Plantronics Savi W730-M Manuale utente

Getting started:

The Plantronics Savi headset is ready to use with

your computer and Microsoft® Lync™.

1. Connect your Savi base to the computer.

If this is the first time you are

connecting, wait for the installation

process to complete. Restart the

computer if directed to do so.

Configuring Microsoft Lync to always route call

audio to the headset:

2. Click on the Options button in the main

Microsoft Lync window.

3. Select the Audio Device option.

4. Choose your Plantronics headset for

Audio Device.

5. Check the Also Ring box for Secondary

Ringer and choose your PC speakers

from the drop down menu if you would

like them to ring for incoming calls.

6. In this screen you can also test and

adjust volumes.

7. Click Ok when finished.

Note: USB configuration settings are unique for

each USB port. If you connect the headset to a

different port you will need to make these

changes again to set behavior for that USB port.

Savi®W730-M™Quick Setup Guide

Welcome:

Using a Plantronics Savi headset for PC

calls will deliver a simpler, more

comfortable and better sounding audio

experience than you could get using just

your computer’s internal microphone

and speaker.

©2011 Plantronics, Inc. All rights reserved, Plantronics, the logo design, Savi and W730-M are trademarks or registered trademarks of Plantronics, Inc. Microsoft and Lync are either registered trademarks or trademarks of Microsoft Corporation in the

United States and/or other countries. Published 09.11

Savi W730-M Key Features:

Manages PC, deskphone and mobile

calls from a single headset

One-touch call answer/end, vol +/-,

mute and flash across devices

Wireless freedom up to 350 feet from

your desk

Conference in up to three additional

Savi headsets

Making and Receiving Calls with Microsoft Lync

To MAKE a call:

To call an existing contact, click on the

drop down next to their name (1) and

select the number you would like to

call (2).

You can also enter a phone number

manually using the search box located

at the top of the main Microsoft Lync

screen (3).

When a call is placed, a call window

will open and the audio will be routed

to your headset.

To RECEIVE a call:

When you receive a call, a notification

window will appear in the lower right

corner of your computer screen (4).

To answer the call, use the controls on

your headset or click on the call

notification window (5).

United States and/or other countries. Published 09.11

To REDIRECT a call:

You can also redirect a call by clicking

Redirect (6) and choosing one of the

options given.
