Philips M555 Scheda informativa del prodotto

M550

M555

www.philips.com/welcome

Short user manual

Important safety instructions

Warning

•The Electrical network is classified as hazardous.The

only way to power down the charger is to unplug the

power supply from the electrical outlet. Ensure that the

electrical outlet is always easily accessible.

•Refer to safety information before using the product.

•This product complies with European R&TTE directive

1999/5/EC

•Use only the power supply listed in the user instructions.

•Use only the batteries listed in the user instructions.

•Do not allow the product to come into contact with

liquids.

•Risk of explosion if battery is replaced by an incorrect

type.

•Dispose of used batteries according to the instructions.

•When the handset rings or when the handsfree is

activated, keep the handset away from your ear to

avoid hearing damage.

1Overview

Microphone

Earpiece

Loudspeaker

(back of the

handset)

In call

Phonebook

Access the redial list.

Increase the volume.

Decrease the volume.

End calls.

Turn the speaker on/off.

Mute/unmute the microphone.

Enter a pause (press and hold).

Standby

Access the main menu.

Access the redial list.

Phonebook

Call log

Make and receive calls.

Make an intercom call (press and hold).

For multi-handset version only.

Switch the handset on or off (press and hold).

Lock the keypad (press and hold).

Make and receive calls.

In menu

Confirm / Select / Enter the option menu.

Cancel

Up / down

Exit menu.

In text input

Delete a character.

Delete all characters (press and hold).

Enter a space.

Switch upper/lower case (press and hold).

Display icons

The number of bars indicates the connection

status between the handset and base station.

The more bars are shown, the better the signal

strength is.

It remains steadily on when browsing answered

incoming calls in the call log.

It indicates an outgoing call in the redial list.

It flashes when there is a new missed call or when

browsing new missed calls. It remains steadily on

when browsing the missed calls in call log that are

already read.

It flashes when receiving incoming call. It

remains steadily on during a call.

The speaker is on.

The ringer is off.

Answering machine: it flashes when there is

a new message or when the memory is full.

It remains steadily on when the telephone

answering machine is turned on.

Voice messages indicator: flashes for new

messages, is steady for reviewed messages.

* This is network dependent

It displays when you scroll up/down a list or

increase and decrease the volume.

There are more digits on the right. Press to

read.

ECO+

The ECO+ mode is activated.

Find handset

Display icons

2Connect

2 1

3Get started

Configure your phone Charge your phone

Charge 8 hours

1 The batteries are pre-installed in the handset. Pull the

battery tape off from the battery door before charging.

2 When using your phone for the first time, you see a

welcome message (country dependent).

3 Set the country and language if prompted.

4 Set the date and time.

•If the time is in 12-hour format, press /key to

select [am] or [pm] (country dependent).

Charge your handset by docking it in either direction.

> 75%

50% - 75%

25% - 50%

< 25%

Flashing: low battery

Scrolling: charging in progress

4Enjoy

Phonebook

Add record

1 Press > [Phonebook] > [Add new].

2 Follow on-screen instructions.

Call from the phonebook

1 Press .

2 Select a record and press .

Direct access memory

You have 2 direct access memories (Keys 1 and 2).

To dial the saved phone number automatically, press

and hold on the keys in standby mode.

Depending on your country, keys 1 and 2 are

preset to [1_voicemail] (voice mail number) and

[2_info svc] (information service number) of your

network operator respectively (network dependent).

Call log

Call from the call log

1 Press .

2 Select a record and press .

View record

Press > > [View].

Save record

1 Press > > [Save number].

2 Follow on-screen instructions.

Delete record

1 Press > > [Delete].

2 Follow on-screen instructions.

Redial list

Call from the redial list

1 Press .

2 Select a record and press .

Save record

1 Press > > > [Save number].

2 Follow on-screen instructions.

Delete record

1 Press > > > [Delete].

2 Follow on-screen instructions.

Telephone answering machine

(for M555 only)

Record an announcement

1 Press > [Answ. Machine] >

[Announcement].

2 Follow on-screen instructions.

Listen to the incoming messages

Press > [Answ. Machine] > [Play], then

press to confirm.

Delete an incoming messages

1 When you listen to the message, press to

enter the options menu.

2 Select [Delete], then press to confirm.

egister additional handsets

You can register up to 3 additional handsets to the

base station.

1 Press > [Services] > [Register].

2 Press and hold on the base station for 5

seconds.

3 Enter the system PIN (0000).

4 Press to confirm the PIN.

» Registration is complete in less than 2 minutes.

ECO+ mode

It eliminates radiation in standby mode (causes 2

seconds ring delay, 50% shorter standby time).

1 Press > [Phone setup] > [ECO+ mode].

2 Follow on-screen instructions.

Technical data

Battery

•Philips: 2 x AAA NiMH 1.2V Rechargeable

550mAh batteries

Use only the supplied batteries.

Adapter

Base and charger:

•Philips:

S003EB06000302:

Input: 100-240V~ 50/60Hz 0.2A;

Output: (i)6Vdc 0.3A, (ii)6Vdc 0.2A

Phonebook with 100 entries

Call log with 50 entries

Talk time: 16 hours

Standby time: 250 hours

Note

•YoucaninstallaDSL(digitalsubscriberline)lterto

prevent noise and caller ID problems caused by the

DSL interference.

•YoucanndtheDeclarationofConformityon

www.p4c.philips.com.

Frequently asked questions

No signal bar is displayed on the screen.

•The handset is out of range. Move it closer to the

base station.

•If the handset displays [Register your handset],

the hands).

If I fail to pair (register) the additional handsets to

the base station, what do I do?

Your base memory is full. Access > [Services]

> [Register your handset] to unregister the

unused handsets and try again.

My handset is in searching status, what do I do?

•Make sure that the base station has power supply.

•Register the handset to the base station.

•Move the handset closer to the base station.

I cannot change the settings of my voice mail, what

do I do?

The voice mail service is managed by your service

provider but not the phone itself. Contact your

service provider to change the settings.

No display

•Make sure the batteries are charged.

•Make sure there are power and phone

connections.

The handset on the charger does not charge.

•Make sure the batteries are inserted correctly.

•Make sure the handset is placed properly on the

charger.The handset event LED flashes for a few

seconds when charging.

•Make sure the docking tone setting is turned on.

When the handset is placed correctly on the

charger, you can hear a docking tone.

•The charging contacts are dirty. Disconnect the

power supply first and clean the contacts with a

damp cloth.

•Batteries are defective. Purchase new ones with

the same specifications.

Bad audio (crackles, echo, etc.)

•The handset is nearly out of range. Move it closer

to the base station.

•The phone receives interference from the nearby

electrical appliances. Move the base station away

from them.

•The phone is at a location with thick walls. Move

the base away from them.

The handset does not ring.

Make sure the handset ringtone is turned on.

The caller ID does not display.

•The service is not activated. Check with your

service provider.

•The caller’s information is withheld or unavailable.

For information, refer to the extended user

documentation online.

www.philips.com/support

When this crossed-out wheeled bin symbol is

attached to a product it means that the product is

covered by the European Directive 2002/96/ EC.

2013 © WOOX Innovations Limited.

Philips and the Philips’ Shield Emblem are registered

trademarks of Koninklijke Philips N.V. and are used

by WOOX Innovations Limited under license from

Koninklijke Philips N.V.

UMS_M550-555

90_EN_V2.0

WK13452

0168
