PiXORD 3GR-431P User Manual
1
3GR-431P
User’s Manual
Vehicle 3G Wi-Fi Router
Version: 1.1
Date: 11/30/ 01
PiXORD 3GR-431P User Manual
2
Notices
This user manual is intended for administrators and users of the PiXORD 3GR-431P Vehicle 3G i-Fi Router,
including instructions for using and managing the router on your network. The use of surveillance devices
may be prohibited by law in your country. It is the user’s responsibility to ensure that the operation of such
devices is legal before installing this unit for its intended use.
Before the Vehicle 3G iFi Router is installed, all the safety and operating instructions should be carefully
read and followed to avoid damage due to faulty assembly and installation. This also ensures the product is
used properly as intended.
Heed all warnings
Do not drop or strike this equipment
Sensitive electronics inside the 3G i-Fi Router are vulnerable.
Do not install the equipment near any flames or heat sources
Excessive heat could damage this equipment.
Do not cover cloth or to install this equipment in poorly ventilated places.
Overheating could damage this equipment.
Do not expose this equipment to rain or moisture. Do not touch the power connection with wet
hands
Risk of short circuit, electric shock or fire
Do not damage the power cord or leave it under pressure
Risk of fire or shock circuit
To reduce the risk of electric shock, do not remove the Cover or Back).
No user-serviceable parts inside. Misusage, improper, and negligence could damage this
equipment. Need to refer servicing to qualified service personnel.
Do not continue to operate if there appears to be fault.
If the unit ceases to function, contact qualified service personnel for help.
All work related to the installation of this product should be made by qualified service
personnel or system installers.
PiXORD 3GR-431P User Manual
3
Liability PiXORD Corporation
reserves the right to make corrections, modifications, enhancements, improvements, and other changes to
its products and services at any time and to discontinue any product or service without notice. Customers
should obtain the latest relevant information before placing orders and should verify that such information
is current and complete. All products are sold subject to PiXORD Corporation’s terms and conditions of sale
supplied at the time of order acknowledgment.
PiXORD is not responsible or liable for the resale of its products with statements different from or beyond
the specification/parameters stated by PiXORD. Customers are responsible for their applications using
PiXORD products. To minimize the risks associated with customer applications, customers should provide
adequate operating safeguards. PiXORD is under no obligation to provide any further technical support
service or product/software alteration beyond PiXORD's representation.
PiXORD products are not authorized for use in safety-critical applications where a failure of the PiXORD
product would cause severe personal injury or death, unless officers of the parties have executed an
agreement specifically governing such use.
Reproduction of PiXORD information or datasheets with alteration is an unfair and deceptive business
practice. PiXORD is not responsible or liable for any such statements.
Every care has been taken of this manual. If there are any inaccuracies or omissions, please inform your
local office. PiXORD Corporation cannot be held responsible for any typographical or technical errors.
PiXORD Corporation is not liable or responsible for incidental or damages caused by mishandling.
Trademarks
All names used in this manual for hardware and software are probably registered trademarks of respective
companies. PiXORD is a registered trademark of PiXORD Corporation. All rights reserved.
PiXORD 3GR-431P User Manual
4
Table of Contents
Chapter 1. Introduction ..................................................................................................................................... 7
Chapter 2. Installation ....................................................................................................................................... 8
Chapter 3. Operation Mode ............................................................................................................................ 15
3.1 Bridge ................................................................................................................................................. 15
3.2 Gateway ............................................................................................................................................. 16
3.3 AP Client ............................................................................................................................................ 17
Chapter 4. Internet setting .............................................................................................................................. 19
4.1 AN ( ide Area Network) ............................................................................................................... 19
4.2 LAN (Local Area Network).................................................................................................................. 19
4.3 DHCP Client List ................................................................................................................................. 21
4.4 VPN Passthrough ............................................................................................................................... 21
4.4 Static Routing Settings ....................................................................................................................... 22
Chapter 5. ireless Settings ............................................................................................................................ 24
5.1 Basic ireless Settings ...................................................................................................................... 24
5.2 Advanced ireless Settings ............................................................................................................... 25
5.3 ireless Security ............................................................................................................................... 27
5.4 Station List ......................................................................................................................................... 28
5.5 ireless Statistics .............................................................................................................................. 29
Chapter 6. Firewall........................................................................................................................................... 30
6.1 MAC/IP/Port Filtering ........................................................................................................................ 30
6.2 Port Forwarding ................................................................................................................................. 31
PiXORD 3GR-431P User Manual
5
6.2.1 Port Forwarding ...................................................................................................................... 31
6.2.2 Virtual Servers ........................................................................................................................ 32
6.3 DMZ ................................................................................................................................................... 33
6.4 System Security ................................................................................................................................. 34
6.5 Content Filtering ................................................................................................................................ 35
6.5.1 eb Content Filtering ............................................................................................................ 35
6.5.2 eb URL Filtering ................................................................................................................... 36
6.5.3 eb Host Filtering .................................................................................................................. 36
Chapter 7. Administration ............................................................................................................................... 37
7.1 Management ..................................................................................................................................... 37
7.1.1 Administrator settings ............................................................................................................ 37
7.1.2 NTP setting ............................................................................................................................. 37
7.1.2 DDNS ....................................................................................................................................... 37
7.2 Upgrade Firmware ............................................................................................................................. 38
7.3 Setting Management ......................................................................................................................... 38
7.4 Status ................................................................................................................................................. 39
7.5 Statistics ............................................................................................................................................. 40
7.6 System Log ......................................................................................................................................... 41
Chapter 8. Mobile 3G Management ................................................................................................................ 43
8.1 Mobile 3G Status ............................................................................................................................... 43
8.2 Mobile 3G Protection ........................................................................................................................ 43
8.2.1 PIN Code Settings ................................................................................................................... 43
PiXORD 3GR-431P User Manual
6
8.2.2 PIN Code Settings ................................................................................................................... 44
8.2.3 PIN Code Change Settings ...................................................................................................... 44
8.2.4 PUK Code Settings .................................................................................................................. 44
Chapter 9. GPS Management .......................................................................................................................... 46
9.1 GPS Status .......................................................................................................................................... 46
9.2 GPS Settings ....................................................................................................................................... 46
Appendix. FAQ ................................................................................................................................................. 47
PiXORD 3GR-431P User Manual
7
Chapter 1. Introduction
Pixord 3GR-431P is an 802.11n ireless and 3G Router. It comes equipped with two 10/100 Base-T
Ethernet ports and a 3G connection for mobile connectivity. The 3GR-431P is available to install on
transportation, passengers can use the laptop or smart phone via i-Fi to browse the Internet. The
Ethernet port is also available to connect an IP camera or other Ethernet IP devices for various applications.
Features
Support Bridge, Gateway, and AP Client mode
DHCP Server
VPN Passthrough
Support IEEE 802.11b/g/n
Firewall
DDNS
User-Friendly eb GUI
Application
3GR-431P Vehicle 3G i-Fi Router is a 3G + GPS + 802.11n (2T2R) wireless router for all IP network
application.
PiXORD 3GR-431P User Manual
8
Chapter 2. Installation
Front panel
All supported interfaces in the front panel and indicated LED position.
Rear panel
The 3GR-431P supported SMA connecters in the rear panel.
LED description
LED Color Mode Description
power Green
On Power on
Off Power off
3G Amber
On Internet is ready
Off Internet is not ready
Blink Signal Searching
GPS Red
On GPS connection is established
Off GPS connection is not established
Blink Signal Searching
LAN
Green
On The i-Fi is ready and enabled
PiXORD 3GR-431P User Manual
9
Off The i-Fi is not ready or disabled
Blink Data transmitting or receiving over LAN
ETH1/ETH2
Green
On An Ethernet Link is established
Off An Ethernet Link is not established
Blink Data transmitting or receiving over LAN
Interface detail function
Power connecter:
Pin
Color Function
1 Black GND
2 Red Battery
3 N/A
N/A
4 Yellow ACC
Pin Function
PiXORD 3GR-431P User Manual
10
I/O Port:
RS-232 interface:
1 Left Turn Signal Light
2 Right Turn Signal Light
3 Reversing Light
4 System Reserved
5 System Reserved
6 System Reserved
7 5V
8 System Reserved
9 GND
10 GND
Pin 1 2 3 4 5 6 7 8 9
Function
NC TXD RXD NC GND NC NC NC 5V
