MJ Series

CHICAGO RECESSED GIMBAL UNIT

Page 1 of 2

Job Information Type:

Job Name:

Cat. No.:

Notes:

Features

Illumination: A high-

output halogen sealed beam

lamp provides glare-free

light distribution and has an

expected life of 100 hours.

Housing: Housing, plaster

ring, and gimbal trim are

constructed of a heavy-duty

steel construction and are

finished in white baked-on

powder paint providing scratch

and corrosion resistance.

The gimbal ring allows full

adjustment of the unit lighting

head.

Battery: Maintenance-free,

sealed, lead calcium battery

has an estimated service life

of 5 years, and an operating

temperature range of

68°F (20°C) to 86°F (30°C).

Electronics: 120/277 VAC

dual voltage input with surge-

protected, solid-state circuitry.

Fully automatic, temperature

compensating, variable rate

float charging system is

complete with low voltage

disconnect, AC lockout,

brownout protection, AC

indicator lamp and test switch.

Code Compliance

Unit is UL 924 listed and

meets NFPA 101 Life Safety

Code, NEC, OSHA and City of

Chicago codes. Meets CCEA

plenum rating requirements.

Warranty

Three year unit warranty

(excludes lamps). One year full

plus four year prorated battery

warranty.

MJ112W

7.5"

(19.1 cm)

7.75"

(19.7 cm)12.75"

(32.4 cm)

MJ Series

CHICAGO RECESSED GIMBAL UNIT

Page 2 of 2

Philips Lightolier

e: [email protected]

t: (508) 679-8131

w: www.lightolier.com

MJ Series September 19, 2011

Specifications are subject to change without notice.

Job Information Type:

Ordering Information

Series

MJ = Chicago

Gimbal Unit

12 = 12 W

Battery Wattage

1= 6 V

Voltage

W= White

Housing Color

Quick Connect for

Lamp Assembly

Plaster Ring

(supplied)

Gimbal Ring

(PAR 36 lamp)

AC Ready Light

Electronics and Battery

Compartment

Test Switch

Torsion Spring

Trim Retainer

Trim Ring Diameter

8.5" (21.6 cm)

112 W

B= Black Finish

SP = Special Paint Finish - Specify Color

Factory Installed Options

UNIT

MJ112W

VOLTAGE

LAMP

WATTAGE

BATTERY WATTS TO 87 1/2

OF RATED VOLTAGE*

1 1/2 HRS

Unit Battery Capacity

2 HRS

* Per NEC specifications.

AC Junction

Box
