Philips SA2323 - 2 GB Digital Player Manuale utente

Philips

Flash audio player

2GB*

SA2323

Your digital music on the move

with MP3, WMA music playback & FM radio

Enjoy your MP3 and WMA music on the move with the Philips SA2325. With direct USB

for fast and easy music and data transfer.

Your music, your data - on the go, everyday

• MP3 and WMA playback

• Voice recording to take notes or record anything, anytime

• Fast downloads from your PC via USB 2.0*

• More music with Digital FM Radio with 10 station presets

Ready to wear, Ready to go

• Enjoy up to 10 hours music playback*

• Direct USB – no cables needed

• Plug and play data

• Drag and drop your songs easily - no software needed

Easy, intuitive music experience

• Easy-to-read black and white LCD display

• Equalizer for optimized sound to suit your music style

• Folder view helps you to find songs easily and quickly

Issue date 2009-11-06

Version: 1.0.5

12 NC: 8670 000 32719

UPC: 6 09585 13992 3

Specifications are subject to change without notice.

Trademarks are the property of Koninklijke Philips

Electronics N.V. or their respective owners.

www.philips.com

Specifications

SA2323/37

Flash audio player

2GB*

Picture/Display

•Backlight

•Linesoftext:2

• Resolution: 32 x 128

•Type:LCD

Sound

• Channel separation: 35 dB

• Equalizer settings: Classic, Jazz, Pop, Rock

• Frequency response: 80 - 18 000 Hz

• Output power (RMS): 2 x 3 mW

• Signal to noise ratio: > 80 dB

Audio Playback

• Compression format: MP3, WAV, Windows

Media™ Audio

• ID3 Tag support: Track title and artist name

• MP3 bit rates: 8-320 kbps and VBR

• MP3 sample rates: 8, 11.025, 16, 22.050, 24, 32,

44.1, 48 kHz

• WMA bit rates: 64-320 kbps

• WMA sample rates: 8, 11.025, 16, 22.050, 32, 44.1,

48 kHz

Audio Capturing

• Audio file format: WAV

• Built-in microphone: mono

• Voice recording: ADPCM

Storage Media

• Built-in memory capacity: 2 GB

• Built-in memory type: NAND Flash

• Mass storage class compliant

• Music memory capacity, WMA: Up to 930 tracks *

Connectivity

• Headphone: 3.5 mm

•USB:High-speedUSB2.0

Convenience

• Firmware upgradeable

• Function: Keypad lock

Accessories

• Batteries: AAA Alkaline

• Headphones: AY3812

• User Guide on CD-ROM

Software

• Device manager: to restore and upgrade

Green Specifications

• Lead-free soldered product

System Requirements

•CD-ROMdrive

• Internet connection: Yes (for access to updated

support documents, manuals, future firmware and

PC software upgrades)

• PC OS: Windows 2000, Me, XP

• USB: Free USB port

Dimensions

• Blister dimensions (WxDxH): 135 x 38 x 195 mm

• Packaging type: Clamshell

• Product dimensions (WxDxH): 31.5 X 23 X 77.8

Power

•Batteriesincluded

• Battery type: AAA / LR03 Alkaline

• Playtime on external battery: Up to 10 hours

Tuner/Reception/Transmission

•TunerBands:FM

•
