Philips HTR5205/98 Manuale utente

Digital AV Receiver System

Quick Start Guide

Connect

Set up

Enjoy

What’s in the box?

Need help?

User Manual

See the user manual that came with your Philips Digital AV Receiver System.

Online

Go to www.philips.com/welcome.

HTR5205

2007 © Koninklijke Philips N.V.

SGP713/98-EN1

STANDBY-ON SURROUND SOUND TREBLE BASS PROGRAM

TUNING

SOURCE

PHONES MP3 LINE-IN

VOL

Main Unit Remote Control

and 2 batteries

User

Manual

1 centre, 2 front, 2 rear speakers

and subwoofer

FM wire antenna AM/MW

loop antenna

MP3 Line-In cable for

portable audio player

Audio cable

Coaxial cable

2Set up

Adjusting the speakers

APress STANDBY-ON on the main unit to turn it

on.

BPress SURROUND on the remote control.

CPress and hold PROGRAM on the front panel to

access the system setup menu.

To adjust the audio delay for the centre

speaker only:

zPress .or >to until ‘CENTER DELAY’

appears.

zRotate the VOL control to change the delay time.

To adjust the audio delay for the rear

speaker only:

zPress .or >to until ‘REAR DELAY’ appears.

zRotate the VOL control to change the delay time.

DTo confirm all settings, press PROGRAM.

3Enjoy

Start Playback

APress STANDBY-ON on the main unit to turn it

on.

Note Ensure all the audio/video devices are connected

before you start playback.

BTurn on the connected audio/video device.

CPress PLAY on the connected audio/video device.

DPress DISC/DI, RADIO, TV or AUX to select

the preferred audio input source.

Playback from portable audio

player

Listen to audio from your portable audio player by

connecting the device to your main unit.

AConnect the supplied MP3 Line-In cable from the

MP3 LINE-IN socket on the main unit to the

headphone output socket on your portable audio

player.

BPress PLAY on your portable audio player.

CPress MP3 LINE-IN to listen to the playback.

See the accompanying user manual for other

options to ne-tune your speaker settings.

See the accompanying user manual for radio

tuning and other playback settings.

Power cable

htr5205-98_qsg_EN.indd 1htr5205-98_qsg_EN.indd 1 2007-03-30 1:26:45 PM2007-03-30 1:26:45 PM

1Connect

Placement

Proper speakers system placement is important to

ensure optimum sound performance.

APlace the centre speaker above or close to the TV.

BPlace the subwoofer on the floor, at least one meter

away from the TV.

CPlace the front speakers at equal distances from the

TV.

DPlace the rear speakers at normal listening ear level.

Connect the speakers and

subwoofer

Connect the various coloured plugs from the speakers

and subwoofer to the same coloured sockets at the rear

of the main unit.

Connect the radio antennas

Keep the antennas away from the electronic devices to

prevent unwanted interference.

12 mm

AConnect the FM antenna to the FM 75 socket.

Extend the wire and fix its end to the wall.

BUnfold the AM/MW loop antenna and fix the claw

into the slot. Push the tabs and insert the wires into

the AM/MW sockets.

Connect the audio from TV

(optional)

Connect the red and white audio cable from the AUDIO

IN - TV sockets on the main unit to the AUDIO OUT

sockets on your TV.

AUDIO

OUT

AUDIOIN

AUDIO

OUT

AUDIO OUT

Note Press TV on the remote control to get the sound

output from the speakers system when watching the TV

program.

Connect the audio from audio/video

devices (DVD Player, Recorder or Cable/Satellite

Receiver)

Option 1: Using the analogue audio sockets

Connect the red and white audio cable from the AUDIO

IN - AUX sockets on the main unit to the AUDIO OUT

sockets on the other device.

Note Start playback on the device. Press AUX on the

remote control to hear the sound output from the

speakers.

Option 2: Using the 6 Channel In sockets

Connect the audio cables (not supplied) from the 6

CHANNEL IN sockets on the main unit to the six

channel AUDIO OUT sockets on the other device.

Note Start playback on the device. Press DISC/DI on

the remote control repeatedly until ‘DISC 6CH’ appears.

Option 3: Using the Coaxial In socket

Connect a coaxial cable from the COAXIAL socket on

the main unit to the COAXIAL OUT sockets on the

other device.

Note Start playback on the device. Press DISC/DI on

the remote control repeatedly until ‘COAX IN’ appears.

Option 4: Using the Optical In socket

Connect an optical cable (not supplied) from the

OPTICAL sockets on the main unit to the OPTICAL

OUT sockets on the other device.

Note Start playback on the device. Press DISC/DI

on the remote control repeatedly until ‘OPTI IN’

appears.

Main Unit (rear)

SUBWOOFER

FRONT

RIGHT

FRONT

LEFT

REAR

RIGHT

REAR

LEFT

FRONT CENTER

Audio/Video device (rear)

Television (rear)

Audio/ Video device (rear)

Main Unit

(rear)

Main

Unit

(rear)

FM antenna

AM/MW

antenna

Main Unit

(rear)

Audio/ Video device (rear)

Main Unit (rear)

Main Unit

(rear)

Main Unit (rear)

htr5205-98_qsg_EN.indd 2htr5205-98_qsg_EN.indd 2 2007-03-30 1:26:46 PM2007-03-30 1:26:46 PM
