Philips Beauty Initial HP4643/00 Manuale utente

Initial

HP4643

/00

D C

2345

ENGLISH 6
FRANÇAIS 11
BAHASA MALAYSIA 16
BAHASA INDONESIA 21
 26
30
36
41
51
56
HP4643
/00
»HQYdG

Introduction

This new Philips Initial straightener has been specially designed for fast

and easy straightening.The Initialstraightener has a short heat-up time

so you can quickly start straightening.The ceramic-coated plates ensure

easy gliding through the hair and ultra-smooth results.The comb on the

straightener offers extra convenience by guiding the hair.

General description (fig. 1)

ACool tip area

BCeramic-coated plates

CHanging loop

D'Power on' pilot light

Important

Read these instructions for use carefully before using the appliance and

save them for future reference.

◗The HP4643 can be used at 100-240 volts AC.

◗For additional protection, we advise you to install a residual

current device (RCD) with a rated residual operating current not

exceeding 30mA in the electrical circuit supplying the bathroom.

Ask your installer for advice.

◗Keep this appliance away from water! Do not use this product

near or over water contained in baths, washbasins, sinks etc.

When used in a bathroom, unplug the appliance after use since

the proximity of water presents a risk, even when the appliance is

switched off.

◗This appliance gets very hot. Prevent the hot surfaces of the

appliance from coming into direct contact with the hands, eyes,

ears, face and neck. Do not touch the straightening plates when

the appliance is switched on.The plastic parts near the

straightening plates also become very hot during use, except for

the cool tip areas.

◗Keep the straightening plates clean and free of dust, dirt, styling

spray and gel. Never use the appliance in combination with styling

mousse, styling spray, gel etc.

ENGLISH6

◗Keep the appliance out of the reach of children.

◗If the mains cord of this appliance is damaged, it must always be

replaced by Philips or a service centre authorised by Philips in

order to avoid hazardous situations.

◗Always return the appliance to a service centre authorised by

Philips for examination or repair. Repair by unqualified people

could cause an extremely hazardous situation for the user.

◗Always unplug the appliance after use.

◗Wait until the appliance has cooled down before storing it.

◗This appliance is suitable for use abroad. It automatically adjusts

to the required voltage. Use a plug adapter of the type suitable

for the wall sockets in the country you are visiting to connect the

appliance to the mains.

◗The plates have a ceramic coating.This coating will wear in the

course of time.When this happens, the appliance will still function

normally.

Styling your hair

Step 1: washing your hair

Everybody wants shiny and beautiful hair. A good hair-washing routine

can help to achieve this.

◗When washing your hair, wet your hair thoroughly for 30-60

seconds.

◗Pour some shampoo into the palm of your hand. Spread it

between your hands and distribute it evenly through the hair.

◗Gently massage your hair and scalp. Do not rough up the hair or

pull long hair up onto the scalp, as this may cause tangles.

◗Massage your scalp with your fingertips.This stimulates blood

circulation and is gentler to the hair cuticles.

◗Rinse your hair thoroughly, as poor rinsing can result in dull hair.

Finish with a cold rinse for extra shine.

ENGLISH 7

Step 2: drying your hair

To get super-smooth results, it is Initialto prepare your hair for

straightening. Dry you hair properly with a hairdryer to ensure a

professional, smooth finish.

◗After washing, squeeze excess water out of the hair with your

hands and then towel-dry the hair. Use a comb to disentangle hair

gently from the roots to the tips.

◗Divide the hair into sections by means of clips, starting at the

back.

◗Dry each section by pulling a straightening brush down the hair

length while following the brush with the hairdryer, with its

nozzle pointing towards the hair ends.

◗When you have finished drying each section, set the hairdryer to

the cold setting for a final cold shot.This closes the cuticles and

leaves your hair glossier.

BTip: Philips Protect hairdryers have a lower drying temperature and a

stronger airflow than regular dryers.Thanks to this combination, they dry

just as quickly as regular hairdryers but in a gentler way.

Step 3: straightening your hair

Straighteners are powerful styling tools and should always be used with

care.

1Insert the plug into the wall socket.

2The 'power on' pilot light goes on (fig. 2).

3Let the appliance heat up for 2-3 minutes.

Never leave the appliance unattended when it is plugged in.

Never put the appliance on a surface that is not heat-resistant when

it is heating up and when it is hot.

4Comb or brush your hair so that it is disentangled and smooth

(fig. 3).

ENGLISH8

Use a comb to divide the hair into sections. Do not put too much hair

in one section.

BTip: it is better to section off the crown area and to straighten the hair

underneath first.Then straighten the top area.

5Take a section that is not wider than 5 cm. Place it between the

straightening plates and press the handles of the appliance firmly

together.

6Slide the straightener down the length of the hair for 5 seconds,

from root to hair end, without stopping to prevent overheating

(fig. 4).

7Repeat this process after 20 seconds until you have achieved the

desired look.

8Allow your hair to cool down. Do not comb or brush it before it

has cooled down, as this would ruin the hairstyle you have just

created.

Creating a bob

1To create nicely shaped bobs, follow the instructions described in

the section 'Straightening your hair', but turn the appliance

inwards once you reach the hair ends (fig. 5).

2Hold the appliance in this position for a few seconds and then

release it.

Creating a flicked hairstyle

1To create flicks, follow the instructions in the section

'Straightening your hair', but turn the appliance outwards once

you reach the hair ends (fig. 6).

Cleaning

1Unplug the appliance.

2Let the appliance cool down completely on a heat-resistant

surface.

3Clean the appliance with a damp cloth.

ENGLISH 9

Storage

Never wind the mains cord round the appliance.

1Make sure the appliance is unplugged.

2Let the appliance cool down on a heat-resistant surface before

storing it.

Guarantee & service

If you need information or if you have a problem, please visit the Philips

Web site at www.philips.com or contact the Philips Customer Care

Centre in your country (you will find its phone number in the

worldwide guarantee leaflet). If there is no Customer Care Centre in

your country, turn to your local Philips dealer or contact the Service

Department of Philips Domestic Appliances and Personal Care BV.

Troubleshooting

If problems should arise with your straightener and you are unable to

solve them by means of the troubleshooting guide below, please

contact the nearest Philips service centre or the Philips Customer Care

Centre in your country.

Problem

◗The appliance does not work at all.

1Perhaps there is a power failure or the socket is not live. Check if

the power supply is working. If it is, check whether the socket is

live by plugging in another appliance.

2If the mains cord of this appliance is damaged, it must always be

replaced by Philips or a service centre authorised by Philips in

order to avoid hazardous situations.

ENGLISH10
