Philips 20MDRF20 Manuale operativo

There are many ways to connect your new TV /DVD to your other equipment.This Quick-Use

Guide shows the easiest, most common connections for the TV / DVD.

OUT

ANT.ANT.

1Disconnect all equipment from the power outlets. Connect the equipment to the power outlets

only after you have finished hooking up everything. Never make or change connections with equipment

connected to the power outlet.

2If you do not have a Cable Box, simply connect your Antenna or Cable TV signal directly to the

ANT(enna) jack on the rear of the TV/ DVD.

3Or, if you do have a Cable Box or Satellite Receiver, first connect the Cable TV or Satellite

signal to the IN jack on the Cable Box or Satellite Receiver. Then, use an RF coaxial cable (not

supplied) to connect the OUT jack of the Cable Box or Satellite Receiver to the ANT(enna) jack

on the TV/ DVD. To view any channel, set the TV / DVD to the output channel of the Cable Box or Satellite

Receiver (channel 3 or 4).Then, select channels at the Cable Box or Satellite Receiver.

4When all connections are complete, plug the power cord of the TV /DVD into an active

power outlet.

5Press the STANDBY-ON button on the TV /DVD or its remote to turn on the TV/ DVD. The

first time you turn on the TV/ DVD, you should complete the TV / DVD setup. See the other

side of this Quick-Use Guide for details.

Quick-Use Guide

Playing a Disc

1Press STANDBY-ON to turn on the TV / DVD.

2Press OPEN/CLOSE /to open the disc tray.

This will switch the unit to DVD mode automatically.

Put a Disc in the tray with the label facing up and the

shiny side facing down.

3Press PLAY Bto close the tray. Playback may

start automatically. If not, press PLAY Bagain.

If a DVD Disc menu appears, use the 1 234, ENTER, or

Number buttons to select features or start playback.

Follow the instructions in the menu.

4To stop playing the Disc, press STOP 9.

20MDRF20 / 8239 210 98371

OEMN02319 TD812HC*****

Setting Up the TV/DVD the First Time

1Press STANDBY-ON to turn on the TV /DVD.

2Press ENTER repeatedly to select English, French,

or Spanish as the language for TV / DVD setup menus.

3Press 3or 4to select AUTO PRESET. Then press

ENTER to set up TV channels. When setup is

complete, the lowest TV channel will appear on the

TV /DVD.

4To watch TV, press the CH. 3or 4buttons to

select memorized channels. Remember, if you are using a

Cable Box or Satellite Receiver, set the TV / DVD to

channel 3 or 4. Change channels at the Cable Box or

Satellite Receiver.

- SET UP-

2 LANGUAGE

[ENGLISH] ESP FRA

AUTO PRESET

Playable Discs

The TV/DVD will play the following Discs.

DVDs must have a Region Code of ALL regions or Region 1.

DVDs must be recorded in the NTSC Color System.

1ALL

Recordable

ReWritable

2-3

Quick-Use Guide (cont’

Quick-Use Guide (cont’d)

HEADPHONE
