Plantronics DISCOVERY 925 Manuale utente
Plantronics Discovery®925
User Guide
ii
Welcome
Thank you for purchasing the Plantronics Discovery®925 earpiece.
This guide contains instructions for setting up and using
your new earpiece.
Please refer to the separate “For Your Safety” booklet for important
product safety information prior to use of the product.
Getting Assistance
The Plantronics Technical Assistance Centre is ready to assist you.
You can find answers to frequently asked questions, ask a question
using e-mail, receive service over the Internet, or speak directly
with a representative. Visit www.plantronics.com/support or call
your country support line mentioned at the back of this user guide.
NOTE If you are considering returning this earpiece, please contact
the Technical Assistance Centre first.
Registering Your Product
Visit www.plantronics.com/productregistration to register your product
online so we can provide you with the best service and technical support.
NOTE For pairing your earpiece, your PIN code, or “Passkey,” is 0000.
iii
Contents
Package Contents, Features and Accessories......................................iv
Charging Your Earpiece........................................................................1
Using the AC or USB charger......................................................1
Using the Charging Case.............................................................2
Checking the Battery Level..........................................................2
Recharging the Charging Case....................................................3
Pairing Your Earpiece............................................................................4
Plantronics QuickPair™ Technology............................................4
How to Pair Your Phone With Your Earpiece for the First Time.....5
Adjusting the Fit....................................................................................6
How to Install a Different Gel Eartip..............................................6
Earpiece Controls.................................................................................7
Hands-Free Features............................................................................8
Range ..................................................................................................9
Indicator Lights and Tones....................................................................9
Troubleshooting..................................................................................11
Using More Than One Bluetooth Phone..............................................13
How to Turn the Multipoint Feature On and Off..........................13
How to Initiate a Call..................................................................13
How to Answer a Call While Talking on the Other Phone ...........13
Product Specifications........................................................................14
Package Contents and Features
Optional Accessories*
Vehicle Power Charger
#78583-01
Earpiece
Charging Case
* Not included. To order, please contact your Plantronics supplier or go
to www.plantronics.com
AC Charger
100–240V USB Charging Cable
Volume Control Button
Charging Jack
Eartip
Stabilizing Eartips
(small, medium, and large)
Call Control Button
USB Lanyard
#79393-01
iv
1
Option A: Using the AC Charger
1 Plug the AC charger into a power outlet.
2 Connect the AC charger to the charging jack on the earpiece.
Charging Your Earpiece
Your new earpiece performs best when fully charged. While your
earpiece is charging, the indicator light slowly flashes red. When your
earpiece is fully charged, the indicator light turns off. This applies to
all charging options.
1
2
Option B: Using the USB Charger
1 Connect USB charger to the USB
port on a computer or laptop.
2 Connect the USB charger to the
charging jack on the earpiece.
3 Turn the computer or laptop on.
1
2
3
WARNING Do not use your earpiece while it is
connected to the charger.
CHARGING TIME
3 hours.....Full charge using
AC or USB
1 hour.......Minimum charge
before first use
2
Option C: Using the Charging Case
Open the cover of the case. Align the charging jack on the earpiece with
the micro USB connection in the case. Gently push the earpiece onto
the micro USB connection until you feel it click into place.
IMPORTANT Incorrect removal of the earpiece from the case will
damage the micro USB port in the case. To properly remove the
earpiece, use your thumb to gently push the earpiece in a diagonal,
not vertical, direction away from the micro USB connector.
Checking the Battery Level of Your Earpiece
With the earpiece on, simultaneously press and hold the call control
button and the volume button for about 2 seconds. The indicator light
flashes red to show the charge level.
Charging Your Earpiece
press and hold the call control
CHARGE INDICATOR LIGHTS
Red Flashes Battery Level
1 Full battery
2 1/3 to 2/3 full
3 Less than 1/3 full
Volume Button
Call Control Button
CHARGING TIME
3 hours.....Full charge using
charging case
1 hour.......Minimum charge
before first use
3
2
The charging case provides one full charge to your earpiece before the
battery within the case requires charging. While the case is charging,
the indicator light on the bottom of the case flashes red. When fully
charged, the indicator turns off.
Recharging the Charging Case
1 To check the battery status of the charging case, you must
connect the earpiece to the case.
If the earpiece does not begin charging mode (indicator light slowly
flashes red) then both the earpiece and case need recharging.
2 Plug either the AC charger or the USB charger to power
source before connecting to the charging jack on the bottom
of the case.
If you disconnect the power source from the case after 10 minutes of
charging you must then wait at least 60 minutes before reconnecting
a power source to resume the charging cycle.
NOTE If recharging with the AC charger, the charging case will feel
warm to the touch during the charging cycle. Once fully charged, the
case will cool down. See the separate “For Your Safety” booklet for
more information.
1
Charging Your Earpiece
Indicator Light
Charging Jack
CHARGING TIME
9 hours....Full charge
using USB
3 hours....Full charge
using AC
4
Pairing Your Earpiece
Pairing is the process of introducing your earpiece to your phone.
Before using your earpiece for the first time, you must pair it with
your Bluetooth®wireless technology enabled phone. Normally you
need to pair your earpiece with your phone only once.
To see a demo of the pairing process, visit www.plantronics.com/
EasyToPair (only available in English).
Plantronics QuickPair™Technology
Your new earpiece includes Plantronics QuickPair technology to simplify
the Bluetooth setup process. The fi
rst time you turn your earpiece on,
your earpiece automatically enters pairing mode for 10 minutes. Once
paired successfully, your earpiece stays on for instant use.
If not successfully paired after 10 minutes, your earpiece automatically
powers off. When you turn the earpiece on again, it automatically goes
into pairing mode until successfully paired with a Bluetooth phone.
5
3
2
How to Pair Your Phone with Your Earpiece for the First Time
1 Turn on the Bluetooth feature on your phone.
For most phones, select Settings/Tools > Connections >
Bluetooth > On. See your phone’s user guide for more information.
2 Turn the earpiece on.
Press and hold the call control button until the indicator flashes
red/blue. The earpiece is now in pairing mode.
If you don’t see the red/blue flash, press and hold the call control
button to turn your earpiece off, and then press and hold the call
control button again until you see the red/blue flash.
3 Use the commands on your phone to locate your earpiece.
For most phones, select Settings/Tools > Connections > Bluetooth
> Search > 9XXPlantronics. See your phone’s user guide for more
information.
4 When prompted for the PIN code or Passkey, enter 0000.
Pairing is successful when the indicator on your earpiece flashes
blue. Your earpiece is now connected and ready to use.
Pairing Your Earpiece
SETTINGS
Time and Date
Phone Settings
Bluetooth
Sound Settings
Network Serv ces
Security
Reset Settings
1BLUETOOTH
BLUETOOTH
9XXPlantronics
PASSKE Y
0000
4
B O
BLUETOOTH
9XXPlantronics
PASSKEY
0000
6
How to Install a Different Gel Eartip
If the earpiece does not feel stable, the eartip needs adjusting or it may
be the wrong size for your ear. The earpiece comes with the medium
eartip installed, but you can replace it with the optional small or large
eartip provided.
Adjusting the Fit
For optimal voice clarity,
point the boom towards
the corner of your mouth.
Correct Fit Incorrect Fit
23
1 Remove the earpiece from your ear.
Rotate the eartip on the earpiece to position the stabilizer to rest
comfortably in your ear. If the earpiece still feels unstable, then remove
the earpiece from your ear and change the eartip to a different size.
2 To remove the eartip, hold the stabilizer and gently pull the
eartip off the speaker housing.
3 To fit a new eartip, position the eartip over the speaker
housing with the stabilizer pointed away from the microphone
boom and gently press the eartip onto speaker housing.
Eartip
Speaker housing
1
