Philips FWM996/78 Manuale utente

Quick start guide

FWM996

MP3 link cable

What’s in the Box?

You should find these items upon opening the box.

Remote Control

Quick Start Guide

User Manual

Quick Start Gulde

User Manual

2 AC power cords

(for the main unit and the

subwoofer each)

FM antenna

AM antenna

DIN cable

1 Microphone

FWM996_78_QSG_V2.0_Eng 3/31/10, 16:171

SetupSetup

Setting the clock

Connect the AM and FM antennas.

Tip

See the User Manual on how to connect

other equipment to this system.

In standby or view clock mode, press PROG/CLOCK (or CLOCK on the

remote control) once.

Press ALBUM/PRESET +/- (or ALBUM +/- (à/ á) on the remote

control) to select clock mode.

Press PROG/CLOCK (or CLOCK on the remote control) again to

activate and adjust clock time.

Press ALBUM/PRESET +/- (or ALBUM +/- (à/ á) on the remote

control) repeatedly to set the hour.

Press S/ T(or TITLE - / + (í/ë) on the remote control)

repeatedly to set the minute.

Press PROG/CLOCK (or CLOCK on the remote control) again to store

the setting.

Connect the speaker cables.

Connect the subwoofer and the main unit

using the supplier DIN cable.

Connect the supplied AC power cords to

the main unit and the subwoofer.

To turn on or off the subwoofer, press

POWER swith on the back of the subwoofer.

Important!

This set can only be operated after the

supplied DIN cable has been connected.

2 2

AC power cord

FM antenna AM antenna

Subwoofer

Front

speaker

(right)

Front

speaker

(left)

Rear speaker

(right)

Rear speaker

(left)

AC power

cord

FWM996_78_QSG_V2.0_Eng 3/31/10, 16:172

Enjoy

Playing a disc

Press OPEN•CLOSE to open the disc tray and load up to two

discs on the individual disc trays.To load the third disc, press DISC

CHANGE.

➜Make sure the label side of each loaded disc is facing up.

Press OPEN•CLOSE again to close the disc tray.

Use DISC 1/2/3 (or CD 1/2/3 on the remote control) to select a

disc for playback.

To stop playback, press 9.

Programming and tuning to radio

stations

Press TUNER repeatedly to select the tuner source.

Press PROG/CLOCK (or PROGRAM on the remote control) for

more than two seconds to program all available stations in order of

waveband.

Press ALBUM/PRESET +/- (or TITLE - / + (í/ë) on the

remote control) until the desired preset station is displayed.

FWM996_78_QSG_V2.0_Eng 3/31/10, 16:173

FWM996_78_QSG_V2.0_1013

Insert the USB device’s USB plug into the socket on the set.

Press USB to select the USB source.

Play the USB’s audio files as you do with the albums/tracks on a CD.

Playing a USB mass storage device

With the Hi-Fi system, you can use USB flash memory (USB 2.0 or USB1.1),

USB flash players (USB 2.0 or USB1.1), memory cards (requires an additional card reader to

work with this Hi-Fi system).

Tip

Detailed playback features and additional functions are described in the

accompany owner's manual.

C2010 Koninklijke Philips Electronics N.V.

http://www.philips.com

Ripping function

Insert a USB mass device with sufficient free space to the USB DIRECT socket on

the set.

Prepare the source to record from.

Press USB RECORD to start ripping.

At any moment, simply press 9to stop ripping.

Enjoy

FWM996_78_QSG_V2.0_Eng 3/31/10, 16:174
