Philips NP1100/12 Manuale utente

Philips Streamium Network Music Player

Quick start guide

Prepare

Connect

Enjoy

NP1100

np1100_qsg_01eng_non.rhapsody.in1 1 2008-04-28 8:22:37 PM

Please read and accept our Streamium terms & conditions as well as the Software End

User License Agreement that are included in the User Manual.

np1100_qsg_01eng_non.rhapsody.in2 2 2008-04-28 8:22:37 PM

What’s in the box

Remote control

2 x AAA batteries

1 x RCA cable 1 x AC power cable CD-ROM containing

user manual and

software

Streamium Network Music Player NP1100

Before using the remote control:

Insert batteries as shown.

np1100_qsg_01eng_non.rhapsody.in1 1 2008-04-28 8:22:39 PM

Prepare

Front view

a Display

Top view

a STANDBY - ON

Rear view

a LINE OUT (red/white) jacks

b DIGITAL OUT jack

c pjack

d ETHERNET jack

e POWER SUPPLY jack

np1100_qsg_01eng_non.rhapsody.in2 2 2008-04-28 8:22:40 PM

Remote control

bMUSIC SERVICES optional feature available in

some regions

cSETTINGS

dDIM adjust display

eFAVORITE

fSEARCH

g3 4 1 2 navigate

hOK / 2; confirm / play/pause

i)K skip forward

j9 stop

k+ VOL -

lMUTE

mCLEAR

na/A case shift

o3RATE4

pJ( skip back

qHOME

rSHUFFLE random play

sREPEAT

tMUSIC

uINTERNET RADIO

np1100_qsg_01eng_non.rhapsody.in3 3 2008-04-28 8:22:41 PM

Connect

Connect a sound system

Connect the player to the power supply

Connect the player to a home network

Wirelessly steam music from a PC

www

np1100_qsg_01eng_non.rhapsody.in4 4 2008-04-28 8:22:41 PM

This section describes the most commonly used wireless home network setup.

(For instructions on how to create a ‘wired’ connection, refer to the User Manual.)

When you connect the player to a home network with broadband Internet access

You can listen to Internet radio

You can connect to the Internet for firmware updates

START HERE…

Important! For first-time setup, hold ready your network name and network password

or the encryption key.

Connect a sound system

Use the supplied red and white audio cables to connect the AUX IN jacks of the

sound system with the red and white LINE OUT jacks of the NP1100.

Set the source of the sound system to ‘AUX’ and control the sound system as you

normally would.

Connect the player to the power supply

After a short introduction demo, the player shows the [Language] screen.

Press 34 to select the language, then press 2.

The display shows the [Date format] screen.

Press 34 to adjust, then 2to confirm the setting and skip to the next setting.

Follow step 2 to set date format, time format, date, and time.

The display shows the [Network setup] screen.

np1100_qsg_01eng_non.rhapsody.in5 5 2008-04-28 8:22:41 PM

Create a wireless connection to your home network with

broadband Internet access

Press 34 to select [Wireless], then press 2.

Press 2to start searching for your home network.

Press 34 to select your home network with wireless broadband Internet access,

then press 2.

Select [Automatic] > (Enable Proxy?) [No (default)].

The NP1100 displays a confirmation screen that the settings are saved.

Here is how to create a wireless connection any time ‘after’ the initial setup:

Ensure that your wireless access point or wireless router is turned on and connected

to broadband Internet.

Ensure that the NP1100 is turned on and connected to the wireless access point or

wireless router.

On the NP1100, configure the network:

Press HOME.

Press 34, then to select [Settings] > [Network setup] > [Wireless] > [Search

for networks].

Press 34, then to select network.

Enter encryption key (if required).

•

Note For details on how to create wired connection, refer to the User Manual.

np1100_qsg_01eng_non.rhapsody.in6 6 2008-04-28 8:22:41 PM

Wirelessly stream music from a PC

You can wirelessly stream music to the NP1100 from a connected PC, if you install

Windows Media Player 11 on the PC and configure the PC to share your music. (If

Windows Media Player 11 is already installed on the PC, you can skip the installation

section and continue with the configuration.)

Install Windows Media Player 11

On the PC, insert the supplied software CD.

Installation starts.

If installation does not start, click on the Windows Media Player 11 icon in your

Explorer program.

Follow the instructions on the PC to install Windows Media Player 11.

Configure a PC to share music

This chapter shows you how to configure the PC to share music with the NP1100.

Follow the instructions to install Windows Media Player 11.

On the PC, click Start > Programs > Windows Media Player.

In the Windows Media Player interface, click on the Library pull-down menu and select

Media sharing....

•

np1100_qsg_01eng_non.rhapsody.in7 7 2008-04-28 8:22:42 PM

Enjoy

Internet radio

Listen to Internet radio

Ensure that the NP1100 is turned on.

Ensure that the NP1100 is connected to the home network with broadband Internet

access.

Press INTERNET RADIO.

The options are displayed.

To listen to a specific Internet radio station, select option [Search], then use the

alphanumeric buttons to enter the radio station name.

Press 34 to select the station, then press 2.

To return to the Home menu, press HOME.

•

Note Internet radio features require that the NP1100 is connected to a home network

with broadband Internet access.

In the Media sharing... pop-up window, select Share my media, then confirm with OK.

When the NP1100 is connected to your home network, the display shows the

NP1100 with an alert icon:

Click on the NP1100.

Select Allow, then confirm with OK.

On the NP1100, press HOME.

Press 34 to select [Music], then press 2.

The display shows [Searching for UPnP servers...], followed by the list of media

servers.

Press 34 to select the PC, then press 2.

•

np1100_qsg_01eng_non.rhapsody.in8 8 2008-04-28 8:22:42 PM
