PNI SafeHome PT945M Manuale utente
Camera supraveghere mini PNI SafeHome
PT945M 1080P WiFi, control prin internet
Mini surveillance camera PNI SafeHome
PT945M 1080P WiFi
EN - User manual
RO –Manual de utilizare
ABOUT PNI SafeHome PT945M 1080P WiFi
Product introduction and main features:
The PNI PT945 mini surveillance camera is a 2MP IP camera designed for remote video / audio
surveillance and monitoring of indoor locations. The camera connects to the internet via 2.4GHz Wi-
Fi to stream real-time video to the dedicated Tuya Smart or Smart Life application on your
smartphone. It can save videos locally to the microSD card. The camera is also equipped with a motion
detection function.
1. CAMERA INSTALLATION
Important conditions:
- Connect the camera to a 230 V power source using the adapter in the package to charge the camera
battery.
- The first configuration must be made near the internet source / wireless router;
- If you need local recordings, install a microSD TF card of up to 64 GB in the camera (not included).
Search for the "Tuya Smart" or "Smart Life" app for iOS / Android smartphone in the App Store /
Google Play Store.
Android & iOS App
2. REGISTER / LOG IN WITH EXISTING ACCOUNT
2.1 Register
If you do not yet have an account in the Tuya application, you can register / create an account or log
in via personal e-mail or personal phone number, using a verification code procedure.
Read and follow the steps below to describe the registration process:
2.2 Log in with existing account
If you already have an account in the Tuya app, you can skip creating a new account and click "Log in
with existing account" to access the login page.
(1) The system automatically select the current Country/Region, or you can manually select the
Country/ Region.
(2) ) Enter your registered e-mail address or mobile number enter your password to log in the system.
If your phone has installed WeChat App or QQ App, click WeChat/QQ icon in the log in with social
media acount area. After accessing the authorization page, and filled in received code from your e-
mail/phone log in the system.
3. ADD DEVICE
3.1 QR code net-pairing
Attention: The product only accepts 2.4 GHz Wi-Fi networks. It does not support 5 GHz Wi-Fi networks.
Before configuring the camera with Wi-Fi, please set / check the router parameters.
The Wi-Fi password must not contain special characters such as: ~! @ # $% ^ & * ().
When setting up your Wi-Fi connection, make sure your router, mobile phone, and camera are as
close as possible to a quick setup of your devices..
Connect your smartphone to the Wi-Fi router with internet access and activate the location and
Bluetooth on your phone.
1. Turn on the camera from the ON / OFF button on the back of the camera by moving it to ON - at
which point a blue LED will light up continuously. At approximately 20 seconds, the blue LED will
flash when the setup procedure begins.
2. Press the orange “+” or Add Device button (fig. 1) in the application to add the new device
3. Select Security & Sensors> Smart Camera (fig. 2). Check “Make sure the indicator is flashing quickly
..” and click Next (fig. 3).
Fig. 1 Fig. 2
4. With the phone connected to Wi-Fi, check the WiFi network name and enter the Wi-Fi password,
click Next (fig. 4).
5. Hold the mobile phone screen in front of the camera to read the QR code (fig. 5); the distance
between the two should be between 15 and 20 cm. Try not to move your mobile phone while
scanning. The camera read the QR code on the phone when the blue LED no longer flashes. Now
click "I Heard a Prompt"
Fig. 3 Fig. 4 Fig. 5
4. FUNCTION DESCRIPTION
Real-time preview interface
1. Setting si Management
2. Wi-Fi signal strenght
3. Speaker activation
4. SD / HD resolution
5. Full screen
6. Printscreen
7. Record live view
8. Playback of bideo
9. Cloud record
10. Motion detection alarm
11. Photo album (images created with the
screenshot are saved)
Fig. 6
5. CLICK “ 1 “ IN THE UPPER RIGHT CORNER OF THE CONTROL PAGE FOR THE
MANAGEMENT AND SETTING OF THE DEVICE (fig. 7)
Device Name - can modify the device name and device location;
Device Information –to view: Owner, IP address, Device ID, Device time zone.
Tap-to-Run and Automation - View automations and scenaries created for this device
Third Party Supported - Compatible smart services (Amazon Alexa, Google Home).
Basic Settings –Basic settings of camera.
IR Night Vision –Settings for IR function.
Detection Alarm Settings - can set the motion detection switch, motion detection alarm sensitivity and
motion tracking function.
Storage settings - Shows microSD card informations, and settings for Local Recording mode.
VAS - Value-added service : you can purchase separately video cloud storage service for this camera for
monthly fee (optional according to customer needs).
Offline Notification - Activates an alarm is camera goes Offline.
Share Device - can share this device to other people, enter the people’s e-mail or mobile phone number;
(Note: the entered e-mail / mobile phone number should be registered with a Tuya App account)..
FAQ & Feedback - Questions and solutions for any problems with product behaviour.
Firmware Information - Support OTA Remote Upgrade (Do not disconnect during upgrading)).
Remove Device –you can delete the application device.
Fig. 7
7. CLICK “ME” ON THE HOME SCREEEN OF TUYA APP FOR MORE
SERVICES
1. Home Management
2. Message Center
3. FAQ & Feedback
4. More Services
- Free Services ( Servicii gratuite): IFTTT , Google Assistant, Alexa, etc;
- Value-added you can check the purchasing record of purchased value-added services: Cloud Storage for
Cameras, AI Filtered Notifications etc;
5. Settings and informations for your Tuya app account: Sound, Notifications, Network, Cache
8. FREQUENTLY ASKED QUESTIONS
I: Fail to add device during net-pairing?
R: Please make sure the mobile phone and device are connected to 2.4GHz router. Make sure the correct
Wi-Fi password is entered.
I: Still fail to add device after re-scanning?
R: If fail to add device, it is recommended to restart the device or power off the device, and try again.
I: The device cannot preview?
R: :Check for weak Wi-Fi signal. You can place the camera closer to the router. If it still doesn’t work, reset
the device, and add it again.
I: Why the device is still on the list after resetting the device?
R: The device resetting only resets the camera’s network configuration and cannot change the
configuration on the App. You must log in the App to delete the camera from the list.
I: How to connect the camera to another router?
R: First log in the App to delete and reset the device, and configure the device again through the App.
I: Why the device cannot identify SD card?
R: It is recommended to insert and remove the SD card after power off the device. Check if the SD card is
under normal service conditions and the format is FAT32. The App shall suggest “”could not find SD card””
under unstable network of the mobile phone or the device.
I: The device is online and has an alarm event, but the mobile phone cannot receive the information?
R: First confirm that App allows notification in the settings of your mobile phone. EN 8 Under normal
circumstances, when an anomaly is detected, a message will appear in the notification bar of your mobile
phone. Your should set a notification sound or vibration in your mobile phone. In addition, when viewing
real-time video in the App you cannot receive alarm from the camera being viewed. Because the device
default function the camera being viewed indicating that the user is focusing on the monitoring video,
and there is no need for an alarm.
Using the advanced intelligent alarm push algorithm to ensure that the alarm message will not be
frequently, but the camera will record all the alarm messages and videos.
9. PRODUCT SPECIFICATIONS
System
Application
TUYA Smart / Smart Life
Video
High Definition
1080P 2MP
Video Compression
H.264
Low Illumination
0.1LUX/F1.2
Picture Capture
Yes
Flip Video
Yes
Lens Illumination
Camera Lens
2.4mm fixed lens
Lamp board
4 pc
Audio
Coding standard
G.711
One-way speech
Yes
Record management
Video file size
2.5GB-4.5GB / day
Record Mode
TF Card / Cloud
Alarm trigger
Alarm recording, screen shot capture
Network
WiFi
802.11b/g/n
Transmission mode
Smart Cloud Server
WIFI Connection
Sweep QR Code
Extend
TF Cad
Maximum support 64GB TF card
Reset key
Yes
Power
Power supply
DC 5V 2A
Battery capacity
Work environment
Weather proof protection
degree
IP20
Working Temperature
-20˚C ~ +60˚C
Working humidity
10% - 90%
General
Material
ABS
Product weight
40 g
Dimension
33 x 33 x 33 mm
Package
Camera
Yes
Magnetic support
Yes
User manual
Yes
Charging cable - power supply
Yes, length 1.2 meters
DESPRE PNI SafeHome PT945M 1080P WiFi
Introducere si functii principale:
Camera supraveghere miniPNI PT945 esteo camera IP de 2MP destinata supravegherii si monitorizarii
video/audio de la distanta a locatiilor interioare. Camera se conecteaza la internet prin Wi-Fi 2.4GHz
pentru a transmite imagini video in timp real catre aplicatia dedicata Tuya Smart sau Smart Life de pe
smartphone-ul dvs.. Poate salva videoclipuri local pe cardul microSD. Camera este echipata de
asemenea cu functie de detectie miscare.
2. INSTALAREA CAMEREI
Conditii importante:
- Conectati camera la o sursa de alimentare de 230 V, folosind adaptorul din pachet pentru a incarca
acumulatorul camerei.
- Prima configurare trebuie facuta in apropierea sursei de internet / router wireless;
- Daca aveti nevoie de inregistrari locale, instalati in camera un card TF microSD de maxim 64 GB (nu
este inclus). Cautati aplicatia „Tuya Smart” sau “Smart Life” pentru smartphone iOS / Android in App
Store / Google Play Store.
Android & iOS App
