Pioneer G-5 Manuale tecnico

Product Update Guide

5th Generation Plasma Models

G-5

Technical Training Department

1925 E. Dominguez Street

Long Beach, CA 90810

Contents

Preface………………….………….4

New Product Information……….5~21

Media Receiver Section………...23~35

Specifications……………….……..24

Front Panel & Connectors………..25~26

Trap switch………..…………….….27

Digital Tuner Board Block…….......28

Power Supply………………….…...29~30

AV Block……………………..…...…31

Main Board Block……………..…...32~33

Disassembly……………………......34~35

Plasma Panel Section…….……37~50

Overall Block………………...…...38~39

Panel IF Block…………….……...40~41

Digital Video Block……….…....…42~43

X-Drive Block……………….….....44

Y-Drive Block……………………..45

Power On Sequence………..…...46

Disassembly….……………..…....47~50

LED Trouble Shooting………...…51~59

Factory Service Modes……..…60~87

Lead in the solder used in this product

is a known reproductive toxicant which

may cause birth defects or other reproductive

harm. (California Health and Safety Code

Section 25249.5).

When servicing this or handling circuit

boards and other components which

contain solder, avoid unprotected skin

contact with the solder. Also, when

soldering do not inhale any smoke or

fumes produced.

This technical training guide will address

the disassembly and adjustments of the

Pioneer Generation 5 Plasma Display models.

This guide was designed as a servicing aid

and is not intended to replace the service

manual. The student should have the

appropriate service manual on hand when

when using this guide. Data in the service

manual for this unit contains specific

information on safety, parts and adjustments.

Safety information

Important safety data for this Pioneer model

is contained in the service manual. Before

returning the unit to the customer, complete

all product safety obligations and tests.

Technicians who bypass safety features or

fail to carry out safety checks may expose

themselves and others to possible injury,

and may be liable for any resulting damages.

Preface

For more information on electronic

circuits and block diagrams refer

to the Service manual.

PRO-1410HD

PRO-1010HD

PRO-

810HD

PRO-920HD

PRO-1120HD

Plasma Products(North America)

2004

Panel :PRO-435P/ PRO-505P

Systems

MR :PRO-R05U

ELITE

PRO-1410HD ---- Made by NPD

PRO-1010HD ---- base model: PDP-504CMX

Monitors

PDP-5045HD

PRO-810HD ---- base model: PDP-434CMX

Systems Panel :PDP-434P/ PDP-504P

PDP-4345HD MR :PDP-R05U

PDP-

5004/5014

Regular Line

PDP-4304/4314 PDP-5004 / 5014 ---- base model: PDP-504CMX

Monitors

PDP-4304 / 4314 ---- base model: PDP-434CMX

Pioneer Plasma

All the great technologies of the

previous models

!Pure Drive

!ACE II

!3:3 Pull Down

!Deep Encased Cell Structure

!Pure Color Filter

Now including

!Digital Cable Tuner

PDP-5045HD

PDP-4345HD

New PIONEER – Built in Cable Tuner

Digital Cable Tuner

!Passport EPG (banner only) Regular line

!POD slot (Point Of Deployment - Host Interface Card)

!Seamless operation between digital and analog

tuners

!DTV closed captioning

Simple

Banner

Extended

Banner

PDP-5045HD

50” HDTV Wide screen Plasma Television

Best in Class Picture Quality

ACE II for over 1 Billion Colors, Advanced Pure Cinema with 3:3 Pull-Down

Pure Drive Signal Processing

Pure Digital Process, Pioneer Exclusive Chipset, ATSC Tuner, DCR with Cable CARD

Specifications:

!16 x 9 Wide screen Aspect Ratio

!WXGA 1280 x 768p Resolution

!1,000 cd/m2Brightness

!Integrated ATSC Tuner

!Pure Drive Image Processing

!Deep Encased Cell Structure

!ACE II for over 1 billion colors

!Advanced Pure Cinema with 3:3 Pull down

!Vertical or Horizontal Mount Media Receiver

!Advanced PIP Capability

!Dual HDMI Inputs

!Energy Star Certified

!2-Way Speakers with Framed or Under Mount

!Swivel Table Top Stand

PDP-4345HD

43” HDTV Wide screen Plasma Television

Best in Class Picture Quality

ACE II for over 1 Billion Colors, Advanced Pure Cinema with 3:3 Pull-Down

Pure Drive Signal Processing

Pure Digital Process, Pioneer Exclusive Chipset, ATSC Tuner, DCR with Cable CARD

Specifications:

!16 x 9 Wide screen Aspect Ratio

!XGA 1024 x 768p Resolution

!1,100 cd/m2Brightness

!Integrated ATSC Tuner

!Pure Drive Image Processing

!Deep Encased Cell Structure

!ACE II for over 1 billion colors

!Advanced Pure Cinema with 3:3 Pull down

!Vertical or Horizontal Mount Media Receiver

!Advanced PIP Capability

!Dual HDMI Inputs

!Energy Star Certified

!2-Way Speakers with Framed or Under Mount

!Swivel Table Top Stand

50” & 43” E

ELIT

LITE

EMonitors

!Pure Drive

!ACE II

!3:3 Pull Down

!Pure Color Filter II

!Dual HDMI inputs

!2nd Generation ISF

!New Cosmetics

PRO-1010HD

PRO-810 HD
