Dual Mode CCD Box Internet Camera

Key Feature

Data Sheet

Equipped with MPEG-4 and M-JPEG video streaming, the PLANET ICA-750

is a Dual Mode CCD Box Internet Camera which is designed for

professional security and high-quality video / audio requirement. The

manual Day / Night switch with ICR (IR-cut filter Removable), CS-Mount

optical lens and PoE (Power over Ethernet) features provides the most

flexibility of IP surveillance.

PLANET ICA-750 supports 2-Way audio that can directly make audio

communication between local and remote side by using the built-in

microphone and adding an external speaker. Besides web browsers, the

ICA-750 also provides 3GPP capability which can let the administrators

remotely view the live video via a 3G mobile phone. With DI / DO ports,

users are allowed to connect external sensors or alarm devices to improve

the security system with more advanced function.

The professional management software - PLANET Cam Viewer, is a

multi-camera video surveillance application which can handle ICA-750 to

provide monitoring, recording and event management functions. That

offers you to setup a comprehensive and effective surveillance system

quickly and easily. ICA-750 is an all-functioned network camera and

suitable for many occasions that could express high-quality video / audio to

everywhere in the world. It can provide a real professional security

environment to protect your property and your life.

ICA-750

• Day / Night Switch with ICR (IR-cut filter removable)

• MPEG-4 and M-JPEG dual codec

• 2-Way Audio supported

• 3GPP for 3G mobile remote application

• Provides 4 Motion Detection area

• E-mail Alert by motion detection and input I/O

• Up to 30 fps for all resolution

• Built-in microphone and external microphone / speaker

• PoE (IEEE 802.3af) supported

• User definable HTTP and HTTPS port number

• External I/O trigger for various surveillance applications

• Cam Viewer, Central management software supported Application

PLANET reserves the right to change specifications without prior notice. All brand names and trademarks are property or

11-07 C-ICA750-1

PLANET Technology Corporation

11F, No. 96, Min Chuan Road, Hsin Tien, Taipei, Taiwan R.O.C.

Tel: 886-2-2219-9518 Fax: 886-2-2219-9528

Email: [email protected] www.planet.com.tw

VoIP Gateway: vip.planet.com.tw

Dual Mode CCD Box Internet Camera

ICA-750

Dual Mode CCD Box Internet Camera

Product

Specification

Applications

Ordering Information

Model

Video

Image Sensor

Lens

Video Codec

Resolution

Frame Rate

Image Control

3GPP

Audio

Audio Codec

Microphone / Speaker

Interface

LAN

AUDIO

DI / DO

Network

Protocols

Management

Client

Security

Motion Detection

E-mail Notification

Environment

Power Requirement

Dimensions (W x D x H)

Weight

Emission

ICA-750

1/4” Sony CCD, VGA Resolution

F1.6 Fixed Focus, CS Mount Type, 4 Layers Glass

MPEG-4 and M-JPEG Dual Stream

640 x 480, 320 x 240, 160 x 120

Up to 30 fps @all resolution

AWB, AEC, AGC, Contrast, Brightness auto-iris Control

160 x 120 @15fs, MPEG-4 for mobile phone viewing

G.726 ADPCM, G.711 PCM

Bi-directional, Built-in Microphone and external Microphone / Speaker

1 x RJ-45, 10/100Base-TX, Auto MDI / MDI-X, IEEE802.3af

1 x Audio In, 1 x Audio Out

2 x Digital In, 2 x Digital Out

TCP / IP, SMTP, HTTP, DHCP, NTP, RTSP / RTP, UPnP, FTP, DDNS, HTTPS, SYSLOG, JABBER

Web browser, Cam Viewer software

Username and Password, HTTPS, IP Filter

4 Area definable

Triggered by motion detection and input I/O

12V DC, 1A

81 x 130 x 50 mm

480 g

CE, FCC

Remote monitoring application

Data Sheet

ICA-750

3GPP

Mobile Network

Boardroom

Office

Computer Room

ICA-750

Two Way Audio

ICA-750

Alarm

Input

Output

Door Open Detector

Router

PoE

M-JPEG

MPEG-4

Internet

PoE Switch

Cam Viewer
