Multimedia Base

This Multimedia Base can be used for following Philips Monitors:

105S1x, 105B1x. 107S1x, 107B1x, 109S1x and 109B1x

• Powerful 36 W PMPO stereo sound output

• Front-firing sound for clear voice reproduction and direct sound

• Bass Boost for extra bass enhancement

• Headphone connector for personal listening

• Microphone connector for recording and videoconferencing

• AC adapter included

• Fast Easy Installation: It’s a Snap!

Multimedia Base

6G3B10

monitor with base

Product Number 6G3B10

Technical Specifications

Compatibility

The Multimedia Base is compatible with the following monitor:

• 105S1x

• 105B1x

• 107S1x

• 107B1x

• 109S1x

• 109B1x

Amplifier

• RMS Power 2x1.5W

• PMPO Power 36Watts

• Input Signal Level 340 mV RMS

• Bass Boost

Speakers

• Unit Diameter 2"

• Impedance 4Ω

• Frequency Response 140Hz-20kHz

• Dual Passive Bass Pipes

Option

USB Hub PCUH411 Clip-On Option

Adapter

• Input (6G3B10/74) 108~132VAC, 60Hz,0.1A (10W)

• Output: 9VDC,600mA

Regulatory Approvals

•UL

• CSA

•CE

• TCO ’99

Physical Specifications

• Dim.(Excl. Swivel)(WxHxD)(mm) 239 x 54 x 208

• Dim.(Excl. Swivel)(WxHxD)(inch) 9.4" x 2.1" x 8.2"

• Additional Height for Monitor 28 mm/1.1"

(Multimedia Base-Normal

Base)

• Weight 0.9 kg/2.0 lbs.

• AdditionalWeight for Monitor 0.5 kg/1.1 lbs.

(Multimedia Base-Normal

Base)

• Power Consumption 5Watts

• UPC Code 0 37849 89239 8

• Carton Dimensions (WxHxD)(mm) 239 x 54 x 208

• Carton Dimensions (WxHxD)(inch) 12.8" x 9.8" x 4.5"

• CartonWeight 1.4 kg/3.1 lbs.

Connections and Cables

• Headphone Connection 3.5mm jack

• Microphone Input 3.5mm jack

• Microphone Output 3.5mm jack

• Audio Cable 1.8M,3.5mm jack to 3.5mm jack

This monitor fulfills all Nutek requirements regarding power management

All trademarks acknowledged.

Printed in the U.S.A.

A Division of Philips Electronics NorthAmerica Corp.

99177 KID Design,Philips Consumer Electronics Co.

INTERNET ADDRESS: http://www.pcstuff.philips.com

FAX INFORMATION SYSTEM: (423) 521-4341

TECHNICAL SUPPORT: (877) 835-1838 (USA)

(903) 242-4804 (outside USA)

Multimedia Base

6G3B10

Specifications subject to change without notice

The Multimedia Base

replaces the easily

removable standard

pedestal of the monitor.

The Multimedia Base

increases the height ofthe

product by only1.1"(3cm).
