Philips Streamium WACS700 Manuale utente

Connect/Setup

Enjoy

Wireless Music System waCS700

Quick start guide

1Read Me First!

QUG-Eng 2005.6.29 15:07 Page 1

Connect to

your PC

waCS700

User manual

waCS700

Mut e

Program

RDS/News

Incr.Sur r. Like Artist Like Genre DB B

Music Match-genr e

Follows MeFollows Me

Repeat

Dim Sleep

View Scrol l

VOL

Server

Tuner

/Aux

def

gh i jkl mn o

pqrs 8

tuv 9

System requirem ents:

• Windows 98 ( SE) / ME / 200 0 / XP

( Home and Profes sional)

• Pentium Class 3 00MHz process or or high er

• CD-ROM drive

• Ethernet po rt

• Free hard d isk space 500M B

f or the software

CD contains:

• Digital Med ia Manager

• Network Set up

• Manual & FAQs

• Registration & Upgrades

Wireless Music Center

PC installer

Quick start guide

waCS700

Connect/Setup

Enjoy

Wireless music center

What’s in the box

Wireless music station

User manualQuick start guideStation’s remote control

1xCR2025 batteries

Center’s remote control

4xAAA batteries

1 x Ethernet cable 2 x Mounting kit

for center & station

Center

Station

2 x FM wire antenna

PC installer

Connect to your PC

QUG-Eng 2005.6.29 15:07 Page 2

After you power up WACS700, the WiFi connection will start automatically

between WAC700 Center and WAS 700 Station.

Set up Wi-Fi connection between Center and Station

The first time you set up the Wi-Fi connection, place

WAC700 Center and WAS700 Station side by side

on a flat and firm surface.

Connect WACS700 to power supply, first the Center

and then the Station

Center/Station: • The screen lights up.

Auto installation/connection starts.

•You will enter HD (Harddisk) mode

when the installation/connection

is finished.

Relocate Center and Station as desired: plug and stream

•Simply unplug your Center or Station and power them up

in different rooms.

•You will be able to move the harddisk music between

Center and Station.

IMPORTANT!

•Avoid thick walls. Your Center and Station should never be blocked by 2 or more walls.

•Keep your Center and Station away from the source of interference, for example: plasma TVs, microwave

ovens, DECT phones, bluetooth devices, cordless phones, other Wi-Fi products.

•Adjust the location of your Center and Station according to the reception status of Wi-Fi signals

: indicates maximum reception; : indicates minimum reception

•For wall mounting, you need to ask for help from the qualified person. For details, see User Manual,

Appendix: How to mount your Center and Station onto walls.

Plug & stream

•Make sure you have powered up Center before powering up Station.

Connect/Setup

After you power up WACS700, the Wi-Fi connection will start automatically

between WAC700 Center and WAS700 Station.

Center

Station

QUG-Eng 2005.6.29 15:07 Page 3

After you power up WACS700, the WiFi connection will start automatically

between WAC700 Center and WAS 700 Station.

Press OK or 2to start playback

To change your playback options,

a. press 1once or more to enter previous option lists

b. Use the navigation controls 3 4 1 2 to select

c. Press OK or 2to confirm

To stop playback, press STOP / 9

Play Harddisk (HD)

On WAC700 Center's 40GB* hard disk, you can centrally store up to 750 audio CDs.

On a connected WAS700 Station, you can play all the music stored on the hard disk.

Press STANDBY ON to switch on the Center or Station

Press SOURCE once or more to select HD source on the Center or Station

•You will enter HD (Harddisk) mode.

Tips:

•Demo tracks are stored under Playlists.

IMPORTANT!

•Remove the protective plastic tab before using the Station’s remote control.

•By default, Center’s remote control works with Center only. To operate

Station using Center’s remote control,

a. Press and hold REFRESH until the select screen appears on the display of

Center’s remote control.

b. Press the navigation controls 3 or 4and 2to select Station

Enjoy

Use the navigation controls 3 4 1 2 to select your playback options

* Actual free space is 35GB or less, due to the firmware, music CD database and demo tracks stored.

QUG-Eng 2005.6.29 15:07 Page 4

Move between Center and Station

Up to 5 WAS700 Stations can be connected to WAC700 Center. Via Wi-

Fi, music can move between Center and Stations. Even in different places

of your house, you and your family will enjoy and share music with ease.

MUSIC FOLLOWS ME

As you move around at home, let music move around you,

from Center to Station or from Station to Center.

On the first unit (Center or Station), where music will leave

During HD playback, press MUSIC FOLLOWS ME to activate

•The icon appears.

On the second unit (Center or Station), where music will continue

Within 5 minutes, press MUSIC FOLLOWS ME

•Selected music stops on the first unit and continues on the second unit.

The icon disappears.

To stop MUSIC FOLLOWS ME, press STOP /9on the second unit

MUSIC BROADCAST

MUSIC BROADCAST allows you to broadcast musicfrom Center to Station(s).

On Center

During HD playback, press MUSIC BROADCAST to activate

•The icon appears on Center and Station. 5-second countdown starts.

On Center and Station

•Selected music plays simultaneously after 5-second countdown.

Tips:

•Check you have selected HD or AUX source on the Station(s) or have switched the Station(s)

to standby mode.

•To broadcast again

Before you press MUSIC BROADCAST, check if you need to deactivate any earlier

broadcasting. If the icon is still active in Center or Station’s display. Press STOP / 9on Center.

Then, follow the above steps 1-2.

•During broadcasting, there may be slight playback delay between Center and

Station if you power them up for the first time.

Tips:

•Check you have selected HD, CD or AUX

source on the second unit or have switched

the unit to Standby mode.

•You must press MUSIC FOLLOWS ME

on the first unit before pressing MUSIC

FOLLOWS ME on the second unit.

QUG-Eng 2005.6.29 15:07 Page 5

CD(RW)

Build music library on Center

You can store up to 750 audio CDs on Center’s 40GB harddisk by ripping

CDs, Importing from or PC Recording from Radio or External source

Ripping CDs

Insert a CD into Center’s CD loader, CD graphic printed

side facing you.

•Reading CD appears.

•Audio CD: List of tracks appears

MP3/WMA: List of file folders appears

• To enter a track list, press 2 on a highlighted file folder

In the screen of track list, press RECORD

•Display shows ripping status of the CD

•List of track checkboxes appears.

Press MARK • UNMARK once or more to select or deselect

the tracks to be recorded

• To select/deselect all tracks, press and hold MARK • UNMARK

To select Rec speed (1x, 4x) and Rec quality,

a. Press MENU.

b. Use the navigation controls 3 4 1 2 to enter Settings menu

c. In Settings menu, use the navigation controls 3 4 1 2 to select

To start recording, press RECORD or OK

• CD-Rec appears. Display shows the album name

of the track being recorded.

To stop recording, press STOP / 9

Center

IMPORTANT!

•It takes some time to convert the ripped tracks into MP3 files. During the

conversion, the ACTIVE indicator lights up green. Do not remove Center's

power plug from the wall outlet while the ACTIVE indicator is on and

within 15 minutes after the indicator is off.

ACTIVE

QUG-Eng 2005.6.29 15:07 Page 6

To find your ripped tracks

After MP3 conversion is completed (the ACTIVE indicator is off), you can

find and playback all the ripped tracks in Albums.

Select HD source

In Albums, use the navigation controls 3 4 1 2 to find the album

of recorded tracks.

Importing from your PC

See the manual Connect to your PC

Recording from Radio or External source

A maximum of 3-hour recording can be made from the radio or external

source. See User manual, Build music library on Center

Play CDs (on Center only)

For playback on the Center you can use:

• All pre-recorded audio CDs

• All finalized audio CDR and CDRW discs

• WMA & MP3-CDs (CD-R/CD-RW with MP3/ WMA files)

Insert a CD into Center’s CD loader, CD graphic printed side facing you.

Use the navigation controls 3 4 1 2 to select a track or album.

To start playback, press 2or OK

To stop playback, press STOP / 9

To remove the CD, press EJECT

Center

ACTIVE

QUG-Eng 2005.6.29 15:07 Page 7

Listen to FM Radio

Check you have connected the supplied FM wire antenna to your

Center and Station (see User manual, Installation)

Press SOURCE once or more to select TUNER source on the Center

or Station (on the remote control, press TUNER/AUX once or more)

To select Autostore radio

a. press MENU

b. Use the navigation controls 3or 4and 2to select

•Display shows: Autostore Please wait...

• You can store up to 40 preset radio stations in the memory

(including a maximum of 10 RDS stations). After all stations are stored,

the first autostore preset station will then automatically play

Press 1to enter the list of presets

Use the navigation controls 3or 4and 2to select your desired station

To enjoy all the product features, read the manuals:

•User manual: find out details on how to use Center and Station.

•Connect to your PC: find out how to connect to a PC, configure

networks, and how to transfer and manage your music collection using

Philips Digital Media Manager (DMM).

www.philips.com/support

Need help?

3141 075 207611

2005 © Koninklijie Philips Electronics N.V.

www.philips.com

QUG-Eng 2005.6.29 15:07 Page 8
