Quick Installation Guide

Use web browser (Internet Explorer 6.0 or above) to connect to 192.168.0.1

(type this address in the address bar of web browser). You’ll be prompted to

input username and password: admin / admin

Further Configuration

For detail configuration, please check user’s manual on the bundled CD.

If you have any other questions, please contact the dealer where you purchased this product or you can contact PLANET directly at the following

email address: [email protected]

Step 5. Login Prompt

Power AdapterRJ-45 cableRJ-11 cable x 2Antenna x 2

Step 4. Connecting Power Adapter

CD-ROM

Step 1. Connecting Network

Follow the figure below to connect wired DSL/Cable connection.

VERIFY THE CONTENTS INSIDE PACKAGE BOX

The package should contain the items plus VIP-281SW. If any item is missing or damaged, please contact the seller immediately.

Step 2. Computer Network Setup

Plug RJ-45 Cable with LAN port and Computer

NOTE : Use only the power adapter shipped with the unit to ensure correct functionality

Step 3. Connecting Telephone

Plug RJ-11 cable with FXS port and telephone

RJ-11 CableRJ-11 Cable

Phone

RJ-45 Cable

Power Adapter

Power

LAN port

FAX

(DHCP Client or Fixed IP 192.168.0.2)

RJ-45 Cable RJ-11 Cable

DSL / Cable Modem Phone Jack

001101010

WAN port
