1 Description

DC/DC converter

QUINT4-PS/12DC/24DC/5/PT

Data sheet

QUINT POWER DC/DC converters with SFB Technology

and preventive function monitoring ensure superior system

availability.

Powerful

– SFB Technology: 6 times the nominal current for 15ms

– Power reserves:

Static boost of up to 125%(PN) for a sustained period

Dynamic boost of up to 200%(PN) for 5s

Preventive

– Comprehensive signaling:

Analog signal, digital signal, relay contact, LED bar

graph

Flexible connection technology

– Tried-and-tested screw connection

– Fast Push-in connection

Technical data (short form)

Input voltage range 12 VDC -25% ... +40%

Mains buffering typ. 4 ms (12VDC)

Nominal output voltage (UN) 24 VDC

Setting range of the output voltage

(USet)

24 VDC ... 29.5 VDC

Nominal output current (IN)

Static Boost (IStat.Boost)

Dynamic Boost (IDyn.Boost)

Selective Fuse Breaking (ISFB)

5 A

6.25 A

10 A (5 s)

30 A (15 ms)

Output power (PN)

Output power (PStat. Boost)

Output power (PDyn. Boost)

120 W

150 W

240 W (5 s)

Efficiency typ. 91.3 % (24VDC)

Residual ripple < 20 mVPP

MTBF (IEC 61709, SN 29500) > 930000 h (40°C)

Ambient temperature (operation) -25 °C ... 70 °C

-40°C (startup type tested)

> 60 °C Derating: 2,5 %/K

Dimensions W/H/D 36 mm / 130 mm / 125 mm

Weight 0.6 kg

All technical specifications are nominal values and refer to a room temperature of 25 °C and 70 % relative humidity

at 100 m above sea level.

109369_en_00 2021-11-03

QUINT4-PS/12DC/24DC/5/PT

109369_en_00 PHOENIX CONTACT 2/49

2 Table of contents

1 Description .............................................................................................................................. 1

2 Table of contents..................................................................................................................... 2

3 Ordering data .......................................................................................................................... 3

4 Technical data ......................................................................................................................... 5

5 Safety and installation notes.................................................................................................. 15

6 High-voltage test (HIPOT) ..................................................................................................... 17

7 Structure of the power supply ................................................................................................ 18

8 Mounting/removing the power supply.................................................................................... 21

9 Device connection terminal blocks ........................................................................................ 25

10 Output characteristic curves .................................................................................................. 26

11 Configuring the power supply ................................................................................................ 29

12 Boost currents ....................................................................................................................... 30

13 SFB Technology.................................................................................................................... 32

14 Signaling................................................................................................................................ 36

15 Operating modes................................................................................................................... 44

16 Derating................................................................................................................................. 46

QUINT4-PS/12DC/24DC/5/PT

109369_en_00 PHOENIX CONTACT 3/49

Description Type Item no. Pcs./Pkt.

Primary-switched DC/DC converter, QUINT POWER, DIN

rail mounting, SFB Technology (Selective Fuse Breaking),

Push-in connection, input: 12 VDC , output: 24 VDC / 5 A

QUINT4-PS/12DC/24DC/5/

2910124 1

3 Ordering data

Accessories Type Item no. Pcs./Pkt.

Universal wall adapter for securely mounting the device in

the event of strong vibrations. The device is screwed

directly onto the mounting surface. The universal wall

adapter is attached on the top/bottom.

UWA 182/52 2938235 1

2-piece universal wall adapter for securely mounting the

device in the event of strong vibrations. The profiles that

are screwed onto the side of the device are screwed

directly onto the mounting surface. The universal wall

adapter is attached on the left/right.

UWA 130 2901664 1

Near Field Communication (NFC) programming adapter

with USB interface for the wireless configuration of NFC-

capable products from PHOENIX CONTACT with

software. No separate USB driver is required.

TWN4 MIFARE NFC USB

ADAPTER

2909681 1

Multi-channel electronic circuit breaker for protecting four

loads at 24 V DC in the event of overload and short circuit.

With electronic locking of the set nominal currents. For

installation on DIN rails.

CBMC E4 24DC/1-4A NO 2906031 1

Multi-channel electronic circuit breaker for protecting four

loads at 24 V DC in the event of overload and short circuit.

With electronic locking of the set nominal currents. For

installation on DIN rails.

CBMC E4 24DC/1-10A NO 2906032 1

Multi-channel electronic circuit breaker with IO-Link

interface for protecting four loads at 24VDC in the event

of overload and short circuit. With electronic locking of the

set nominal currents. For installation on DIN rails.

CBMC E4 24DC/1-4A+ IOL 2910410 1

Multi-channel electronic circuit breaker with IO-Link

interface for protecting four loads at 24VDC in the event

of overload and short circuit. With electronic locking of the

set nominal currents. For installation on DIN rails.

CBMC E4 24DC/1-10A IOL 2910411 1

QUINT4-PS/12DC/24DC/5/PT

109369_en_00 PHOENIX CONTACT 4/49

Multi-channel, electronic circuit breaker with active

current limitation for protecting four loads at 24 V DC in the

event of overload and short circuit. With nominal current

assistant and electronic locking of the set nominal

currents. For installation on DIN rails.

CBM E4 24DC/0.5-10A NO-R 2905743 1

Multi-channel, electronic circuit breaker with active

current limitation for protecting eight loads at 24 V DC in

the event of overload and short circuit. With nominal

current assistant and electronic locking of the set nominal

currents. For installation on DIN rails.

CBM E8 24DC/0.5-10A NO-R 2905744 1

The range of accessories is being continuously extended. The current range of accessories can be found in

the download area for the product.

Accessories Type Item no. Pcs./Pkt.

QUINT4-PS/12DC/24DC/5/PT

109369_en_00 PHOENIX CONTACT 5/49

4 Technical data

Input data

Unless otherwise stated, all data applies for 25°Cambient temperature, 12VDC input voltage, and nominal

output current (IN).

Input voltage range 12 VDC -25% ... +40%

Electric strength, max. 25 VDC (60 s)

Current draw typ. 14 A (12VDC)

Mains buffering typ. 4 ms (12VDC)

Switch-on time < 1 s

Typical response time from SLEEP MODE 300 ms

Inrush current limitation 2 A

Inrush current integral (I2t) < 0.07 A2s

Input fuse slow-blow, internal 30 A

During the first few microseconds, the current flow into the filter capacitors is excluded.

The SCCR value (short-circuit current rating) of the power supply unit corresponds to the SCCR value of the

backup fuse (see input protection table).

The external backup fuse must be approved for the (DC) supply voltage used and the voltage level.

Input protection , DC ( to be connected externally upstream )

Input current IIn

Input protection Circuit breaker Neozed fuse

or equivalent Power switch

Characteristics A B C D K gG ≤ 13 x IIn

(maximum magnetic tripping)

20 A -   -

QUINT4-PS/12DC/24DC/5/PT

109369_en_00 PHOENIX CONTACT 6/49

Electric strength of the insulation

A B C D

Type test ( IEC/EN61010-1 ) 2 kV DC 4 kV DC 0.5 kV DC 0.5 kV DC

Production test 2 kV DC 2 kV DC 0.5 kV DC 0.5 kV DC

Housing

Output

Input Signaling

ABD

(+)

(-)

Input current vs. output current

246810

= UIn: 9 V DC/UOut: 24 V DC

= UIn: 12 V DC/UOut: 24 V DC

Out

[A]

IIn [A]

Input connection data

Connection method Push-in connection

Conductor cross section, rigid 0.2 mm² ... 6 mm²

Conductor cross section, flexible 0.2 mm² ... 6 mm²

Conductor cross section flexible, with ferrule with plastic

sleeve

0.2 mm² ... 4 mm²

QUINT4-PS/12DC/24DC/5/PT

109369_en_00 PHOENIX CONTACT 7/49

Conductor cross section flexible, with ferrule without

plastic sleeve

0.2 mm² ... 4 mm²

Conductor cross section AWG 24 ... 10

Stripping length 10 mm

Input connection data

Output data

Nominal output voltage (UN) 24 VDC

Setting range of the output voltage (USet) ( > 24VDC,

constant capacity )

24 VDC ... 29.5 VDC

Nominal output current (IN) 5 A

Static Boost (IStat.Boost) 6.25 A

Dynamic Boost (IDyn.Boost) 10 A (5 s)

Selective Fuse Breaking (ISFB) 30 A (15 ms)

Magnetic circuit breaker tripping A1 ... A4 / B2 / C1 ... C2 / Z1 ... Z4

Control deviation change in load, static 10 % ... 90 % < 1 %

Control deviation Dynamic load change 10 % ... 90 %,

10 Hz

< 2 %

Control deviation change in input voltage ±10 % < 0.1 %

Short-circuit-proof yes

No-load proof yes

Residual ripple < 20 mVPP

Connection in parallel yes, for redundancy and increased capacity

Connection in series yes

Feedback voltage resistance ≤ 35 VDC

Protection against overvoltage at the output (OVP) ≤ 32 VDC

Rise time typical < 1 s (UOUT (10 % ... 90 %))

Output connection data

Connection method Push-in connection

Conductor cross section, rigid 0.2 mm² ... 6 mm²

Conductor cross section, flexible 0.2 mm² ... 6 mm²

Conductor cross section flexible, with ferrule with plastic

sleeve

0.2 mm² ... 4 mm²

Conductor cross section flexible, with ferrule without

plastic sleeve

0.2 mm² ... 4 mm²

Conductor cross section AWG 24 ... 10

Stripping length 10 mm

QUINT4-PS/12DC/24DC/5/PT

109369_en_00 PHOENIX CONTACT 8/49

LED signaling

POut > 100% LED lights up yellow, output power > 120W

POut > 75% LED lights up green, output power > 90W

POut > 50% LED lights up green, output power > 60W

UOut > 0.9xUSet LED lights up green

UOut < 0.9xUSet LED flashes green

UIn > 0.8 x UInNom LED off

UIn < 0.8 x UInNom LED lights up yellow

Signal contacts

Signal output Out1 (configurable)

Connection labeling 3.5 +

Digital 0/24VDC , 20 mA

Default UIN input voltage OK

Signal option Output voltage

Output current

Output power

Operating hours

Early warning of high temperatures

OVP voltage limitation active

Signal output Out2 (configurable)

Connection labeling 3.6 +

Digital 0/24VDC , 20 mA

Default Output power

Signal option Output voltage

Output current

Operating hours

Early warning of high temperatures

OVP voltage limitation active

Analog 4 mA ... 20 mA ±5% ( Load ≤400Ω )

Signal option Output voltage

Output current

Output power

Signal output Relay13/14 (configurable)

Connection labeling 3.1, 3.2

Switch contact (floating) floating

Maximum contact load 24 VDC 1 A , 30 VAC 0.5 A

Default Output voltage

Signal option Output current

Output power

Operating hours

Early warning of high temperatures

OVP voltage limitation active

UIN input voltage OK

QUINT4-PS/12DC/24DC/5/PT

109369_en_00 PHOENIX CONTACT 9/49

Remote signal input (configurable)

Connection labeling 3.3 +

Function Output power ON/OFF (remote)

Default Output power ON (>40kΩ/24VDC/open bridge between REM

and SGnd)

Signal ground SGnd

Connection labeling 3.4 +

Function Signal ground

Reference potential to OUT1, OUT2, REM

Signal connection data

Connection method Push-in connection

Conductor cross section, rigid 0.2 mm² ... 1 mm²

Conductor cross section, flexible 0.2 mm² ... 1.5 mm²

Conductor cross section flexible, with ferrule with plastic

sleeve

0.2 mm² ... 0.75 mm²

Conductor cross section flexible, with ferrule without

plastic sleeve

0.2 mm² ... 1.5 mm²

Conductor cross section AWG 24 ... 16

Stripping length 8 mm

Reliability 24 VDC

MTBF (IEC 61709, SN 29500) > 1600000 h (25°C)

> 930000 h (40°C)

> 380000 h (60°C)

Life expectancy (electrolytic capacitors)

Output current (IOut)

24 VDC

2.5 A > 365000 h ( 40 °C )

5 A > 194000 h ( 40 °C )

5 A > 388000 h ( 30 °C )

The expected service life is based on the capacitors used. If the capacitor specification is observed, the

specified data will be ensured until the end of the stated service life. For runtimes beyond this time, error-free

operation may be reduced. The specified service life of more than 15 years is simply a comparative value.

Switching frequency Min. Max.

Auxiliary converter stage 190 kHz 220 kHz

Main converter stage 50 kHz 420 kHz

QUINT4-PS/12DC/24DC/5/PT

109369_en_00 PHOENIX CONTACT 10/49

General data

Degree of protection IP20

Protection class Special with SELV input and output

Inflammability class in acc. with UL 94 (housing / terminal

blocks)

Side element version Aluminum

Hood version Stainless steel X6Cr17

Dimensions W / H / D (state of delivery) 36 mm / 130 mm / 125 mm

Dimensions W / H / D (90° turned) 122 mm / 130 mm / 39 mm

Weight 0.6 kg

Power dissipation 24 VDC

Maximum power dissipation in no-load condition < 2 W

Power dissipation SLEEP MODE < 1 W

Power loss nominal load max. < 13 W

Efficiency 24 VDC

typ. 91.3 %

Eta [%]

IOut [A]

435678910

= UIn: 12 V DC/UOut: 24 V DC

Ambient conditions

Ambient temperature (operation) -25 °C ... 70 °C (> 60 °C Derating: 2,5 %/K)

The ambient temperature (operation) refers to IEC61010 surrounding air temperature.

Ambient temperature (start-up type tested) -40 °C

Ambient temperature (storage/transport) -40 °C ... 85 °C

Max. permissible relative humidity (operation) ≤ 95 % (at 25 °C, non-condensing)

Installation height ≤ 5000 m (> 2000 m, observe derating)

Vibration (operation) 5Hz ... 100Hz resonance search 2.3g, 90min., resonance

frequency 2.3g, 90min. (according to DNV GL Class C)

Shock 18 ms, 30g, in each space direction (according to IEC60068-

2-27)

Degree of pollution 2

Climatic class 3K3 (EN60721)

Overvoltage category

EN 61010-1

EN 62477-1

III

Questo manuale è adatto per i seguenti modelli

Indice

Altri manuali Phoenix Contact Convertitore multimediale

Phoenix Contact

Phoenix Contact FL MC 10BASE-T/FO G850 Manuale utente

Phoenix Contact

Phoenix Contact PSI-MOS-RS422/FO1300 E Guida rapida

Phoenix Contact

Phoenix Contact PSM-ME-RS232 Guida rapida

Phoenix Contact

Phoenix Contact GW MODBUS TCP/ASCII 1E/1DB9 Manuale utente

Phoenix Contact

Phoenix Contact QUINT-PS/24DC/24DC/5/CO Manuale utente

Phoenix Contact

Phoenix Contact FL MC EF 1300 MM SC Guida rapida

Phoenix Contact

Phoenix Contact QUINT4-PS/12-24DC/24DC/1.3/PT Manuale utente

Phoenix Contact

Phoenix Contact GW PN/DP 1E/1DB9 Manuale utente

Phoenix Contact

Phoenix Contact QUINT4-PS/48-110DC/24DC/2.5/ PT Manuale utente

Phoenix Contact

Phoenix Contact FL MC 100BASE-T/FO G1300 Manuale utente

Phoenix Contact

Phoenix Contact GW PN/DP 1E/1DB9 Manuale utente

Phoenix Contact

Phoenix Contact GW PN/DP 1E/1DB9 Manuale utente

Phoenix Contact

Phoenix Contact MACX MCR-SL-CAC-12-I-UP Guida rapida

Phoenix Contact

Phoenix Contact QUINT4-PS/12-24DC/24DC/1.3/SC Manuale utente

Phoenix Contact

Phoenix Contact GW PN/DP 1E/1DB9 Manuale utente

Phoenix Contact

Phoenix Contact QUINT4-PS/12-24DC/5-15DC/2.5/ PT Manuale utente

Phoenix Contact

Phoenix Contact PSI-MOS-RS232/FO 850 E Manuale utente

Manuali Convertitore multimediale popolari di altre marche

SoundTraxx

SoundTraxx Blunami BLU-2200 Manuale utente

SPROLINK

SPROLINK VA1 Manuale utente

Acclaim Lighting

Acclaim Lighting DDC-1-AC Manuale utente

Nikon

Nikon AF-S TC-20E III Manuale utente

Axis

Axis AXIS Q7406 Manuale utente

Omega

Omega TAC80B-J Manuale utente

Zoom

Zoom Thunderbolt TAC-2R Manuale utente

OST

OST iConverter 10/100M Manuale utente

Vertiv

Vertiv Netsure Manuale utente

birddog

birddog MINI Manuale utente

Roland

Roland GI-10 Manuale utente

Wallenstein

Wallenstein WX310 Manuale utente

Pace

Pace MSS 200-1 Manuale utente

Solar Converters

Solar Converters EQ 12/24-50 Manuale utente

CYP

CYP EL-7400V Manuale utente

TIE

TIE MIDI 1i1o Manuale utente

DCS

DCS Vivaldi Upsampler Manuale utente

Westermo

Westermo MCW-211 SERIES Manuale utente
