Philips SBM100WHI/00 Manuale utente

www.philips.com/welcome

SBM100

Always there to help you

User Manual

Question?

Contact

Philips

2EN

Contents

1 Important 3

2 Your Portable Speaker 4

Introduction 4

What's in the box 4

Overview of the speaker 4

3 Get started 5

Power supply 5

Turn on/off 5

Select a source 5

4 Play 6

Play from Micro SD card 6

Listen to FM radio 6

Play from an external device 6

Listen through the headphone 7

Adjust volume 7

5 Product information 7

Specications 7

6 Troubleshooting 8

7 Notice 8

3EN

1 Important

• Read these instructions.

• Follow all instructions.

• Do not use this apparatus near water.

• Do not block any ventilation openings.

Install in accordance with the

manufacturer's instructions.

• Do not install near any heat sources such

as radiators, heat registers, stoves, or

otherapparatus(includingampliers)that

produce heat.

• Onlyuseattachments/accessoriesspecied

by the manufacturer.

• Referallservicingtoqualiedservice

personnel. Servicing is required when

the apparatus has been damaged in any

way, such as liquid has been spilled or

objects have fallen into the apparatus, the

apparatus has been exposed to rain or

moisture, does not operate normally, or

has been dropped.

• The battery shall not be exposed to

excessiveheatsuchassunshine,reorthe

like.

• Apparatus shall not be exposed to

dripping or splashing.

• Do not place any sources of danger on the

apparatus(e.g.liquidlledobjects,lighted

candles).

Hearing safety

Caution

•To prevent possible hearing damage, do not listen at

high volume levels for long periods. Set the volume to a

safe level.The louder the volume, the shorter is the safe

listening time.

Be sure to observe the following guidelines

when using your headphones.

• Listen at reasonable volumes for

reasonable periods of time.

• Be careful not to adjust the volume

continuously upwards as your hearing

adapts.

• Do not turn up the volume so high that

you can’t hear what’s around you.

• You should use caution or temporarily

discontinue use in potentially hazardous

situations.

• Excessive sound pressure from earphones

and headphones can cause hearing loss.

Always bring your product to a professional to

remove the built-in battery.

4EN

2 Your Portable

Speaker

Congratulations on your purchase, and

welcometoPhilips!Tofullybenetfromthe

support that Philips offers, register your product

at www.philips.com/welcome.

Introduction

With this speaker, you can:

• listen to FM radio;

• enjoy audio from Micro SD card and other

external devices.

What's in the box

Check and identify the contents of your

package:

• Main unit

• USB cable X 1

• FM antenna X 1

• Quick start guide

Overview of the speaker

• Turn the portable speaker on or off.

b -/+

• Adjust volume.

• Start or pause play.

d /

• Select a track.

• Search within play.

• Tune to FM radio stations.

e S

• Select a source.

f DC 5V

• Recharge the built-in battery.

g BATT

• LED indicator.

h AUX

• Connect an external device.

i MICRO SD

• Micro SD card slot.

• Headphone socket.

5EN

3 Get started

Always follow the instructions in this chapter in

sequence.

If you contact Philips, you will be asked for the

model and serial number of this apparatus.The

model number and serial number are on the

bottom of the apparatus.Write the numbers

here:

Model No. __________________________

Serial No. ___________________________

Power supply

Caution

•Danger of explosion if battery is incorrectly replaced.

Replace only with the same or equivalent type.

•Risk of damage to the speaker. Do not charge through

anything else other than the USB socket of a computer.

The speaker can operate on the built-in

rechargeable battery.

To recharge the built-in battery:

Connect the supplied USB cable to:

• the DC 5V socket on the speaker.

• the USB socket of a computer.

» The power indicator lights up.

» When the battery is fully charged, the

power indicator turns off.

Turn on/off

1 Slide to right.

» The speaker switches to the last

selected source.

2 To turn the speaker off, slide to left.

Select a source

Press Srepeatedly to select an audio source:

Micro SD card, FM tuner, or Aux.

6EN

4 Play

Play from Micro SD card

Note

•Make sure that the Micro SD card contains playable

audio content.

1 Press Srepeatedly to select the Micro SD

card source.

2 Insert a Micro SD card into the card slot.

» Play starts automatically.

• To pause or resume play, press .

• Toselectanaudiole,press / .

• To search during play, press and hold

/ , then release to resume

normal play.

Note

•Due to different materials and product techniques, it

cannot be guaranteed that all Micro SD cards will work

with this speaker.

Listen to FM radio

Note

•Keep the portable speaker away from other electronic

devices to avoid radio interference.

1 Press Srepeatedly to select FM tuner

source.

2 Press and hold / for two seconds.

» The speaker tunes to a station with

strong reception automatically.

3 Repeat step 2 to tune to more radio stations.

To tune to a station manually:

Press / repeatedlyuntilyoundbetter

reception.

Note

•If the signal of the radio station is weak, plug the

supplied antenna into the AUX socket or listen through

the headphone.

Play from an external device

With this speaker, you can also enjoy audio

from an external device.

1 ConnectanAux-incable(notsupplied)to:

• the AUX socket at the back of the

speaker.

• the headphone socket on an external

device.

2 Play audio on the device (see the device's

usermanual).

7EN

Listen through the headphone

Plug a headphone into the socket on the

speaker.

Tip

•When some headphones with Mic are plugged,

you may hear audio from both the speaker and the

headphone. If so, try another headphone.

Adjust volume

During play, press -/+ to adjust volume.

5 Product

information

Note

•Product information is subject to change without prior

notice.

Specications

Amplier

Signal to Noise Ratio >50 dB

Aux Input 600 mV RMS, 22 kohm

Tuner (FM)

Tuning Range 87.5-108.0 MHz

General information

Power supply 5 V 0.6 A;

Built-in battery Lithium battery

Dimensions - Main Unit

(WxHxD)

107 x 71 x 36 mm

Weight - Main Unit 0.1 kg

8EN

6 Troubleshooting

Warning

•Never remove the casing of this device.

To keep the warranty valid, never try to repair

the system yourself.

If you encounter problems when using this

device, check the following points before

requesting service. If the problem remains

unsolved, go to the Philips Web page

(www.philips.com/support).Whenyoucontact

Philips, make sure that the device is nearby

and the model number and serial number are

available.

No power

• Recharge the battery.

No sound

•Adjust volume.

•Check if you have selected the correct

audio source.

•Disconnect the headphones.

No response from the speaker

•Turn on the speaker.

•Recharge the battery.

Poor radio reception

•Increase the distance between the unit and

your TV or VCR.

•Fully extend the FM antenna.

7 Notice

Anychangesormodicationsmadetothis

device that are not expressly approved by

Philips Consumer Lifestyle may void the user’s

authority to operate the equipment.

This product complies with the radio

interference requirements of the European

Community.

Your product is designed and manufactured

with high quality materials and components,

which can be recycled and reused.

When this crossed-out wheeled bin symbol is

attached to a product it means that the product

is covered by the European Directive 2002/96/

EC.

Please inform yourself about the local separate

collection system for electrical and electronic

products.

Please act according to your local rules and

do not dispose of your old products with your

normal household waste. Correct disposal of

your old product helps to prevent potential

negative consequences for the environment and

human health.

Your product contains batteries covered by

the European Directive 2006/66/EC, which

cannot be disposed with normal household

waste.Please inform yourself about the local

rules on separate collection of batteries

9EN

because correct disposal helps to prevent

negative consequences for the environmental

and human health.

Environmental information

All unnecessary packaging has been omitted.

We have tried to make the packaging easy to

separateintothreematerials:cardboard(box),

polystyrenefoam(buffer)andpolyethylene

(bags,protectivefoamsheet.)

Your system consists of materials which can

be recycled and reused if disassembled by

a specialized company. Please observe the

local regulations regarding the disposal of

packaging materials, exhausted batteries and old

equipment.

Note

•The type plate is located on the bottom of the

apparatus.

Specifications are subject to change without notice

SBM100_00_UM_V1.0
