Plantronics Voyager 8200 UC Manuale utente

Voyager 8200 UC

User Guide

Contents

Headset overview 3

Be safe 3

Connect and pair 4

Connect to PC 4

Conﬁgure for media 4

Pair to mobile device 4

Pair mode 5

USB Bluetooth adapter 5

Pair USB adapter again 5

NFC pairing 5

Load software 6

The Basics 7

Power on/off 7

Fit 7

Volume 7

Make/Take/End Calls 7

Mute/unmute 8

Play/pause music 8

Track selection 8

Voice control 8

Charge 8

More Features 10

Select language 10

Use sensors 10

ANC 11

OpenMic 11

Change headset settings 11

Caller Announcement (mobile phone only) 11

Update ﬁrmware 12

Headset recovery 12

Troubleshooting 13

Support 15

ANC

OpenMic

voice

00:02

Volume dial

Voice control: Siri, Google Now™, Cortana

Play previous track*

Play/pause*

Skip to next track*

ANC Active Noise Cancelling

OpenMic Hear surroundings

Mute

Headphone LEDs

Call button: Answer/end/decline call

Power

Bluetooth®pairing

NOTE *Functionality varies by application. May not function with web-based apps.

Please read the safety guide for important safety, charging, battery and regulatory information

before using your new headset.

Headset overview

Be safe

Your Bluetooth USB adapter comes pre-paired to your headset.

1Turn on your headset and insert the Bluetooth USB adapter into your laptop or PC.

2The USB adapter LED ﬂashes blue and then turns solid blue to indicate the headset is connected to

the USB adapter. If you are wearing your headset you will hear “PC connected” to indicate the

connection has been established. When on a call, the LED on the USB adapter will flash blue.

When not on a call the LED will be solid blue.

3OPTIONAL Load Plantronics Hub for Windows and Mac by visiting plantronics.com/software. This

will allow you to customize your headset behavior through advanced settings and options.

Your USB Bluetooth adapter comes ready to take calls, but listening to music takes some

additional configuration.

Windows

1To conﬁgure your Bluetooth USB adapter to play music, go to Start menu > Control Panel > Sound

> Playback tab. Select Plantronics BT600, set it as the Default Device and click OK.

2To pause music when you place or receive calls, go to Start menu > Control Panel > Sound >

Communications tab and select the desired parameter.

Mac

1To conﬁgure the Bluetooth USB adapter, go to Apple menu > System Preferences > Sound. On

both the Input and Output tabs, select Plantronics BT600.

1To put your headset in pair mode, press and hold the power button towards the Bluetooth icon

until you hear "pairing" and the headset LEDs flash red and blue.

2Activate Bluetooth on your phone and set it to search for new devices.

•iPhone Settings > Bluetooth > On*

•Android Settings > Bluetooth: On > Scan for devices*

NOTE *Menus may vary by device.

3Select “PLT V8200 Series.”

If necessary, enter four zeros (0000) for the passcode or accept the connection.

Once successfully paired, you hear “pairing successful” and the headset LEDs stop flashing.

NOTE To enable caller name announcement, allow access to your contacts if your phone prompts

you.

NOTE Your headset can pair with up to 8 devices but only maintain 2 connections simultaneously;

this includes the Bluetooth USB adapter.

Connect and pair

Connect to PC

Configure for media

Pair to mobile device

Slide and hold the power button towards the Bluetooth icon until the LEDs flash red and blue.

USB LEDs What they mean

Red and blue ﬂashes Pairing

Solid Blue Pairing successful; Connected

Blue ﬂashes On a call

Solid red Mute active

Purple ﬂashes Streaming music/media from computer

1Insert the high-fidelity Bluetooth USB adapter into your laptop or computer and wait for your

computer to recognize it.

2Put your headphones in pair mode.

3Put your Bluetooth USB adapter into pair mode by gently pressing and holding the pair button

with a pen or paperclip until the Bluetooth USB adapter flashes red and blue.

Pairing is successful when you hear "pairing successful" and the Bluetooth USB adapter LED is

solid blue.

1Ensure NFC is on and your phone’s display is unlocked.

2Tap and hold the headphones to the phone’s NFC tag location until NFC pairing completes. If

necessary, accept the connection.

TIP Keep an eye on your Smartphone's screen for prompts to start and accept the pairing process.

NOTE The headphone’s NFC tag is located on the outside of the left ear cup. Phone NFC tag locations

vary.

Pair mode

USB Bluetooth adapter

Pair USB adapter again

NFC pairing

NOTE Some softphones require the installation of Plantronics Hub for Windows and Mac to enable

headset control (answer/end and mute) functionality.

• Download Plantronics Hub for Windows/Mac by visiting plantronics.com/software.

• Download Plantronics Hub for iOS/Android by visiting plantronics.com/software, the App Store

or Google Play.

Manage your headset settings with your computer or mobile device with Plantronics Hub for

Windows and Mac or Plantronics Hub for iOS and Android, respectively.

Plantronics Hub iOS and Android Windows and Mac

Call control for softphones available for some

softphones

Change headset language X X

Update firmware X X

Turn features on/off X X

View user guide X X

Battery meter X X

Find MyHeadset X

Load software

ANC

OpenMic

voice

00:02

Slide the switch to power on or off.

IMPORTANT Headset microphones are on the front of your earcups.

For best call audio, ensure that left and right earcups are on the correct ear.

Rotate the volume wheel forward (+) or backward (–) to control the volume.

Adjust headset microphone volume (softphone)

Place a test softphone call and adjust softphone volume and PC sound volume accordingly.

Answer a call

Choose:

• Tap the Call button

The Basics

Power on/off

Fit

Volume

Make/Take/End Calls

• Put on the headset to answer call

IMPORTANT For best call audio, ensure that left and right earcups are on the correct ear.

Answer a second call

First, tap the Call button to end current call, then tap the Call button again to answer new call.

End a call

Tap the Call button to end current call.

Hold a call

Double-tap the Call button to put a call on hold. Tap the Call button again to answer an

incoming call.

NOTE Up to 2 calls can be put on hold.

Switch between calls (flash)

Double-tap the Call button to switch between calls.

NOTE Flash functionality works only between calls of the same type. Flash does not work between

mobile and softphone calls.

Call back last call

Double-tap the Call button .

Answer calls from a second device

It's easy to answer calls from two devices (including softphone).

When on a call, you hear a ringtone notification of the incoming call from the second paired

device.

To answer a second call from the other device, first tap the Call button to end the current call

and tap the Call button again to answer the new call. If you choose to not answer the second call,

it will go to voicemail.

While on an active call, choose:

• Tap the red Mute button

• Take off/put on your headset while on an active call (requires active smart sensors)

Tap the Play/pause button.

NOTE Because your headset is equipped with sensors, if you are playing music and you take off your

headset, your music pauses. If you put on your headset, your music resumes (functionality varies by

application and doesn't function with web-based apps).

Tap the Forward button or Back button to control the track selection.

Siri, Google Now™, Cortana Press and hold the Play/pause button for 2 seconds until you hear

the tone. Wait for the phone prompt to activate voice dialing, search, and other smartphone voice

controls.

It takes up to 3 hours to fully charge your headphones. The LEDs turn off once charging is

complete.

Mute/unmute

Play/pause music

Track selection

Voice control

Charge

TIP To check the headphones battery status, tap the Call button while wearing your headphones.

Headphones must be in idle state.

Your headphones have up to 24 hours of listening time.

You can wirelessly change your headset language using Plantronics Hub software. Download:

plantronics.com/software. Choose:

• With your headset paired to your smartphone, select headset language in Plantronics Hub for iOS/

Android

• With your headset connected to your computer via USB adapter or cable, select headset language

in Plantronics Hub for Windows/Mac*

*USB adapter not included in all models.

Voice alerts list

Following is a list of common voice alerts. You can use Plantronics Hub to customize some of

these alerts. Download Plantronics Hub at plantronics.com/software

• "Answering call"

• "Battery low"

• "Redialing last outgoing call"

• "Incoming call"

• "Mute on/mute off"

• "No phone is connected"

• "Pairing"

• "Pairing incomplete, restart headset"

• "Pairing successful"

• "Power on/off"

• "Phone X connected/disconnected"

• "Recharge headset"

• "Smart sensors on/off"

• "Battery high"

• "Volume maximum/minimum"

Smart sensors respond when you put on or take off your headphones. Customize in Plantronics

Hub. Below describes default settings.

With active sensors putting on the headphones will: taking off the headphones will:

Mobile/softphone call answer the incoming call mute the active call

Music/media resume music/media (if playing

previous to taking off)*

pause music/media (if playing)*

NOTE *Functionality varies by application. May not function with web-based apps.

Reset Sensors

You may need to reset the sensors if they are not working as expected.

To reset the headset sensors, connect it directly to your computer's USB port, and place it, with

the ear cups up, on a flat, non-metallic surface for more than 10 seconds.

More Features

Select language

Use sensors
