Philips PET731/12 Manuale utente

PET731Portable DVD player

www.philips.com/welcome

User manual

Content

1Control elements

and functional com-

ponents

1.1 Main unit controls

1.2 Remote Control

2 Introduction

2.1 Your portable DVD

player

2.2 Unpacking

2.3 Placement

2.4 Playable disc formats

2.5 Zero Bright DotTM

3General information

4Charging the units

4.1 Charge the DVD player

4.2 Powering your remote

control

5Start up

5.1 Setup

5.2 Playback DVD

5.3 Playback VCD

5.4 Playback Super (S)-VCD

5.5 Playback Music CD

5.6 Playback Music

MP3/WMA-CD

5.7 Playback Picture-CD

5.8 Playback from SD/MMC

card

6Addition Functions

6.1 DISPLAY Menu

6.2 Connection

6.2.1 Headphone

6.2.2 TV

6.2.3 Component

Video(YPbPr/YCbCr)

6.2.4 SD/MMC card slot

6.2.5 Coaxial

7Troubleshooting

8Technical data

English

Congratulations on your purchase and welcome

to Philips! To fully benefit from the support that

Philips offers, register your product at

www.philips.com/welcome.

1.1 Main unit controls (see figure 1)

1POWER Switch the player on / off

29Press once to stop playback and store the stop

position. Press twice to stop playback completely.

32; Start / pause / resume playback

4J( / )K previous/next track or fast search backward/forward

- VOL +

Volume control

6 OPTIONS Access additional functions

7 MENU Display MENU page

83,4,1,2Up / down / left / right cursor

OK Confirm selection

9 OPEN Open disc door to insert or remove disc

10 POWER•IR•CHG

Power / Remote sensor / charging indicator

11 SD/MMC CARD

Insert SD/MMC card

12 COAXIAL Digital audio output

13 DC IN 12V Power supply socket

14 COMP. OUT Component video output

15 AV OUT Audio/Video output

16 1p 2Headphones jacks

17 RESET Reset the player when it is hanged up

18 Car mounting screw hole

1.2 Remote Control (see figure 2)

1 MENU Display MENU page

23,4,1,2Up / down / left / right navigation key

OK Confirm selection

VOL+ / -Volume control

3 DISPLAY Adjust the display value of the system

4J( Skip to previous chapter, track or title

52; Start / pause / resume playback

69Press twice to stop playback

70- 9Numeric keypad

8 SUBTITLE Subtitle language selector

9 RETURN For VCD menu page

10 A - B To r epeat or loop a sequence in a title

11 SETUP Enter SETUP menu

12 OPTION Access additional functions

13 )K Skip to next chapter, track or title

14 sMute player volume

15 AUDIO Audio language selector

16 ZOOM Enlarge video image

2 Introduction

2.1 Your portable DVD player

Your portable DVD player plays digital video discs conforming to

the universal DVD Video standard.With it, you will be able to enjoy

full-length movies with true cinema picture quality, and stereo or

multichannel sound (depending on the disc and on your playback

set-up).

The unique features of DVD-Video, such as selection of soundtrack

and subtitle languages, and of different camera angles (again depend-

ing on the disc), are all included.What’s more, parental lock lets you

decide which discs your children will be able to see.You will find

your player remarkably easy to use with the On-Screen Display and

player display in combination with the remote control.

2.2 Unpacking

First check and identify the contents of your package, as listed below:

•Portable DVD player • Remote Control

•Car adaptor • User manual

•AC power adaptor • Car headrest mounting kit

•Audio/Video cable • Component cable

2.3 Placement

•Place the player on a firm, flat surface.

•Keep away from domestic heating equipment and direct sunlight.

•If the player cannot read CDs/DVDs correctly, try using a com-

monly available cleaning CD/DVD to clean the lens before taking

the player to be repaired. Other cleaning methods may destroy

the lens.

•Always keep the disc door closed to avoid dust on the lens.

•The lens may cloud over when the player is suddenly moved

from cold to warm surroundings. It is then not possible to play a

CD/DVD. Leave the player in a warm environment until the

moisture evaporates.

2.4 Playable disc formats

In addition to DVD-Video disc, you will also be able to play all

Video CDs, CDs, CDR, CDRW,DVD±R and DVR±RW.

2.4.1 DVD-Video

Depending on the material on the disc (a movie, video clips, a

drama series, etc.) these discs may have one or more Titles, and

each Title may have one or more Chapters.To make access easy

and convenient, your player lets you move between Titles, and also

between Chapters.

2.4.2 Video CD

Depending on the material on the disc (a movie, video clips, a

drama series, etc.) these discs may have one or more Tracks, and

tracks may have one or more indexes, as indicated on the disc

case.To make access easy and convenient, your player lets you

move between tracks and between indexes.

2.4.3 Audio CD / MP3 CD / WMA CD

Audio CDs / MP3 CD / WMA CD contain music tracks only.You

can play them in the conventional way through a stereo system

using the keys on the remote control and/or main unit, or via the

TV using the On Screen Display (OSD).

2.4.4 CD with JPEG files

You can also view JPEG still photos on this player.

2.4.5 DivX video discs

DivX is a popular media technology created by DivX, Inc. DivX

media files contain highly compressed video with high visual quality

that maintains a relatively samll file size. DivX files can also include

advanced media features like menus, subtitles, and alternate audio

tracks. Many DivX media files are available for download online, and

you can create your own using your personal content and easy-to-

use tools from DivX.com.

Offical DivX® Certified product. Plays all versions of DivX® video

(including DivX® 6) with standard playback of DivX® media files.

2.4.6 About SD Memory Card

SD Memory Card is a slim and compact bridge media linking various

kinds of digital equipment through its easy connectivity.The card's

control circuitry allows data to be read and written (in its protec-

tion area) only when appropriate external devices are detected.

Using decoder software, an SD Memory Card-compatible device can

play music, video clips and more without a drive mechanism like

those in CD and DVD players.

2.5 Zero Bright DotTM

Enjoy highest-quality images that are free from annoying blank spots

on the LCD screen. LCD displays commonly have imperfections,

termed as 'bright dots' by the LCD industry.A limited number of

bright dots were once considered an inevitable side effect of LCD

mass production.With Philips' strict quality control procedures

used in our Portable DVD Players, our LCD displays are produced

with zero tolerance for bright dots. Select Portable DVD Players

come with Philips Zero Bright DotTM Policy to guarantee optimal

screen quality.Warranty service varies from region to region. Contact

your local Philips representative for more detailed information.

3General information

Power Sources

This unit operates on a supplied AC adaptor, car adapter, or a

rechargeable battery pack.

•Make sure that the input voltage of the AC adaptor is in line

with the local voltage. Otherwise, the AC adaptor and unit may

be damaged.

•Do not touch the AC adaptor with wet hands to prevent elec-

tric shock.

•When connecting with car power (cigarette lighter) adaptor, be

sure the input voltage of the adaptor is identical with car voltage.

•Unplug the AC adaptor from the outlet when the unit is not

used for long periods of time.

•Hold the plug to disconnect the AC adaptor. Do not pull the

power cord.

Safety and maintenance

•Do not disassemble the unit for laser rays are dangerous to eyes.

Any service should be done by qualified service personnel.

•Unplug the AC adaptor to cut the power if liquid or objects get

inside the unit.

•Take care not to drop the unit or subject it to strong shocks,

which may cause malfunction.

•Do not expose to excessive heat caused by heating equipment

or direct sunlight.

•This product is not waterproof: do not allow your player to be

submersed in water.Water entering the player may cause major

damage.

•Do not use any cleaning agents containing alcohol, ammonia,

benzene, or abrasives as these may harm the player.

Please always use supplied AC/DC adaptor (AY4195)
