 12 Serial data line (SDA)

5Self-test 13 H. Sync / H+V

6Red video ground 14 V. Sync (VCLK for DDC)

7Green video ground 15 Data clock line (SCL)

8Blue video ground

Installing your Monitor

Front View • Rear View

Front View

Power button switches your monitor on.

MENU MENU button which when pressed will take you to the OSD

controls

(-) Contrast hotkey. When the "(-)" button is pressed, the

adjustment controls for the CONTRAST will show up.

(+) Brightness hotkey. When the "(+)" button is pressed, the

adjustment controls for BRIGHTNESS will show up.

High Bright hot key delivers 4 suitable brightness instantly for text,

internet, game and multimedia.

RETURN TO TOP OF THE PAGE
