Philips PET718/05 Manuale utente

Portable DVD Player

www.philips.com/welcome

User manual

PET714

PET718

A_CCR 2007.12.6 10:52 Page 1

! @ # %$

AV OUT/DVD

A_CCR 2007.12.6 10:52 Page 2

A_CCR 2007.12.6 10:52 Page 3

Important notes for users in the UK

Mains plug

This apparatus is fitted with an approved 13 Amp plug. To change a

fuse in this type of plug proceed as follows:

1. Remove fuse cover and fuse.

2. Fix new fuse which should be a BS1362 5 Amp, A.S.T.A. or BSI

approved type.

3. Refit the fuse cover.

If the fitted plug is not suitable for your socket outlets, it should be cut

off and an appropriate plug fitted in its place. If the mains plug

contains a fuse, this should have a value of 5 Amp. If a plug without a

fuse is used, the fuse at the distribution board should not be greater

than 5 Amp.

Note: The severed plug must be disposed of to avoid a possible shock

hazard should it be inserted into a 13 Amp socket elsewhere.

How to connect a plug

The wires in the mains lead are coloured with the following code: blue

= neutral (N), brown = live (L). As these colours may not correspond

with the colour markings identifying the terminals in your plug, proceed

as follows:

•Connect the blue wire to the terminal marked N or coloured black.

•Connect the brown wire to the terminal marked L or coloured red.

•Do not connect either wire to the earth terminal in the plug, marked

E (or e) or coloured green (or green and yellow).

•Before replacing the plug cover, make certain that the cord grip is

clamped over the sheath of the lead - not simply over the two wires.

Recording and playback of material may require consent. See Copyright

Act 1956 and The Performer’s Protection Acts 1958 to 1972.

A_CCR 2007.12.6 10:52 Page 4

English FUNCTIONAL OVERVIEW

Congratulations on your purchase and welcome to Philips! To fully

benefit from the support that Philips offers, register your product at

www.philips.com/welcome.

Main unit controls ( see figure 1)

1OPEN .....................Open the disc door to insert or remove disc.

2OK ..........................Confirm a selection.

33,4,1,2...........Navigate in a menu.

...........(1 / 2) search backward/forward in a disc at different

speeds.

4AV OUT/DVD.........Switch between DVD and AV OUT modes.

5MENU.....................Enter or exit the disc contents menu.

6J( /§..................Skip to the previous/next chapter, track or title.

;

.........................Start or interrupt playback.

89.............................Stop playback or erase a program.

9IR.............................Remote sensor.

0POWER and CHG..Power and charge indicator.

Left of player ( see figure 1)

!....................Power supply socket.

@AV OUT... ...............Audio/Video output jack.

A_CCR 2007.12.6 10:52 Page 5

FUNCTIONAL OVERVIEW

#...................Volume control.

$...............Headphone jacks.

%ON/OFF...................Switch the power on/off.

Remote controls ( see figure 2)

1SETUP....................Enter or exit the system menu.

2DVD MENU ...........Enter or exit the disc contents menu.

33,4,1,2...........Navigate in a menu.

...........(1 / 2) search backward/forward in a disc at different

speeds.

4OK...........................Confirm a selection.

5PROGRAM.............Enter the program menu.

6DISPLAY ................Display information on TFT during playback.

7PREV/NEXT J( /§Skip to the previous/next chapter, track or title.

8PLAY/PAUSE 2

;

...Start or interrupt playback.

A_CCR 2007.12.6 10:52 Page 6

REMOTE CONTROL

9STOP 9..................Stop playback or erase a program.

0TITLE ......................Display the disc title

!Numeric Keypad (0-9)...Input numbers.

@REPEAT..................Repeat a chapter/track/title.

#A-B... ......................Repeat playback of a specific section on a disc.

$ZOOM.....................Enlarge or reduce a picture or active image on the TFT.

%SUBTITLE ..............Select a subtitle language.

^AUDIO....................Select an audio language when playing a DVD disc or

select an audio mode (Stereo, Mono-Left or Mono-Right)

when playing a VCD/CD disc.

CAUTION

Use of controls or adjustments or performance of procedures

other than herein may result in hazardous radiation exposure

or other unsafe operation.

A_CCR 2007.12.6 10:52 Page 7

INTRODUCTION

Your portable DVD player

Your portable DVD player plays digital video discs conforming to the universal

DVD Video standard. With it, you will be able to enjoy full-length movies with

true cinema picture quality, and stereo or multichannel sound (depending on the

disc and on your playback set-up).

The unique features of DVD-Video, such as selection of soundtrack and subtitle

languages, and of different camera angles (again depending on the disc), are all

included.

What’s more, parental lock lets you decide which discs your children will be able

to see. You will find your player remarkably easy to use with the On-Screen

Display and player display in combination with the remote control.

Unpacking

• Portable DVD player • Remote Control

• Car adaptor (12V) • Audio / Video cable

• User Manual • Warranty

• Quick Start Guide

• AC power adaptor, DSA-9W-09 F (DVE) or AY4132 (PHILIPS) for PET714 only

DSA-20R-12F (DVE) for PET718 only

Placement

• Place the player on a firm, flat surface.

• Keep away from domestic heating equipment and direct sunlight.

• If the player cannot read CDs/DVDs correctly, try using a commonly

available cleaning CD/DVD to clean the lens before taking the player to be

repaired. Other cleaning methods may destroy the lens.

• Always keep the disc door closed to avoid dust on the lens.

•The lens may cloud over when the player is suddenly moved from cold to warm

surroundings. It is then not possible to play a CD/DVD. Leave the player in a warm

environment until the moisture evaporates.

A_CCR 2007.12.6 10:52 Page 8

INTRODUCTION

About Built-in Rechargeable Battery

Precautions related to battery recharge

1Once the battery is fully discharged, immediately recharge it (regardless of

whether you plan to use the battery or not) in order to maximize the battery

life. When the power is low, the battery icon will be shown on the upper-left

corner of the TFT for warning.

2To charge the battery, please directly connect this DVD player to AC mains

and the charge indicator will turn on.

Using and maintaining your rechargeable batteries

1Please make sure you always use only the AC adapter included with the play-

er to recharge your batteries.

2Recharge efficiency will degrade when the environmental temperature drops

below 50oF (10oC) or exceed 95oF (35oC).

3The lasting time of the fully charged battery when a headphone is connected

to the DVD player is approximately 2 hours.

Playable disc formats

In addition to DVD-Video disc, you will also be able to play all Video CDs and

audio CDs (including CDR, CDRW,DVD±R and DVD±RW).

DVD-Video

Depending on the material on the disc (a movie, video clips, a

drama series, etc.) these discs may have one or more Titles,

and each Title may have one or more Chapters. To make access

easy and convenient, your player lets you move between Titles, and also

between Chapters.

CD with JPEG files

You can also view JPEG still photos on this player.

A_CCR 2007.12.6 10:52 Page 9

INTRODUCTION

Video CD

Depending on the material on the disc (a movie, video clips, a

drama series, etc.) these discs may have one or more Tracks, and

tracks may have one or more indexes, as indicated on the disc

case.To make access easy and convenient, your player lets you

move between tracks and between indexes.

Audio CD / MP3 CD

Audio CDs / MP3-CD contain music tracks only. You can play

them in the conventional way through a stereo system using the

keys on the remote control and/or main unit, or via the TV using

the On Screen Display (OSD).
