USER MANUAL

BluLink™

Wireless Cell Phone

and Music Adapter

www.pilot-usa.com

www.pilotblulink.com

Thank you for purchasing

BluLink™

At Pilot USA we have been instrumental in bringing cutting edge

technology to the aviation market. In 2001 we introduced the ﬁrst

aviation headset with a cell phone input. Today we are very proud

to present BluLink, the world’s ﬁrst wireless cell phone and music

adapter for general aviation! BluLink reduces the need for extra cables

and adapters, creating a safer and more trouble free cockpit. Use

your GA headset along with BluLink to wirelessly connect to your cell

phone and music player. BluLink even allows you to wirelessly control

the music. Just use the buttons on the device to select songs on

your Bluetooth music streaming cell phone or portable music player

such as an iPod (NOTE: a Bluetooth dongle may be required and are

available at www.pilot-usa.com)

The manual provides step by step usage instructions for your BluLink

device, however if you have any further questions, please call us at

1-888-GO-PILOT. Also note the warranty information on page 7.

Introduction

BluLink allows you to have a wearable link to your Bluetooth enabled

mobile phone with no cords or wires to get in the way. BluLink along

with your existing aviation headset, works like stereo headphones

allowing you to stream digital music and even lets you control the

music wirelessly. Just use a mobile phone with music streaming

capability or add a Bluetooth dongle to your portable music player.

Make sure the Bluetooth enabled phone or adapter has Bluetooth

A2DP (Advanced Audio Distribution Proﬁle) and Bluetooth AVRCP

(Audio/Video Remote Control Proﬁle). These Bluetooth technologies

allow the device to work with BluLink.

Answer / end cAll

BlUeTOOTH IndIcATOr led

BlUeTOOTH PAIrInG / reQUesT

On / Off

POwer IndIcATOr led

redIAl / VOIce dIAl

VOlUMe UP

fOrwArd

PlAy / PAUse

VOlUMe dOwn

Directions

• Insert2AAalkalinebatteries.

• Plugthecordforheadsetintoheadsetlabeledjack.

• Plugthecordforintercom/panelintoairplanelabeledjack.

• ConnectheadsettoBluLink.

• ConnectBluLinktoaircraftpanelorintercomsystem.

• Turnunitonbypushingandholdingbuttonfor2seconds.

Green light will come on and then fade away.

• Toturnunitoff,pressandholdbuttonfor2secondsuntilred

light comes on.

Note: In the battery compartment are 2 switches. The top switch

(A) is a Mono/Stereo switch. If aircraft intercom system is Mono, put

switch in Right (2) Position. (If you hear from only 1 side of headset,

put switch in right (2) position.)

The bottom Switch (B) is for auto mute. When the switch is to the left

(1) BluLink will mute your music source when anyone, including ATC,

speaks over the intercom. When the switch is to the right (2) BluLink

will not mute the music source.

Pairing with your phone and/or music device

What is pairing?

Bluetooth devices need to be “paired” with each other beforehand.

Once Bluetooth devices are paired, there is usually no need for

pairing again.

Before you can use BluLink to make a call or listen to music, it must

be paired with your Bluetooth enabled phone and/or music device.

Note: Once you have paired one device (i.e. cell phone) BluLink must

be turned off and back on before another device (i.e. iPod, music

player) can be paired.

To pair BluLink with your phone or music player

• Onyourphone,besuretheBluetoothfeatureisturnedon.For

more information, consult the user’s guide that came with your

phone.

• IfusingaBluetoothdonglewithyourmusicplayerpleaseconsult

the user guide that came with it.

• WithBluLinkturnedon,enter“pairinginprocess”modeby

pressing and holding button until BT indicator light ﬂashes

Blue 3 times AND then ﬂashes Red/Blue.

• HaveyourphonesearchforBluetoothdevices.Oncethephone

ﬁnds BluLink, pair with it. If your phone prompts you to enter a pass

code, enter 0000.

• ConnecttoBluLink.

Note: Passcode of this unit is ﬁxed at “0000”, “1234”, or “8888”

Passcode may be called “Passkey”, “PIN code”, “PIN number”

or “Password”

Reconnecting previously paired devices

to BluLink

Once a device has been paired with BluLink, you can reestablish

a connection to the device by turning BluLink on and holding the

button until the blue light ﬂashes 3 times.

Making and Receiving Calls

You can use your phone as normal for all dialing and call receiving

procedures.However,BluLinkenablesyoutohavesomeofthe

phone’s controls directly at your ﬁnger touch without having the phone

in your reach.

Using the answer/end call button

• Pushbuttononcetoanswerincomingphonecall

• Pushbuttononceduringcalltoendphonecall

• Torejectthecallpushbuttontwicebriey

Using redial/ voice dial button

• Pressbuttontwicebrieytorediallastnumber

• Pressandholdbuttonfor2secondsthenspeakthenameor

command (only works if you have voice activation set up in your

phone)

Note: Some phones do not support all the features listed.

Controlling Music

Use BluLink to wirelessly control music from your Bluetooth music-

streaming phone or music player. If a call comes in while music is

playing, the music will pause and you can answer the call by pressing

the button. After the call is ended, the music will begin to play

automatically.

Using the Multi Function audio controls

• Togotothenextsongpressthebutton

• Torepeatsongpressthebutton

• Togototheprevioussongpressthebuttontwicequickly

• ToplayorPausethemusicpushthebutton

• Toincreasethevolumepushthebutton

• Todecreasethevolumepushthebutton

Troubleshooting:

Symptom Cause / Remedy

Pairing cannot be established. Locate BluLink and other Bluetooth

device(s) as near as possible.

Bluetooth connection cannot Locate BluLink and other Bluetooth

beestablishedWithadevice device(s)asnearaspossible.

that has been “paired” before.

Pairing information may be

deleted. Pair the device again.

Cannot change the volume on Change the volume on BluLink

my iPod when I use a dongle.

My voice seems distorted to move mic away from mouth at

the person I’m speaking to least 1 to 2 inches

on the cell phone when I use

BluLink connected to my intercom

Warranty:

Your BluLink has a 1 year warranty from the purchase date. The

warranty only covers manufacture defects. Any damage done to the

product by misuse or negligence, such as dropping or breaking it, will

not be covered under the warranty. Any modiﬁcations made to the unit

or cable assemblies by anyone other than Pilot USA will void warranty.

Speciﬁcations:

Bluetooth Speciﬁcations ................................................. BT 2.0+EDR*

Bluetooth Proﬁles ....................... Handsfree,Headsets,A2DP,AVRCP

MusicFrequencyResponse.....................................20Hz–20,000Hz

(Dependable on headset used)

TelephonyFrequencyResponse .............................300Hz–3,000Hz

Battery Life ....................................................................... 15-20 hours*

Battery Type ..................................................................... 2 AA alkaline

Standby Time ............................................................... Over 100 hours

Weight ........................................................ 4.2oz(includingbatteries)

*Enhanced Data Rate

**Battery life depends on numerous factors including volume level and BT streaming

70 Maxwell, Irvine, CA 92618

1-888-GO-PILOT, (949) 748-8880 • Fax: (949) 748-8881

www.pilot-usa.com

Visit our website to see our full line of headsets, intercoms and accessories

For more info or FAQ, please go to

www.pilotblulink.com
