MCM 276R

Quick Start Guide

Prepare

Install

Enjoy

Step A

Step

What’s in the Box?

You should find these items upon opening the box.

AM antenna

Quick Start Guide

User Manual

Remote control with

1 x CR2025 battery

Quick start guide User manual

Stand FM antenna

140mm (5.51")

Mounting kit

(1x template, 2 x screws)

MCM275 QSG_-37-Eng 2006.7.26, 13:551

Install

Mounting stand onto the set

Put MCM276R on a flat and firm surface, rear side facing up

As shown, align the stand to the slots at set’s bottom, 4FRONT facing

down

Push the stand down into the slots

PRESS

FRONT

PRESS

Rear connections

Connect the cable of the left speaker to LEFT (red and black) and the cable

of the right speaker to RIGHT (red and black)

Extend the wire antenna and fit it to FM ANTENNA

a. Assemble the loop antenna

b. Fit the plug of the loop antenna to AM ANTENNA

Connect the AC power cord to the wall socket

ANTENNA

Helpful hints:

- For wall mounting, please refer to the User Manual, Appendix: How to mount

your MCM276R onto Walls. You may need assistance from the qualified service

personnel.

AM loop

antenna

Speaker

(left)

Speaker

(right)

FM wire

antenna

AC power cord

MCM275 QSG_-37-Eng 2006.7.26, 13:552

Prepare

Setting the clock

In the standby mode, press and hold DISPLAY/CLOCK on the remote control

➜12 HR or 24 HR appears for the initial clock setting. To select 24-hour clock or

12-hour clock,

a. Press VOLUME +/- once or more

b. Press DISPLAY/CLOCK to confirm

➜ The hours digits start flashing

Hold down or press VOLUME +/- repeatedly to set the hours

Press DISPLAY/CLOCK to confirm

Hold down or press VOLUME +/- repeatedly to set the minutes

Press DISPLAY/CLOCK to confirm

Enjoy

Playing discs

With this system, you can play all pre-recorded audio CDs (CDDA), all finalized audio CD-Rs

and CD-RWs, MP3/WMA-CDs (CD-Rs/CD-RWs with MP3/WMA files)

Press SOURCE once or more to select CD (or CD on the remote control)

Press CD OPEN•CLOSEçto open the CD compartment

Insert a disc with the printed side facing up. Press CD OPEN•CLOSEçagain

to close the compartment

Press ÉÅ to start playback

To stop playback, press STOPÇ

Notes for remote control:

– First, select the source you wish to

control by pressing one of the source

select keys on the remote control (DISC

orTUNER, for example).

–Then select the desired function

(2;,

for example).

IMPORTANT!

– Remove the

protective

plastic tab

before using

the remote

control

Press and hold STANDBY-ON y to switch the set to Standby mode

➜ The display shows the set time

➜ -- --:-- -- flashes by default if you have not set the clock

MCM275 QSG_-37-Eng 2006.7.26, 13:553

Tuning to radio stations

Check you have unfolded the control panel

Insert the USB device’s USB plug into the socket on the set ‘s foldable control panel

Press SOURCE once or more to select USB (or USB on the remote control)

PDCC-JS_JW-0630

Tips

–Detailed playback features and additional functions are described in the accompanied

owner's manual.

–Refer to the user manual for how to use the DOCK functions.

Press SOURCE once or more to select TUNER (or TUNER on the remote control)

Press and hold PROGRAM until AUTO appears

➜ flashes. Available stations are programmed: FM stations followed by AM stations

Press the ALBUM/ PRESET buttons once or more until the desired preset station is

displayed

Playing a USB mass storage device

With the Hi-Fi system, you can use USB flash memory (USB 2.0 or USB1.1),

USB flash players (USB 2.0 or USB1.1), memory cards (requires an additional card reader to

work with this Hi-Fi system).

Play the USB’s audio files as you do with the albums/tracks on a CD

Enjoy

Press STANDBY-ON y to switch off the set

Printed in China

MCM275 QSG_-37-Eng 2006.7.26, 13:554
