Plantronics K100 Manuale utente

LEARN

K100™Bluetooth®In-car Speakerphone

TAKE A GOOD LOOK

MULTI-FUNCTION BUTTON

• Poweronoroff(3- to 4-second

press)

• Takeacallorendit (1 tap)

• Redial (2 taps)

• Transferaudiotoorfromphone

duringcall (3-second press)

• Rejectacall (press and hold until

you hear a single tone)

• Initiatephone’svoice-dialing

(2-second press until second

tone is heard)

• Activatemanualpairing(with

power off, press and hold until

LED ﬂashes red/blue)

• Reconnect(1 tap)

• Enable/DisableMissedCall

Indicator (1 tap)

FM BUTTON

• FMtransmitonoroff (1 tap)

• FindFMchannel (press and hold

until station option is announced)

LED

• Charging (solid red)

• Poweringonoroff(2 blue or red ﬂashes)

• FMtransmission (2 purple ﬂashes)

• Missedcall (1 purple ﬂash)

• Pairingmode (red/blue ﬂashes)

VOLUME WHEEL

• Increasevolume(rotate clockwise)

• Decreasevolume (rotate counterclockwise)

MUTE BUTTON

• Muteonoroff(1 tap)

• Nightmode:LEDonoroff

(2-second press until tone is heard)

MICRO USB CHARGING PORT

• WithmicroUSBorcarcharger:

2.5 hours (100% charge)

• Bestperformancewhenfullycharged

MICROPHONES

Besafe!Pleasereadthesafetyguide

beforeusingyournewspeakerphone.

CONNECT TO YOUR PHONE

“Pairing” is the process that

connects the speakerphone

to your phone. You can pair

more phones but can have

only one active connection

at a time.

1. READY

Activate the Bluetooth feature on

your phone, then use the phone’s

settings to add/search/discover

new Bluetooth devices.

iPhone: Settings > General >

Bluetooth > On

(starts the search for devices)

BlackBerry®smartphone:

Settings/options > Bluetooth: On >

Search for devices

VIDEO TUTORIAL FOR USA:

www.plantronics.com/pairing

2. SET

FirstTime:

With speakerphone turned off,

activate Bluetooth pairing mode

by pressing and holding the Multi-

function button to turn on speak-

erphone. The LED ﬂashes red/blue

to indicate pairing mode.

3. CONNECT

Select “PLT_K100” from the list

of Bluetooth devices shown on

your phone.

If the phone asks for a passcode,

enter four zeros (0000). You may

see **** on screen.

Some phones also ask to conﬁrm

the connection after pairing.

The speakerphone LED will stop

ﬂashing red/blue once your phone

is successfully paired/connected.

HEAR CALLS THROUGH YOUR CAR STEREO

Suggested placement

You can listen to calls through

your car stereo speakers by

transferring the audio from

the speakerphone to one of

ﬁve FM channel options:

88.3MHz

88.7MHz

89.1MHz

89.5MHz

89.9MHz

If your phone is A2DP-enabled

you can also hear streaming

audio like GPS instructions and

music through your car speakers.

We recommend that you trans-

fer audio to an FM channel

before you start driving, and

that you make a routinely clear

channel a preset on your stereo.

1. READY

Ensure that your phone and speakerphone are

powered on and connected.

2. SET

Press the FM button to enter FM transmit

mode. The FM transmit channel will be an-

nounced.

3. CONNECT

Manually set your radio to the announced FM channel. You are now ready to transmit calls

and streaming audio like GPS directions from your phone to your car stereo.

If a radio station suddenly takes over the FM channel, tap the FM button to quickly redirect

the audio back through the speakerphone.

To ﬁnd another FM channel, while FM is turned on, press and hold the FM button until another

channel option is announced, then tune your radio to the new channel.

LISTEN TO THE VOICE

WHAT YOU’LL HEAR WHEN YOU’LL HEAR IT

PowerOn After pressing the Multi-Function button for 3 to 4 seconds

PowerOff After pressing the Multi-Function button for 3 to 4 seconds

BatteryLow When you have less than an hour left before the battery

must be recharged

Pairing While the speakerphone and phone are trying to pair/connect

PairingIncomplete After the speakerphone and phone tried to pair but failed

LostConnection When the phone and speakerphone lose the Bluetooth connection

CallTerminated After ending a call or when using the call back feature through

visual voice mail

VolumeMaximum After reaching the highest volume setting

Connected After turning the speakerphone on or reconnecting a dropped

Bluetooth signal

MuteOn After tapping the Mute button

MuteOff From muted, after tapping the Mute button

FMONChannelXX.X After tapping the FM button, FM transmission turns on and the

voice announces the current station it is using

FMChannelXX.X After pressing and holding the FM button, the voice announces

the channel it now uses

FMOff From on, after tapping the FM button to turn transmission off

This speakerphone announces various

status alerts when you power on/off,

run low on talk time, or lose/reconnect

the Bluetooth connection to your

phone.

TIPS

Keep Your Eyes on the Road:

The controls are easy to ﬁnd with your

ﬁngertips without looking for them.

Before driving, reach up and familiarize

yourself with the controls so you can

keep your eyes on the road when a call

comes in.

The notched Volume wheel is easy•

to feel.

The Multi-function button is inside•

the wheel.

The Mute button has a raised notch.•

Avoid a Dead Battery:

Remember to power off the speaker-

phone when you exit your car. If you

forget, the speakerphone will automat-

ically turn off after 90 minutes of not

having an active connection.

Protect Your Hearing:

You can adjust the volume faster by

turning the volume wheel faster. To

adjust the volume a small amount,

turn the wheel slowly.

Learn to Share:

When powering on, the speakerphone

searches for the last connected phone.

If the last connected phone is not

within range, or the Bluetooth fea-

ture is turned off on the phone, then

another phone within range that has

been previously paired with the speak-

erphone can be connected by tapping

the Multi-function button.

Turn the LED On or Off:

For comfortable night driving, you

can turn the lights on or off by press-

ing and holding the Mute button for

2 seconds until you hear a tone.

Listen to the Voice:

This speakerphone says various status

alerts when you power on/off, lose/

reconnect the Bluetooth connection

to your phone, or change FM channels.

Sound Your Best:

Clip the speakerphone to your visor

where the two microphones, located

on the top of the unit, can be closest

to your face so you can speak in a

normal tone of voice and be heard.

SPECIFICATIONS

TalkTime Up to 17 hours

StandbyTime Up to 15 days

OperatingDistance(Range) Up to 33 feet from phone

SpeakerphoneWeight 92 grams

SpeakerphoneDimensions 120 x 60 x 16.5mm (without clip)

ChargeConnector Micro USB connector

BatteryType Rechargeable, non-replaceable Lithium-ion polymer

ChargeTime(Maximum) 2.5 hours to full charge

PowerRequirements 5V DC - 500mA

BluetoothVersion 2.1 with EDR and eSCO

BluetoothProles Hands-Free (HFP) 1.5, Headset (HSP) 1.1 and Advanced

Audio Distribution (A2DP)

Operating,Storageand

ChargingTemperature

14°F - 122°F (-10°C - 50°C)

NEED MORE HELP?

24-hour support in USA:

1-866-363-BLUE (2583)

1-year limited warranty details:

www.plantronics.com/warranty

or registered trademarks of Plantronics, Inc. The Bluetooth word mark and logos are

owned by the Bluetooth SIG, Inc. and any use of such marks by Plantronics, Inc. is under

license. iPhone is a trademark of Apple Inc. registered in the U.S. and other countries.

Blackberry is owned by Research In Motion Limited and is registered in the United

States and may be pending or registered in other countries. Plantronics, Inc is not

endorsed, sponsored, afﬁliated with or otherwise authorized by Research In Motion

Limited. AM84444-01 (08/10)

Z109

N10687
