Philips MCM309R Manuale utente

What’s in the Box?

You should find these items upon opening the box.

Quick start guide

MCM309R

1 x main unit speaker

2 x speaker stands

FM and AM antennas

Quick Start Guide

Wall Mounting

Quick Start Guide

Wall Mounting

User Manual

6 x screws and dowels

2 x speaker brackets

User manual

Remote control with two

AAA batteries

Docking cable

MCM309R QUG_Eng 2007.1.30, 10:001

Attach the supplied stands to the main unit

and speakers respectively so that they can

stand firmly on a desktop.

Connect the speaker cables.

Tip

– See the User Manual for how to

connect other equipment to this

system.

– See Wall Mounting for detailed

instructions if you want to mount

the system on the wall.

Connect the AM and FM antennas.

Connect the power cable of the system.

WARNING:When you are holding

the speakers for mounting them

on the stands, please DO NOT

press on the speaker cloth directly

to avoid any speaker damage!

CONNECT TO SUB WOOFER

FM Antenna

AM Antenna

Speaker

(right)

Speaker

(left)

AC power

Subwoofer

MCM309R QUG_Eng 2007.1.30, 10:002

Setting the timer

Press and hold CLOCK•TIMER on the front panel of the system for more than

two seconds or press TIMER on the remote to select timer mode.

Press SOURCE (CD or TUNER on the remote) to select the desired source.

Press ALBUM/PRESET +/- 56(56on the remote) repeatedly to set

the hour for the timer to start.

Press TITLE -/+ í/ë(ALBUM/PRESET +/- on the remote) repeatedly to

set the minute for the timer to start.

Press CLOCK•TIMER (TIMER on the remote) to store the start time.

Setting the clock

In active mode, press CLOCK•TIMER (CLOCK on the remote) repeatedly

until the time digits flash.

Press ALBUM-/+

56(56on the remote) repeatedly to set the hour.

Press TITLE -/+ í/ë(ALBUM/PRESET +/- on the remote) repeatedly to

set the minute.

Press CLOCK•TIMER (CLOCK on the remote) again to store the setting.

Important!

–Before setting the timer, ensure that the clock is set correctly.

MCM309R QUG_Eng 2007.1.30, 10:003

Enjoy

Playing a disc

Press LEFT OPEN • CLOSE or RIGHT OPEN • CLOSE on the front panel (L

çor R çon the remote) to open the left or right CD door respectively.

Insert one or more discs with the printed side facing you. Press LEFT OPEN •

CLOSE or RIGHT OPEN • CLOSE on the front panel (L çor R çon the

remote) again to close the CD door.

Use DISC 1/2/3/4 (or CD 1/2/3/4 on the remote control) to select a disc for

playback.

➜Playback will start automatically. If not press ÉÅ.

To stop playback, press 9.

Programming and tuning to

radio stations

Press SOURCE on the front panel of the system repeatedly or

TUNER on the remote to select the tuner source.

Press PROGRAM for more than two seconds to program all

available stations in order of waveband.

Press TITLE -/+ í/ ë(ALBUM/PRESET +/- on the remote)

until the desired preset station is displayed.

///

PDCC-JS/JW-0705

Tip

Detailed playback features and additional functions are described in the

accompany owner's manual.

MCM309R QUG_Eng 2007.1.30, 10:004
