Plantronics Discovery 650e Manuale utente

User Guide

650E

Stylish Bluetooth®Headset with Multipoint Technology

WELCOME

Thank you for purchasing a Plantronics headset.

Let us provide you with the best possible service and technical support. After

reviewing this user guide, if you need additional assistance or have any product

questions, please contact:

•Plantronics Technical Assistance Center at 866-363-BLUE (2583)

•www.plantronics.com/support

Please refer to the separate Safety Instructions booklet for important product

safety information prior to installation or use of product.

Visit www.plantronics.com/productregistration to register your product online

so we can provide you with the best possible service and technical support.

TABLE OF CONTENTS

Package Contents & Features 3

Charging 4

Pairing 5

Powering 7

Adjusting Fit 8

Using Your Headset 9

Multipoint 11

Indicator Lights 12

Optional Accessories 12

Troubleshooting 13

Product Specifications 13

Technical Assistance 14

Warranty 14

Regulatory Notices 15

PACKAGE CONTENTS & FEATURES

PLANTRONICS DISCOVERY

650E

AC charger

PLANTRONICS DISCOVERY 650E

ACCESSORIES

Indicator light

Call control button (on/off)

Volume/mute button

Microphone

Soft gel ear tips

Ear loop

AAA

battery

small

medium

large

Headset

charging

pocket

AAA

battery

charger

CHARGING

PLANTRONICS DISCOvERY 650E

Before using, you must first charge your headset.

1 hour = minimum charge 3 hours = full charge

DISCONNECTING COMPONENTS

To separate components, grasp both the battery charger and the charging pocket

with the shirt clip facing you. Bend the components back and they will snap apart.

NOTE Do not twist the components apart.

CAUTION

Only replace with a non-rechargeable AAA battery.

Option A: Using the included AC charger

The indicator light glows red continuously while

charging and turns off when fully charged.

1. Plug the AC charger into the base of the charging

pocket and connect it to your power source.

2. Insert the headset into the charging pocket.

Option B: Using a AAA battery

One AAA battery recharges the headset to full

capacity.

1. Twist the bottom of the AAA battery charger

counterclockwise and release the battery holder.

2. Insert the battery into the AAA battery holder.

3. Slide the battery holder back into the battery

charger and turn clockwise.

4. Snap battery charger onto charging pocket.

Ensure that the indentation on the battery

charger connector aligns with the shirt clip on

the charging pocket.

5. Insert the headset into the charging pocket.

PAIRING

Step One:

Prepare Phone—

Turn on Bluetooth

For most phones, go

to Settings/Tools menu

and select Bluetooth or

Connectivity and select

“On.” (Or see the user

guide for your phone.)

SETTINGS

Time and Date

Phone Settings

Bluetooth

Sound Settings

Network Services

Security

Reset Settings

BLUETOOTH

Discover/

BLUETOOTH

6XXPlantronics

Headset Passkey

PASSKEY

0000

This headset now comes with QuickPairTM technology so pairing with your Bluetooth

phone is even easier. Follow the instructions below to pair your phone with your

headset for the first time.

Step Two:

Prepare Headset—

Pairing Mode

Begin with headset turned

off. Turn headset on (hold

call control button for at

least four seconds) and it

will automatically go into

pairing mode, flashing red

and blue.

Step Three:

Pairing—

Add Headset to Phone

For most phones, go to

Settings/Tools > Bluetooth >

Search or Add a Device, then

Select “6XXPlantronics.”

For passkey enter 0000.

Headset will flash blue

when paired successfully.

It is now powered on and

ready to use.

NOTE: Normally you only need to pair the headset and handset once. If the headset

has been previously paired with another device, follow pairing instructions on the

next page.

QUICKPAIR FEATURE INSTRUCTIONS

PAIRING

If headset has been previously paired with another device, please follow these

instructions for pairing a second time. Be sure the headset is fully charged. For

set up and pairing instructions with other Bluetooth devices, please consult your

Bluetooth device user guide or visit www.plantronics.com/easytopair–an online,

interactive pairing guide for phones and headsets.

Begin with headset turned off.

1. Press and hold down the call

control button for 10 seconds until

theheadsetstatusindicatorbegins

to flash red then blue.

The headset is now in pairing

mode for the next 120 seconds.

2. While the headset is flashing,

use the phone menu to search

for Bluetooth devices and select

“6XXPlantronics.”

3. When prompted for a passkey,

enter 0000. Headset will flash

blue when paired successfully.

1. 2.

When purchased the headset will have the online and standby indicator lights enabled.

To disable these indicators, press the volume up button while turning the headset

ON. To re-enable both indicator lights, turn the headset off; then press the volume up

button again while turning the headset ON.

NOTE: This process only disables online and standby indicator lights when headset is

connected to mobile phone. All other indicator lights, such as low battery, will continue

to function.

TO DISABLE ONLINE AND STANDBY

INDICATOR LIGhTS

POWERING

CHARGE LEVEL INDICATION

When the headset is turned on, the

indicator light will briefly show the

headset charge level.

1. Turn on the headset by pressing

and holding the call control button

until the indicator light glows blue.

If you are wearing the headset,

you will hear a beep when the

power turns on. The indicator light

will flash blue every 5 seconds

when the power is on.

2. Turnofftheheadset bypressingthe

call control button for 6-8 seconds

until the indicator light glows red

or until you hear the beep. The

indicator light remains unlit when

the power is off.

3 red flashes = greater than 2/3 battery charge

2 red flashes = 1/3 to 2/3 battery charge

1 red flash = less than 1/3 battery charge

Right ear

Left ear NN

ADJUSTING FIT

The Plantronics Discovery 650E

headset comes with three soft gel ear

tips and an optional ear loop.

1. The medium-sized ear tip is pre-

installed and aligned for wearing

on the right ear (R).

2. For left ear wearing, twist the ear

tip counterclockwise.

3. Place the headset into your ear and

check to see that it fits comfortably.

If the headset is either too tight

or too loose, remove the medium-

sized ear tip from the headset by

turning the ear tip to the centre

or neutral position.

1. 2.

The ear loop may be attached to the

headset to improve stability.

1. Remove the ear tip from the

headset by turning the ear tip to

the center or neutral position and

pulling the ear tip away from the

headset.

2. Attach the ear loop between the ear

tip and the headset.

3. Replace the ear tip.

USING ThE OPTIONAL EAR LOOP

4. In the neutral position, the ear tip

can easily be removed by pulling

the ear tip directly away from the

headset.

Next, select the ear tip size that

fits most comfortably in your ear.

Hold the ear tip with the elongated

edge pointing down toward the

neutral position and then push

the ear tip onto the headset.

NOTE Choose an ear tip that is large

enough such that it will not enter the

ear canal. Do not insert the ear tip

into the ear canal as it may become

lodged in the ear canal. The ear tip

should rest against the entrance to

the ear canal.

USING YOUR HEADSET

ANSWERING/

ENDING/MAKING

CALLS

To answer or end a call, briefly press

the call control button.

To make a call, enter number on

your phone, press send, and the call

is automatically transferred to the

headset; no need to press the call

control button.

NOTE When answering a call, wait

until you hear a ring from the headset

itself (not the ring from your phone),

before pressing the call control button.

AUTO ANSWER

Removing the headset from the

pocket will automatically answer

the call. Returning the headset to the

charging pocket will end the call.

ADJUSTING

vOLUME

To increase listening volume, press

the upper end (+) of the volume/mute

button. To decrease listening volume,

press the lower end (-).

WARNING: Do not use headphones/

headsets at high volumes for an

extended period of time. Doing so can

cause hearing loss. Always listen at

moderate levels. See www.plantronics.

com for more information on headsets

and hearing.

MUTE A CALL

To turn the mute on while on a call,

press both sides of the volume/mute

button simultaneously until you hear

a beep.

To turn the mute off, press both

buttons again.

USING YOUR HEADSET

ADDITIONAL FEATURES

Redialing last number

To activate last number redial, double

press the call control button. You will

hear a high tone after each press.

Using voice dialing

With the headset on, press and hold

the call control button for 2 seconds

to activate voice dialing.

NOTE To use voice activated dialing,

the voice dialing feature must

be enabled on your phone. See

your Bluetooth phone manual for

instructions.

Rejecting a call

When receiving an incoming call,

press and hold the call control button

for 2 seconds to reject the call.

MOvING OUT OF RANGE

As the headset moves more than 33 feet (10 meters) away from the Bluetooth device

or encounters interference:

•Audio quality will degrade

•A beep will be heard in the headset when the connection drops between headset

and Bluetooth device

•When out of range, only the power off function will operate

If any of the above occur, move closer to your Bluetooth device to improve the

connection between the two devices.

Switching a call from phone to

headset

To switch an active call from your

phone to your headset, press the call

control button for 3 seconds.

Switching a call from headset to phone

To switch an active call from your

headset to your phone, press and hold

the call control button until you hear

a tone.

Indice

Lingue:

Altri manuali Plantronics Cuffia

Plantronics

Plantronics Voyager 4200 UC series Manuale utente

Plantronics

Plantronics EXPLORER 395 - Manuale utente

Plantronics

Plantronics Savi W740 Manuale utente

Plantronics

Plantronics BLACKWIRE C210 Manuale utente

Plantronics

Plantronics BackBeat FIT 3100 Series Manuale utente

Plantronics

Plantronics Voyager 5200 UC Manuale utente

Plantronics

Plantronics SUPRA Manuale utente

Plantronics

Plantronics Blackwire 710 Manuale utente

Plantronics

Plantronics Savi 8200 Series Manuale utente

Plantronics

Plantronics Savi Office WO1 Manuale utente

Plantronics

Plantronics EncorePro HW510 Manuale utente

Plantronics

Plantronics Voyager 5200 UC Manuale utente

Plantronics

Plantronics Blackwire C510- M Manuale utente

Plantronics

Plantronics CS70 Series Manuale utente

Plantronics

Plantronics Plantronics 510SL Manuale utente

Plantronics

Plantronics EXPLORER 230 Manuale utente

Plantronics

Plantronics ENCORE H91 Manuale utente

Plantronics

Plantronics Savi W440-M Manuale utente

Plantronics

Plantronics Tristar Manuale utente

Plantronics

Plantronics VOYAGER 520 Manuale utente

Plantronics

Plantronics Savi W745 Manuale utente

Plantronics

Plantronics Pulsar 590 series Manuale utente

Plantronics

Plantronics BackBeat PRO 2 Manuale utente

Plantronics

Plantronics Discovery 640 Manuale utente

Manuali Cuffia popolari di altre marche

Sena

Sena SMH10 Manuale utente

IASUS

IASUS Stealth IA-NT4-BASIC-BT Manuale utente

Sennheiser

Sennheiser EPOS ADAPT 230 Manuale utente

Doro

Doro Flexus HS2005 Manuale utente

GE 98971 Manuale utente

Hama

Hama 00184070 Manuale utente

Blue Tiger

Blue Tiger Advantage PLUS Manuale utente

Jawbone

Jawbone Icon Manuale utente

Jabra

Jabra FR 20 Manuale utente

Roxcore

Roxcore Flow A+ Manuale utente

Turtle Beach

Turtle Beach XP 510 Manuale utente

Philips

Philips SHB6101 Manuale utente

Jabra

Jabra PRO 9460 Duo Manuale utente

HyperX

HyperX HyperX Cloud Flight Manuale utente

Bose

Bose MIE2 Mobile Manuale utente

Jabra

Jabra Steel Manuale utente

HyperX

HyperX cloud ii Manuale utente

Southwing

Southwing SA505 Manuale utente
