Philips PET740/12 Manuale utente

PET740Portable DVD player

www.philips.com/welcome

User manual

Manuel d’utilisation

Manual de usuario

Benutzerhandbuch

Gebruikershandleiding

Manuale dell’utente

Användarhandbok

Brugervejledning

P001-031_PET740_12_Eng 2008.4.28 18:09 Page 1

Important notes for users in the U.K.

Mains plug

This apparatus is fitted with an approved 13 Amp plug.To change a

fuse in this type of plug proceed as follows:

1. Remove fuse cover and fuse.

2. Fix new fuse which should be a BS1362 3 Amp, A.S.T.A. or BSI

approved type.

3. Refit the fuse cover.

If the fitted plug is not suitable for your socket outlets, it should be

cut off and an appropriate plug fitted in its place. If the mains plug

contains a fuse, this should have a value of 3 Amp. If a plug without

a fuse is used, the fuse at the distribution board should not be

greater than 3 Amp.

Note:The severed plug must be disposed of to avoid a possible shock

hazard should it be inserted into a 13 Amp socket elsewhere.

How to connect a plug

The wires in the mains lead are coloured with the following code:

blue = neutral (N), brown = live (L). As these colours may not

correspond with the colour markings identifying the terminals in

your plug, proceed as follows:

•Connect the blue wire to the terminal marked N or coloured

black.

•Connect the brown wire to the terminal marked L or coloured red.

•Do not connect either wire to the earth terminal in the plug,

marked E (or e) or coloured green (or green and yellow).

Before replacing the plug cover, make certain that the cord grip is

clamped over the sheath of the lead - not simply over the two wires.

Recording and playback of material may require consent. See Copyright

Act 1956 and The Performer’s Protection Acts 1958 to 1972.

P001-031_PET740_12_Eng 2008.4.28 18:09 Page 2

English

English - - - - - - - - - - - - - - - - - - - - 6

Français- - - - - - - - - - - - - - - - - - - 32

Español - - - - - - - - - - - - - - - - - - 64

Deutsch- - - - - - - - - - - - - - - - - - - 94

Deutsch Español Français

Norge

Typeskilt finnes på apparatens underside.

Observer: Nettbryteren er sekundert

innkoplet. Den innebygde netdelen er

derfor ikke frakoplet nettet så lenge

apparatet er tilsluttet nettkontakten.

For å redusere faren for brann eller elektrisk

støt, skal apparatet ikke utsettes for regn eller

fuktighet.

P001-031_PET740_12_Eng 2008.4.28 18:09 Page 3

P001-031_PET740_12_Eng 2008.4.28 18:09 Page 4

P001-031_PET740_12_Eng 2008.4.28 18:09 Page 5

Content

1Control elements and functional components . . 8

1.1 Main unit controls . . . . . . . . . . . . . . . . . . . . . . . . . . 8

1.2 Remote Control . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

2 Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

2.1 Your portable DVD player . . . . . . . . . . . . . . . . . . . 10

2.2 Unpacking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

2.3 Placement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

2.4 Playable disc formats . . . . . . . . . . . . . . . . . . . . . . . 11

3General information . . . . . . . . . . . . . . . . . . . . . 13

4Charging the units . . . . . . . . . . . . . . . . . . . . . . . 17

4.1 Charge the DVD player . . . . . . . . . . . . . . . . . . . . . 17

4.2 Powering your remote control . . . . . . . . . . . . . . . 17

5Start up . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

5.1 Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

5.2 Playback DVD . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

5.3 Playback VCD . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

5.4 Playback Super (S)-VCD . . . . . . . . . . . . . . . . . . . . 22

English

P001-031_PET740_12_Eng 2008.4.28 18:09 Page 6

5.5 Playback Music CD . . . . . . . . . . . . . . . . . . . . . . . . 23

5.6 Playback Music MP3-CD . . . . . . . . . . . . . . . . . . . . 24

5.7 Playback Picture-CD . . . . . . . . . . . . . . . . . . . . . . . 25

6Addition Functions . . . . . . . . . . . . . . . . . . . . . . . . . . 27

6.1 DISPLAY Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27

6.2 Connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28

6.2.1 Headphone . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28

6.2.2 TV . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28

7Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29

8Technical data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31

English

P001-031_PET740_12_Eng 2008.4.28 18:09 Page 7

1.1 Main unit controls (see figure 1)

1POWER Switch the player on / off

29Press once to stop playback and store the

stop position. Press twice to stop playback

completely.

32; Start / pause / resume playback

4J( / )K Skip to previous/next track or fast search

backward/forward

- VOL +

Volume control

6 OPTION Access additional functions

7 MENU Display MENU page

83,4,1,2Up / down / left / right cursor

OK Confirm selection

9POWER•IR•CHG

Power / Remote sensor / charging indicator

10 OPEN Open disc door to insert or remove disc

11 1p 2Headphones jacks

12 AV OUT Audio/Video output

13 DC IN 12V Power supply socket

14 RESET Reset the player when it is hanged up

English

Congratulations on your purchase and wel-

come to Philips! To fully benefit from the

support that Philips offers, register your

product at www.philips.com/welcome.

1Control elements and functional components

(illustrations on page 4-5)

P001-031_PET740_12_Eng 2008.4.28 18:09 Page 8

1.2 Remote Control (see figure 2)

1 MENU Display MENU page

23,4,1,2Up / down / left / right navigation key

OK Confirm selection

VOL+ / -Volume control

3 DISPLAY Adjust the display value of the system

4J( Skip to previous chapter, track or title

52; Start / pause / resume playback

69Press twice to stop playback

70- 9Numeric keypad

8 SUBTITLE Subtitle language selector

9 RETURN For VCD menu page

10 A - B To repeat or loop a sequence in a title

11 SETUP Enter SETUP menu

12 OPTION Access additional functions

13 )K Skip to next chapter, track or title

14 sMute player volume

15 AUDIO Audio language selector

16 ZOOM Enlarge video image

English

P001-031_PET740_12_Eng 2008.4.28 18:09 Page 9

English

2.1 Your portable DVD player

Your portable DVD player plays digital video discs conforming

to the universal DVD Video standard.With it, you will be able

to enjoy full-length movies with true cinema picture quality,

and stereo or multichannel sound (depending on the disc and

on your playback set-up).

The unique features of DVD-Video, such as selection of

soundtrack and subtitle languages, and of different camera

angles (again depending on the disc), are all included.What’s

more, parental lock lets you decide which discs your children

will be able to see.You will find your player remarkably easy

to use with the On-Screen Display and player display in com-

bination with the remote control.

2.2 Unpacking

First check and identify the contents of your package, as listed

below:

•Portable DVD player • Remote Control

•Car adaptor • User manual

•AC power adaptor • Audio/Video cable

2.3 Placement

•Place the player on a firm, flat surface.

•Keep away from domestic heating equipment and direct

sunlight.

•If the player cannot read CDs/DVDs correctly, try using a

commonly available cleaning CD/DVD to clean the lens

before taking the player to be repaired. Other cleaning

methods may destroy the lens.

•Always keep the disc door closed to avoid dust on the

lens.

2 Introduction

P001-031_PET740_12_Eng 2008.4.28 18:09 Page 10
