Philips SBM130ORG/00 Manuale utente

www.philips.com/welcome

SBM130

Always there to help you

User Manual

Question?

Contact

Philips

2EN

Contents

1 Important 3

2 Your Portable Speaker 4

Introduction 4

What's in the box 4

Overview of the speaker 5

3 Get started 6

Power supply 6

Turn on/off 6

Select a source 6

4 Play 7

Play from Micro SD card 7

Play from USB device 7

Play from an external device 7

Listen to FM radio 7

Listen through the headphone 8

Adjust volume 8

5 Product information 9

Specications 9

USBplayabilityinformation 9

6 Troubleshooting 10

7 Notice 11

3EN

1 Important

• Read these instructions.

• Follow all instructions.

• Do not use this apparatus near water.

• Do not block any ventilation openings.

Install in accordance with the

manufacturer's instructions.

• Do not install near any heat sources such

as radiators, heat registers, stoves, or

otherapparatus(includingampliers)that

produce heat.

• Onlyuseattachments/accessoriesspecied

by the manufacturer.

• Referallservicingtoqualiedservice

personnel. Servicing is required when

the apparatus has been damaged in any

way, such as liquid has been spilled or

objects have fallen into the apparatus, the

apparatus has been exposed to rain or

moisture, does not operate normally, or

has been dropped.

• The battery shall not be exposed to

excessiveheatsuchassunshine,reorthe

like.

• Apparatus shall not be exposed to

dripping or splashing.

• Do not place any sources of danger on the

apparatus(e.g.liquidlledobjects,lighted

candles).

Hearing safety

Caution

•To prevent possible hearing damage, do not listen at

high volume levels for long periods. Set the volume to a

safe level.The louder the volume, the shorter is the safe

listening time.

Be sure to observe the following guidelines

when using your headphones.

• Listen at reasonable volumes for

reasonable periods of time.

• Be careful not to adjust the volume

continuously upwards as your hearing

adapts.

• Do not turn up the volume so high that

you can’t hear what’s around you.

• You should use caution or temporarily

discontinue use in potentially hazardous

situations.

• Excessive sound pressure from earphones

and headphones can cause hearing loss.

Always bring your product to a professional to

remove the built-in battery.

4EN

2 Your Portable

Speaker

Congratulations on your purchase, and

welcometoPhilips!Tofullybenetfromthe

support that Philips offers, register your product

at www.philips.com/welcome.

Introduction

With this speaker, you can:

• listen to FM radio;

• enjoy audio from Micro SD card, USB

devices, and other external devices.

What's in the box

Check and identify the contents of your

package:

• Main unit

• USB cable X 1

• Aux-in cable X 1

• FM antenna X 1

• Quick start guide

5EN

Overview of the speaker

• Start or pause play.

b S

• Select a source.

c /

• Select a track.

• Search within play.

• Tune to FM radio stations.

d -/+

• Adjust volume.

• Turn the speaker on or off.

f Display panel

g DC 5V

• Recharge the built-in battery.

• Connect a USB storage device.

i MICRO SD

• Micro SD card slot.

• Headphone socket.

k AUX

• Connect an external device.

6EN

3 Get started

Always follow the instructions in this chapter in

sequence.

If you contact Philips, you will be asked for the

model and serial number of this apparatus.The

model number and serial number are on the

bottom of the apparatus.Write the numbers

here:

Model No. __________________________

Serial No. ___________________________

Power supply

Caution

•Danger of explosion if battery is incorrectly replaced.

Replace only with the same or equivalent type.

•Risk of damage to the speaker. Do not charge through

anything else other than the USB socket of a computer.

The speaker can operate on the built-in

rechargeable battery.

To recharge the built-in battery:

Connect the supplied USB cable to:

• the DC 5V socket on the speaker.

• the USB socket on a computer.

» The charging icon is displayed.

» When the battery is fully charged, the

charging icon disappears.

Turn on/off

1 Slide to left.

» The speaker switches to the last

selected source.

2 To turn the speaker off, slide to right.

Select a source

Press Srepeatedly to select an audio source: FM

tuner, Aux, USB device, or Micro SD card.

7EN

4 Play

Play from Micro SD card

Note

•Make sure that the Micro SD card contains playable

audio content.

1 Press Srepeatedly to select the Micro SD

card source.

» [SD] is displayed.

2 Insert a Micro SD card into the card slot.

» Play starts automatically.

• To pause or resume play, press .

• Toselectanaudiole,press / .

• To search during play, press and hold

/ , then release to resume

normal play.

Note

•Due to different materials and product techniques, it

cannot be guaranteed that all Micro SD cards will work

with this speaker.

Play from USB device

Note

•Make sure that the USB storage device contains

playable audio content.

Insert the USB device into the socket.

» [USB] is displayed.

» Play starts automatically.

Play from an external device

With this speaker, you can also enjoy audio

from an external device.

1 Press Srepeatedly to select Aux source.

2 Connect the supplied Aux-in cable to:

• the AUX socket on the speaker.

• the headphone socket on an external

device.

3 Play audio on the device (see the device's

usermanual).

Listen to FM radio

Tune to FM radio stations

Note

•Keep the portable speaker away from other electronic

devices to avoid radio interference.

1 Press Srepeatedly to select FM tuner

source.

2 Press and hold / for two seconds.

» The speaker tunes to a station with

strong reception automatically.

3 Repeat step 2 to tune to more radio

stations.

8EN

To tune to a station manually:

Press / repeatedlyuntilyoundbetter

reception.

Tip

•If the signal of the radio station is weak, plug the

supplied antenna into the AUX socket or listen through

the headphone.

Store FM radio stations automatically

1 In FM tuner mode, press and hold for

two seconds.

» The speaker stores all the FM radio

stations automatically and then

broadcaststherstpresetradio

station.

2 To select a preset radio station, press

repeatedly.

Listen through the headphone

Plug a headphone into the socket on the

speaker.

Tip

•When some headphone with Mic is plugged, you may

hear audio from both the speaker and the headphone.

If so, try another headphone.

Adjust volume

During play, press -/+ to adjust volume.

9EN

5 Product

information

Note

•Product information is subject to change without prior

notice.

Specications

Amplier

Signal to Noise Ratio >50 dB

Aux Input 600mV RMS, 22 kohm

Tuner (FM)

Tuning Range 87.5-108 MHz

General information

Power Supply 5 V 0.7 A

Built-in Battery Lithium battery

Dimensions - Main Unit

(WxHxD)

155 x 71 x 37 mm

Weight - Main Unit 0.2 kg

USB playability information

Compatible USB devices:

• USBashmemory(USB1.1)

• USBashplayers(USB1.1)

• memory cards (requires an additional card

reader to work with this unit; Some multi-

cardUSBreadermaynotbesupported.)

Supported formats:

• USBormemoryleformat:FAT12,FAT16,

FAT32(sectorsize:512bytes)

• MP3bitrate(datarate):32-320Kbpsand

variable bit rate

• WMAv9orearlier

• Directory nesting up to a maximum of 8

levels

• Numberofalbums/folders:maximum99

• Numberoftracks/titles:maximum999

• ID3 tag v2.0 or later

• File name in Unicode UTF8 (maximum

length:16bytes)

Unsupported formats:

• Empty albums: an empty album is an album

thatdoesnotcontainMP3/WMAles,and

is not be shown in the display.

• Unsupportedleformatsareskipped.For

example,Worddocuments(.doc)orMP3

leswithextension.dlfareignoredand

not played.

• AAC,WAV,PCMaudioles

• DRMprotectedWMAles(.wav,.m4a,

.m4p,.mp4,.aac)

• WMAlesinLosslessformat

10EN

6 Troubleshooting

Warning

•Never remove the casing of this device.

To keep the warranty valid, never try to repair

the system yourself.

If you encounter problems when using this

device, check the following points before

requesting service. If the problem remains

unsolved, go to the Philips Web page

(www.philips.com/support).Whenyoucontact

Philips, make sure that the device is nearby

and the model number and serial number are

available.

No power

• Recharge the battery.

No sound

•Adjust volume.

•Check if you have selected the correct

audio source.

•Disconnect the headphones.

No response from the speaker

•Turn on the speaker.

•Recharge the battery.

Poor radio reception

•Increase the distance between the unit and

your TV or VCR.

•Fully extend the FM antenna.

USB device not supported

•The USB device is incompatible with the

unit.Try another one.
