MCD515

Quick Start Guide

What’s in the Box?

You should find these items upon opening the box.

Quick Start Guide

CompositeVideo Cable

PRO

Remote control with two

AA batteries

MW antenna FM antenna

User Manual

MCD515 QUG_Eng 2006.4.26, 9:421

Tip

See the User Manual for otherTV

connection options.

Setting up the TV

Connect the speaker cables.

Connect the MW and FM antennas.

Connect the composite video cable to a TV.

Connect the power cords of the system and TV.

Press SOURCE (DISC on the remote) to select disc source.

Turn on the TV and set it to the correctVideo In channel.

DSC

PROGRAMMODEANGLE A-B

SUB

WOOFER OUT

AUX/

CDR IN

LINE OUT

DIGITAL

OUT

SPEAKERS 8Ω

AM ANTENNA FM ANTENNA

Speaker

(right)

Speaker

(left)

LINE OUT

DIGITAL

OUT

AC power cord

FM wire

antenna

AUDIO

S-VIDEO

VIDEO IN

AUDIO

S-VIDEO

VIDEOIN

TVIN

MW loop

antenna

MCD515 QUG_Eng 2006.4.26, 9:432

Setting the clock

In standby mode, press and hold CLOCK SET on the system.

When the hour digits flash, turn the VOLUME control on the front panel or press VOL+/-

on the remote to set the hours.

Press CLOCK SET again and the minute digits flash.Then turn the VOLUME control on

the front panel or press VOL+/- on the remote to set the minutes.

Press CLOCK SET again to confirm the time setting.

Setting system menu options

Tip

See chapters "Preparations" and "System Menu Options" in the User

Manual for detailed descriptions.

THEATHRE

TUNING

PRESET

DIVX(R) VODDIVX(R) VOD

ITALIAN

MIC SETUP

MCD515 QUG_Eng 2006.4.26, 9:433

Playing a disc

Programming and tuning to radio stations

Press SOURCE (TUNER on the remote) to select tuner source.

Press PROGRAM for more than three seconds to program all available stations in order

of waveband.

Press PRESETí/ëuntil the desired preset station is displayed.

Tip

Detailed playback features and additional functions are described in the

accompany owner's manual.

2005 CKoninklijie Philips Electronics

http://www.philips.com

Press OPEN•CLOSE3to open the disc tray and load in a disc, then press the same

button again to close the disc tray.

➜Make sure the label side of the disc is facing up.

Playback will start automatically. If not press PLAY/PAUSEÉÅ.

To stop playback, press STOP 9.

OPEN CLOSE

•

RDS

CLOCK SETBAND

STANDBY-ON

RECORD

DISPLAY

PDCC-JS/JW-0616

MCD515 QUG_Eng 2006.4.26, 9:434
