Philips Streamium WACS4500 Manuale utente

Connect/Setup

Enjoy

FAQ

Quick start guide

Read Me First!

ENG

Wireless Music

Center + Station

WACS4500

Setting up connection between the Center and

Station

The first time you set up a Wi-Fi connection, place the

Center and Station side by side on a flat and firm

surface.

Center/Station:

• The screen lights up in a few seconds.

Auto installation/connection starts.

• Both the Center and Station are switched on.

The HD screen appears if the Station is connected to the

Center (it takes about 1-2 minutes).

Connect/Setup

Connect WACS4500 to power supply - connect the

Center first followed by the Station.

Relocate the Center and Station as desired: plug and stream*

a. Press and hold the STANDBY-ON/ECO POWER y button

for 5 seconds to switch the Center to power-saving mode.

b. Unplug the Center or Station and power them up in your

preferred rooms

• You will be able to stream* the hard disk music between the

Center and Station.

IMPORTANT!

• Avoid installing in between thick walls. Separating the Center and

Station by 2 or more walls may cause poor streaming connection.

• For better Wi-Fi reception, you can adjust the Wi-Fi antenna, or

adjust the location of the Center and Station (e.g. shorten the dis-

tance between the Center and Station).

:indicates maximum reception; :indicates minimum recep-

tion.

*Streaming is the process in which data (music in this case) is trans-

ferred from one device to another device or many other devices.

Center

Station

On Center:

Insert the red plug of the red/white audio cable (supplied) to the

red socket LINE OUT R and the white plug to the white sock-

et LINE OUT L.

As shown, insert the L-shaped antenna into the socket WiFi

ANTENNA.

Press and screw the antenna clockwise till it is secured in place.

Mounting the stand onto Station

Align the stand's slots as shown.

Push down the stand till it is locks into place.

On the home audio system:

a. Connect the other end of the audio cable to the AUX IN (or

AUDIO IN) terminals, red plug to the red socket AUX IN R

and white plug to the white socket AUX IN L.

b. To listen to music playback, select AUX mode.

for illustration only

Connect/Setup

Mounting the Wi-Fi antenna onto Center

Connect Center to an existing audio system

You can easily connect Center to your existing home audio systems, such as

audio/video receivers, home theatre systems, mini/micro systems, multi-media

speaker boxes (with built-in amplifier) and audio amplifiers.

WACS4500 WACS4500

Wireless Music

Center + Station

User manual

Manuel d'utilisation

Manual del usuario

Benutzerhandücher

puteS/tcennoC

yojnE

snoitseuQdeksAyltneuqerF

Wireless Music

Center + Station

WACS4500

ediugtratskciuQ

Read Me First!

Wireless Music Center WAC4500

What’s in the box

Wireless Music Station WAS4500

User manual

Quick start guide

1 x Ethernet cable

Remote control and

2 x AA batteries

PC Suite CD

Connect to your PC

Wi-Fi antenna

Audio cable (for Center)

Station’s stand

Power cord

AC/DC adaptor

Play Hard Disk (HD)

You can centrally store up to 1500 audio CDs in the 80GB* hard disk on the

Center.

Enjoy

* Available storage space for music is around 75GB, due to capacity reserved for system purpose

PressÉÅ/OK to start playback

To change your playback options,

a. Press 1once or more times to enter previous option lists

b. Use the navigation controls 3 4 1 2 to select

c. Press OK or 2to confirm

To stop playback, press STOP / 9

Press SOURCE once or more times to select HD

source (or press HD on the remote control)

Use the navigation controls 3 4 1 2 to select your playback

options (Demo tracks are stored under All tracks)

To switch on the Center, press STANDBY-ON y

Tips:

By default, the remote control works with the Center only. To oper-

ate the Station using the remote control,

•Press and hold REFRESH until the Select Device screen appears

on the display of the Center's remote control

•Press the navigation controls 3or 4and 2tto select the Station,

and then press OK

For more information, see User Manual, 4.1 Preparation: Using

the remote control.

REC

PROGRAM

INCR.SURR.

SLEEP

MUSIC BROADCAST

SMART EQ

MUSIC FOLLOWS ME

DIM RDS/NEWS

SCROLL VOL

VIEW

mno

wxyz

pqrs 8

tuv

MARK/UNMARK

DBB

SEARCHCD/MP3-CD HD SOURCE

REPEAT SHUFFLE

abc

SAME GENRE SAME ARTIST

jkl

ghi

CD(RW)

Play CDs (on Center only)

Use the navigation controls 3 4 1 2 to select a track or album

PressÉÅ/OK to start playback

To stop playback, press STOP /9

To remove the CD, press OPEN • CLOSEç

For playback on the Center, you can use:

• All pre-recorded audio CDs

• All finalized audio CDR and CDRW discs

• MP3 & WMA-CDs (CD-R/CD-RW with MP3/WMA files)

Note: Discs with “Digital Rights Management” cannot be played

a. Press OPEN • CLOSEçon the set to open the CD

compartment

b. Insert a disc with the printed side facing up

c. Press OPEN • CLOSEçagain to close the compartment

• Display shows Reading CD

• List of CD tracks appears

(For CD recorded with MP3/WMA music files:

To enter a track list, press 2 on a highlighted file folder)

To find out more about product features and how to activate them

please read the supplied manual:

•User manual: for further details and troubleshooting

•Connect to your PC: to connect to your PC, transfer and manage

your music collection using the Philips Wireless Audio Device

Manager (supplied), set up networks, and playback music between

Center/Station and UPnP-enabled device

Search for your desired tracks/albums

Search by keywords

The keyword should be the first letter or word of the title of the track you

wish to search for. By inputting a keyword, you can quickly find all the items

containing the word (note that it is case sensitive)

Use the navigation controls 3 4 1 2 to enter the desired

option list under tracks, albums, artists or playlists

Press SEARCH on the remote control

• A text box appears

a. Press the alphanumeric keys repeatedly to input the

keywords (maximum 8 characters)

b. To delete an entry before the cursor, press 4

c. Press 1or 2 to move the cursor backward / forward

Press OK to start searching

• Display shows: Searching .... Searching starts from the

beginning of the current option list

• The matched items appear at the top of the list

5000

Stream music between the Center and Station

MUSIC FOLLOWS ME

As you move around at home, let music move with you, either from the

Center to Station or from Station to Center.

On the source unit (Center or Station) where the music is

playing

a. On HD source, select and play the album or playlist you wish to

play on the destination unit

b. Press MUSIC FOLLOWS ME to activate

• The icon appears

On the destination unit (Center or Station) where the music will

continue

a. Check that the destination unit is switched on or is already in standby

mode

b. Press MUSIC FOLLOWS ME

• Selected music continues on the destination unit

• On the source unit, the music stops. The icon disappears

c. To stop MUSIC FOLLOWS ME, press STOPÇ

5000

Stream music between the Center and Station

Tips:

• Always press MUSIC FOLLOWS ME on the source unit before pressing

MUSIC FOLLOWS ME on the destination unit.

•MUSIC FOLLOWS ME will be automatically deactivated if you do not press

MUSIC FOLLOWS ME on the destination unit within 5 minutes

• After MUSIC FOLLOWS ME is activated on the destination unit, you can

select other tracks or source for playback on the source unit.

MUSIC BROADCAST

MUSIC BROADCAST allows you to broadcast music from the Center to

the Stations.

On the Center

a. On HD source, select and play the album or playlist you wish to

broadcast to the Stations

b. Press MUSIC BROADCAST to activate

• The icon appears on the Center and Station, a 5-second countdown

starts

On the Center and Stations

• Selected music starts to play simultaneously

Tips:

• Check that the Stations are switched on or are already in standby mode.

•To broadcast again

Before you press MUSIC BROADCAST, check if you need to deactivate any earlier

broadcasting. If the icon is still active in the Center or Station's display, press STOP/9

on Center. Then, follow Steps 1to 2mentioned above.

• Other functions are unavailable during MUSIC BROADCAST

• To exit MUSIC BROADCAST on a Station, press STOP /9on the Station.

•InMUSIC FOLLOW ME or MUSIC BROADCAST mode, the navigation controls,

SAME ARTIST,SAME GENRE and VIEW buttons do not function. The LCD will dis-

play the following message:

Build your music library on the hard disk in the Center by Recording from CDs

or Importing MP3/WMA files from PC.

Recording from CDs

a. Press OPEN•CLOSE/on the set to open the CD compart-

ment

b. Insert a disc with the printed side facing up

c. Press OPEN•CLOSE/again to close the compartment

• Display shows Reading CD

• List of CD tracks appears

(For CD recorded with MP3/WMA music files: To enter a track list, press

2 on a highlighted file folder)

In the track list screen, press RECORD

• List of tracks with checkboxes appears

To start recording the whole CD, press RECORD. (To rip

part of the CD, press 2or MARK•UNMARK to select/

deselect the tracks to be recorded, and then press RECORD.To

select/deselect all tracks, press and hold MARK•UNMARK)

•CD-Rec appears. Display shows the album name of the track

being recorded

• Center will return to CD mode when recording is complete

To record from another CD, repeat Steps 1 to 3 above.

IMPORTANT!

• It takes some time to convert the recorded CD music to MP3 files.

• Always press and hold STANDBY-ON y to switch the set to ECO POWER (power-saving mode)

before removing its power plug.

• To record a CD during playback (for audio CD only), see User Manual,6.5 HD: Building music

library on Center.

• To record from external source, see User Manual,6.5 HD: Building music library on Center.

• You can edit the track information and import MP3/WMA files from PC using the supplied Wireless

Audio Device Manager (WADM). For details, see the manual Connect to your PC.

• WAC4500 Center allows you to check if the current CD information can be found in the latest

Gracenote®music recognition service database via the Internet. For details, see User Manual

10 Gracenote CD Information

Build a music library on the Center

Altri manuali per Streamium WACS4500

Indice

Altri manuali Philips Impianto stereo

Philips

Philips MC146 Manuale utente

Philips

Philips MC-D370/30 Manuale operativo

Philips

Philips MCB700/05B Manuale utente

Philips

Philips MCB146 Manuale utente

Philips

Philips FW540C Manuale utente

Philips

Philips FW910R Manuale utente

Philips

Philips MCM275/93 Manuale utente

Philips

Philips FWD398 Manuale utente

Philips

Philips MCDB710 Manuale utente

Philips

Philips AZ2402 Manuale utente

Philips

Philips MCB146 Manuale utente

Philips

Philips Magnavox FW 338C Manuale utente

Philips

Philips FWD397/98 Manuale utente

Philips

Philips Compact Component System Manuale utente

Philips

Philips SWA3102W Manuale utente

Philips

Philips FWM185/BK Manuale utente

Philips

Philips HTS4600/05 Manuale utente

Philips

Philips FWM462 Manuale utente

Philips

Philips MCM166/12 Manuale utente

Philips

Philips MCM204B Manuale utente

Philips

Philips NTRX700X/78 Manuale utente

Philips

Philips BTB2465 Manuale utente

Philips

Philips MC150 Manuale utente

Philips

Philips MCM108/55 Manuale utente

Manuali Impianto stereo popolari di altre marche

LG CM3330B Manuale utente

Sony

Sony SS-CEP50 Manuale utente

Cetacea Sound

Cetacea Sound CVS-II Manuale utente

Aiwa

Aiwa XR-H66MD Manuale utente

Denon

Denon UCD-250 Manuale utente

Sanyo

Sanyo DC-MX41i Manuale utente

Sharp

Sharp CD-ES600V Manuale utente

Exibel

Exibel BDX600-UK Manuale utente

Sanyo

Sanyo DC-F320 Manuale utente

Sharp

Sharp CD-C462 Manuale utente

Onkyo

Onkyo CBX 300 - CD / MP3 Clock Radio Manuale utente

Aiwa

Aiwa XR-EM70 Manuale utente

Cyrus

Cyrus Lyric Manuale utente

Philips/Magnavox

Philips/Magnavox Magnavox FW 62C Manuale utente

RCA

RCA RS3965SB Manuale utente

Sharp

Sharp XL-UH240 Manuale utente

LG FB165DAB Manuale utente

Sanyo

Sanyo DC-UB1475M/XE/UK Manuale utente
