Output Power per Channel at 1% THD (all channels driven)

Into 4 ohms @ 12.0 VDC ..................................24 watts x 2

Into 4 ohms @ 14.4 VDC ..................................35 watts x 2

Into 2 ohms @ 14.4 VDC ..................................60 watts x 2

Into 1 ohm @ 14.4 VDC....................................93 watts x 2

Into 1/2 ohm @ 14.4 VDC.................................150 watts x 2*

Bridged into 4 ohms @ 14.4 VDC .....................125 watts x 1

Bridged into 2 ohms @ 14.4 VDC .....................185 watts x 1

Bridged into 1 ohm @ 14.4 VDC.......................300 watts x 1*

Frequency Response........................................±1dB from 20Hz to 20kHz

Signal to Noise Ratio.........................................>100dB

Lowest THD.......................................................0.02%

Damping Factor.................................................500 to 1

Input Sensitivity.................................................200 millivolts to 2 volts

Input Impedance................................................30k ohms

Input Voltage Range..........................................10.5 volts to 15.0 volts

Typical current draw at idle................................3 amps

Continuous current draw @ full power**............30 amps

Peak current draw @ full power***....................40 amps

Bass Boost........................................................+12 dB @ 45 Hz

Recommended Fuse Size.................................40 amps

Dimensions........................................................8.5"L x 11.4"W x 2.4"H

*Low impedance operation requires cooling fans, large gauge power cable and at

least 1 farad of capacitance. MINIMUM SPEAKER LOAD IS 1 OHMS BRIDGED OR 1/2

OHM STEREO.

** Average continuous current draw when playing typical music material

*** Average peak current needed for musical peaks (<20 ms) when playing typical

music material.

Howtoselectthecorrectgaugepowercableforsingleor

multipleamplifiersystems.

PGTechSupportPAW-11/98

Themaximumcontinuousamplifierpowerandthedistanceofthecablerun

determinethecorrectpowercablesize.

-- PhoenixGoldTechTips--

-- PhoenixGoldTechTips--

Distanceofcablerun

M

a

x

C

o

n

t

p

o

w

e

r

Examples:

1.AsystemwithoneZX450.Theamplifierismountedinthetrunkandthebatteryis18feet

awayintheenginecompartment.Theamplifercanproduceupto500 watts.Thechartabove

showstheneedfora2cable.

2.AsystemwithaZPA0.5forbass anda.Theamplifierismountedinthetrunkandthebattery

is18feetawayintheenginecompartment.Theamplifercanproduceupto500 watts.Thechart

aboveshowstheneedfora2cable.

Usethechartbelowtofindthecorrectcablesize

1.Findthedistance(feet)ofthecablerunalongthetop.

2.Findthetotalcontinuouspower(watts)thecablemustsupportontheleft.

3.Wherethetwomeetindicatesthepropergaugecable.

Ifthedistanceorpowerfallsbetweentwocolummsorrows,alwaysrounduptothenext

highergauge.

100 w

200 w

400 w

600 w

800 w

1000 w

1400 w

1800 w

2200 w

2600 w

3000 w

4ft

10

10

8

8

4

4

2

2

2

2

1/0

8ft

10

8

8

4

4

2

2

2

2

1/0

1/0

12 ft

8

8

4

4

2

2

2

2

1/0

1/0

1/0

16 ft

8

4

4

2

2

2

2

1/0

1/0

1/0

1/0x2

20 ft

4

4

2

2

2

2

1/0

1/0

1/0

1/0x2

1/0x2

24 ft

4

2

2

2

2

1/0

1/0

1/0

1/0x2

1/0x2

1/0x3
